2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

CIRCUIT DIAGRAMS
H1J15X25AB
B-255

CIRCUIT DIAGRAMSB-256
INTERCOOLER WATER SPLAY

CIRCUIT DIAGRAMSB-257

CIRCUIT DIAGRAMS
H1J15X47AA
B-258
SPARE CONNECTOR (FOR FRONT FOG LAMP)

INDEX - In order of connector No.C-1
INDEX
In order of connector No.
Connector
No.Parts nameCircuit diagram pageWiring diagram
page
AA-01Side turn signal lamp (RH)B-135,139B-6,8
A-02Side turn signal lamp (LH)B-134,138B-6,8
A-03Wheel speed sensor (Front:LH)B-203,211,217,225,233,243B-6,8
A-04XSpare connector (for front fog lamp
relay)B-73,258B-6,8
A-05XHorn relayB-73,146B-6,8
A-06XCondenser fan relay (LO)B-73,177,183B-6,8
A-07XCondenser fan relay (HI)B-73,177,183B-6,8
A-08XNo connectionB-73B-6,8
A-09XRadiator fan relayB-73,102,176,182B-6,8
A-10XFront-ECUB-73,75,103,104,106,107,110,111,
114,115,124,127,130,131,132,133,
136,140,187,191, 258B-6,8
A-11XFront-ECUB-73,104,106,107,111,115,124,127,
131,133, 136,140,186,187,190,191B-6,8
A-12Front wiring harness (LH) and control
wiring harness combination B-198,206B-6,8
A-13Front wiring harness (LH) and control
wiring harness combination B-86,90,102,176,178,186,252B-6
A-16Headlamp (HI:LH)B-103,106B-6,8
A-21Fan controllerB-102,176,182B-7,8
A-23Horn (HI)B-146B-7,8
A-25Horn (LO)B-146B-7,9
A-28Headlamp (HI:RH)B-103,106B-7,9
A-31Spare connector (for front fog lamp)B-258B-7,9
A-34No connection-B-9
A-36Dual pressure switchB-178,184B-7,9
A-37Wheel speed sensor (Front:RH)B-203,211,217,225,233,243B-7,9
A-39Front combination lamp (LH)B-103,106,110,114,130,132,134,138B-7,9
A-40Front combination lamp (RH)B-103,106,111,114,130,132,135,139B-7,9
A-43Front wiring harness (LH) and control
wiring harness combination B-82,84,177,178,203,217,233B-7
A-44Intercooler water spray motorB-256B-7,9

INDEX - In order of connector No.C-2
Wiring diagram
page Circuit diagram page Parts name Connector
No.
AA-45Condenser fan motorB-177,183B-7,9
A-46Condenser fan motorB-177,183B-7,9
A-47A/C compressorB-178,184B-7,9
A-48Power steering oil pressure switchB-90,98B-7,9
BB-01Windshield wiper motorB-186,190B-10,14
B-02Throttle position sensorB-89,97,215,223,231,241B-10,14
B-03Vehicle speed sensorB-92,100,150,154,197B-10,14
B-04Brake fluid level switchB-157B-10,14
B-05XEngine speed detection connectorB-73,82,83,90,98B-10,14
B-06XNo connectionB-73B-10,14
B-07XNo connectionB-73B-10,14
B-08XNo connectionB-73B-10,14
B-09XIgnition coil relay or no
connection B-73,83B-10,14
B-10XNo connectionB-73B-10,14
B-11XEngine control relayB-73,86,94,252,254B-10,14
B-12XA/C compressor relayB-73,178,184B-10,14
B-14Control wiring harness and battery
wiring harness combinationB-79,84,91,99,157B-10,14
B-18StarterB-79B-11,15
B-19StarterB-79B-11,15
B-20Oil pressure switchB-157B-11,15
B-21AlternatorB-84B-11,15
B-22AlternatorB-84B-11,15
B-23Purge control solenoid valveB-91,99B-11,15
B-24Injector 4B-89,97B-11,15
B-25Injector 3B-89,97B-11,15
B-26Injector 2B-89,97B-11,15
B-27Injector 1B-89,97B-11,15
B-31Air flow sensorB-90,98B-11,15
B-34Oxygen sensorB-88,96B-11,15
B-36Waste gate solenoid valveB-91,99B-11,15
B-37Fuel pressure solenoid valveB-90,98B-11,15

INDEX - In order of connector No.C-3
Wiring diagram
page Circuit diagram page Parts name Connector
No.
BB-108Back-up lamp switchB-142,143B-12,16
B-110Engine coolant temperature gauge unitB-148,152B-12,16
B-112EGR solenoid valveB-91,99B-12,16
B-114Ignition coil 1B-82,83B-12,16
B-115Idle speed control servoB-88,96B-12,16
B-116Camshaft position sensorB-88,96B-12,16
B-118Engine coolant temperature sensorB-89,97B-12,16
B-119Ignition coil 2B-82,83B-12,16
B-121Crank angle sensorB-88,96B-13,16
B-122Detonation sensorB-89,97B-13,17
B-123ABS-ECUB-198,200,201,202,203,204,205,206,
208,209,210,211,229,232,233,239,
242,243B-13,17
B-138ResistorB-89,97B-13,17
B-139Electric pump relay B-216,224,234,244B-13,17
B-140Fuel pump relay 3B-93,101B-13,17
B-141Fuel pump resistorB-93,101B-13,17
B-142Secondary air control solenoid valveB-91,99B-13,17
CC-01Combination meterB-84,87,95,103,106,118,122,126,129,
135,139,148,149,152,153,156,157,
198,206,214,222,230,240,248,250,
256, 258B-18,24
C-02Combination meterB-110,115,118,122,126,129,135,139,
148,149,152,153,156,157,198,206,
248, 250,256,258B-18,24
C-03Hazard warning switchB-136,140B-18,24
C-04ClockB-194B-18,24
C-05J/C (1)B-56,62,93,101,104,107,111,112,115,
116,118,122,124,125,127,128,131,
133,136,137,140,141,148,152,153,
156,158,164,170,172,175,181,185,
187,191,194,195,196,197,212,214,
220,222,228,230,238,240,257B-18,24
C-08J/C (3)B-58,64,95,104,105,107,108,112,113,
116,117,119,123,124,125,126,127,
128,129,131,133,136,137,140,141,
149,153,159,164,165,171,172,173,
175,180,181,185,187,188,189,191,
193,194,195,202,210,214,218,222,
226,227,230,236,240,246,247,253,
255,257,258B-18,24

INDEX - In order of connector No.C-4
Wiring diagram
page Circuit diagram page Parts name Connector
No.
CC-10Outside/Inside air selection damper
control motor and potentiometerB-175,181B-18,24
C-14Blower motorB-174,180B-18,24
C-16ResistorB-174,180B-18,24
C-21SRS-ECUB-248,249,250,251B-18,24
C-22Diagnosis connectorB-92,100,105,108,113,117,119,123,
125,128,137,141,150,154,158,164,
170,172,188,189,204,205,219,227,
237,247,248,250,252,254B-18,24
C-23Diagnosis connectorB-92,100B-18,24
C-24Instrument panel wiring harness and
front door wiring harness (LH) combina-
tionB-162,163,165,170,172,173,192,193,
196B-18,24
C-26J/C (4)B-59,65,92,100,105,113,119,137,157,
158,170,188,194,197,201,204,205,
209,213,219,221,227,232,237,242,
247,250,252,254,258B-19,25
C-28J/C (5) B-66,100,108,117,123,141,164,172,
173,189,205,227,247,254B-25
C-29J/C (5) B-60,84,87,104,112,125,137,149,150,
157,187,194,197,198,214,230,248,
256B-19
C-32A/C-ECU or heater control unitB-175,181,185B-19,25
C-34No connection -B-25
C-35Instrument panel wiring harness and
instrument panel wiring harness com-
bination B-76,78,100,108,117,123,128,141,
154,164,165,172,180,185,189,205,
227,247,250,254B-25
C-36Headlamp leveling switchB-131,133B-19,25
C-41SRS-ECUB-249,251B-19,25
C-42Instrument panel wiring harness and
control wiring harness combination
B-216,234B-19
C-434WD-ECU B-201,209,212,213,214,215,216,218,
219,220,221,222,223,224,226,227,
228,230,231,232,234,236,237,238,
240,241,242,244, 246,247B-19,25
C-444WD-ECU B-201,209,212,213,216,217,219,220,
221,224,225,227,228,229,232,234,
235,237,238,239,242,244,245,247B-19,25
C-45Instrument panel wiring harness and
floor wiring harness (LH) combination
B-216,234B-19
