$MITSUBISHI MONTERO 1998 Service Manual ��\ ��\ �\b��\ ��\ ��\ ��\ ��\ �� Inspect & If * Instrument Panel$

\
\
\b\
\
\
\
\

Inspect & If
* Instrument Panel

Damaged, Replace
* Instrument Panel Reinforcement

Component
* Seatback Assembly ( 2)

(Even If Air
* Seat Belt Pretensioner ( 2)

Bag Did Not
* Spiral Cable

Deploy)
* Steering Wheel

* Wiring Harness & Connectors

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* DO NOT attempt wiring harness repairs.

Replace entire wiring harness.

\
\
\
\
\
\
\

(
1) - Corolla and Sienna only. Replace both sensors.

(
2) - On side of impact.

(
3) - Avalon only.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-2\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Air Bag Sensor Assembly

* Front Air Bag Sensors

* Seat Belt Pretensioner ( 1)

\
\
\b\
\
\
\
\

Inspect & If
* Instrument Panel

Damaged, Replace
* Instrument Panel Reinforcement

Component
* Seat Belt Pretensioner ( 1)

(Even If Air
* Spiral Cable

Bag Did Not
* Steering Wheel

Deploy)
* Wiring Harness & Connectors

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* DO NOT attempt wiring harness repairs.

Replace entire wiring harness.

\
\
\
\
\
\
\

(
1) - Land Cruiser and Tercel only.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-3\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Air Bag Sensor Assembly

* Front Air Bag Sensor ( 1)

* Instrument Panel ( 2)

* Instrument Panel Reinforcement ( 2)

* Spiral Cable ( 3)

* Steering Wheel ( 3)

\
\
\b\
\
\
\
\

Inspect & If
* Spiral Cable ( 4)

Damaged, Replace
* Steering Wheel ( 4)

Component
* Wiring Harness & Connectors

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

Page 1026 of 1501

$MITSUBISHI MONTERO 1998 Service Manual must be replaced. ��\ ��\ � ��\ ��\ ��\ ��\ ��$

must be replaced.

\
\
\
\
\
\
\

(
1) - 1998 RAV4 only.

(
2) - Except 1996-97 Tacoma and 1998 Supra.

(
3) - Except 1998 Tacoma.

(
4) - 1998 Tacoma.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-4\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Air Bag Sensor Assembly

* Glove Compartment Door

* Instrument Panel

* Instrument Panel Reinforcement

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent,

they must be replaced.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-5\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Center Air Bag Sensor Assembly

* Front Air Bag Sensors

* Instrument Panel

* Instrument Panel Reinforcement

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* Wiring for Front Air Bag Sensors can be

repaired following manufacturer's

instructions.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-6\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Center Air Bag Sensor Assembly

Page 1027 of 1501

MITSUBISHI MONTERO 1998 Service Manual * Front Air Bag Sensors

* Glove Compartment

* Glove Compartment Door

* Front Air Bag Sensors

* Glove Compartment

* Glove Compartment Door

* Instrument Panel

* Instrument Panel Reinforcement

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* Wiring for Front Air Bag Sensors can be

repaired following manufacturer's

instructions.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-7\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Center Air Bag Sensor Assembly

* Center Console Bracket Support

* Front Air Bag Sensors

* Instrument Panel

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* Wiring for Front Air Bag Sensors can be

repaired following manufacturer's

instructions.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-8\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Air Bag Sensor Assembly

* Center Console Bracket Support

* Instrument Panel Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Page 1028 of 1501

$MITSUBISHI MONTERO 1998 Service Manual Deploy) ��\ ��\ �\b��\ ��\ ��\ ��\ ��$

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-9\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Center Air Bag Sensor Assembly

* Front Air Bag Sensors

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Wiring Harness & Connectors

Damaged, Replace

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* Wiring for Front Air Bag Sensors can be

repaired following manufacturer's

instructions.

\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-10\
\
\
\
\
\
\

Action Component or System

\
\
\b\
\
\
\
\

Replace After
* Air Bag Module(s)

Deployment
* Front Air Bag Sensors

* Spiral Cable

* Steering Wheel

\
\
\b\
\
\
\
\

Inspect & If
* Center Air Bag Sensor Assembly

Damaged, Replace
* Wiring Harness & Connectors

Component

(Even If Air

Bag Did Not

Deploy)

\
\
\b\
\
\
\
\

Comments
* If any components are damaged or bent, they

must be replaced.

* Wiring for Front Air Bag Sensors can be

repaired following manufacturer's

instructions.

\
\
\
\
\
\
\
\f

Page 1029 of 1501

MITSUBISHI MONTERO 1998 Service Manual POWER WINDOWS
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Windows
Mirage, Montero, Montero Sport & 3000GT
DESCRIPTION & OPERATION

POWER WINDOWS
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Windows
Mirage, Montero, Montero Sport & 3000GT
DESCRIPTION & OPERATION
With ignition switch in RUN position, battery voltage is
applied to master power window switch located on driver's door. Master
power window switch provides power and ground for all power window
switches and motors. Master power window switch offers one-touch
operation of driver's window. A solid state control unit, incorporated
in master switch, fully lowers driver's window when switch is
completely depressed. Master switch also includes lock-out feature to
prevent passengers from operating any of the other power window door
switches.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE\
\
\
\
\
\

Component Location
Power Window Relay ( 1) .......... In Passenger Compartment
Fuse/Relay Block
( 1) - See Fig. 1.
\
\
\
\
\
\

TROUBLE SHOOTING
POWER WINDOWS INOPERATIVE
Check for faulty fusible link, faulty power window relay or
faulty power window switches. See WIRING DIAGRAMS.
ONE WINDOW FAILS TO OPERATE
If one window does not operate, even if both master and
passenger side power window switches are pressed, check for faulty
master power window switch or power window motor that is inoperative.
If one window does not operate only when either master or passenger
side power window switch is pressed, but does operate when both
switches are pressed, check power window switch that is inoperative.
ONE-TOUCH SWITCH FUNCTION INOPERATIVE
Replace master power window switch.
COMPONENT TESTS
CIRCUIT BREAKER TEST
Press UP switch to fully close window. Continue to press
switch for 10 seconds. Release UP switch and immediately press DOWN
switch. If window begins to open within 60 seconds, circuit breaker is

Page 1030 of 1501

MITSUBISHI MONTERO 1998 Service Manual okay. Circuit breaker is part of window motor.
POWER WINDOW RELAY TEST
Mirage & 3000GT
1) Remove power window relay from fuse/relay block. See
Fig. 1 . Check for continuity

Page 1031 of 1501

MITSUBISHI MONTERO 1998 Service Manual Fig. 2: Locating Power Window Relay (Montero)
Courtesy of Mitsubishi Motor Sales of America
Fig. 3: Locating Power Window Relay (Montero Sport)
Courtesy of Mitsubishi Motor Sales of America

Page 1032 of 1501

MITSUBISHI MONTERO 1998 Service Manual Fig. 4: Locating Power Window Relay (3000GT)
Courtesy of Mitsubishi Motor Sales of America
Fig. 5: Identifying Power Window Relay Terminals (Mirage & 3000GT)
Courtesy of Mitsubishi Motor Sales of Am
