2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

INTERIOR -Trims52A-15
TRIMS
REMOVAL AND INSTALLATION
NOTE
Refer to GROUP42 for more information regarding door trim.
8
44±10 N•m
11
1 2649510
1312
3
7
15
16
14
Removal steps
1. Front scuff plate
2. Cowl side trim
3. Rear scuff plate
4. Front door opening trim
5. Rear door opening trim
AA"6. Front pillar trim
7. Center pillar trim, lower
8. Front seat belt connection9. Center pillar trim, upper
10. Rear pillar trim
11. Rear shelf trim
12. Speaker garnish
13. Retractor trim
14. Partition board
15. Rear end trim
16. Trunk side trim

INTERIOR -Trims52A-16
CLIP POSITION
NOTE
: Clip position
: Claw position
Section B - B
Section C - C
Section D - DSection E - ESection A - A
A ABB
C CC
CD
ClipFront pillar trim
Rear pillar trimFront scuff plate,
Rear scuff plate
Speaker garnish
Section F - F
Rear shelf
trim E
E
Front pillar trim,
Center pillar trim,
upper,
Rear pillar trim
Headlining
BBB
D
F
F
B
GG
Section G - G
Rear end trimClip
Clip
ClipClip
ClipClip H
HI
I
Section H - HSection I - I
Retractor trimRetractor trim
Craw
Craw

INTERIOR -Trims/Headlining52A-17
REMOVAL SERVICE POINT
AA"FRONT PILLAR TRIM REMOVAL
Release the clip to pull towards the direction shown in the
illustration and remove the front pillar trim.
HEADLINING
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
Removal and Installation of Front Pillar Trim, Center
Pillar Trim, upper, Rear Pillar Trim (Refer to P.52A-15.)
12
3 4 56
45
Removal steps
1. Assist grip
2. Room lamp assembly
3. Front room lamp
AA"4. Sunvisor holder5. Sunvisor assembly
DFront floor console assembly
(Refer to P.52A-10.)
AB"6. Headlining
Section A – A
Front pillar trim
A
AFront pillar trim
Instrument
panel

INTERIOR -Headlining52A-18
REMOVAL SERVICE POINTS
AA"SUNVISOR HOLDER REMOVAL
Insert the special tool into sides claws of the sunvisor holder
through the both sides of the sunvisor holder to remove the
hinges.
AB"HEADLINING REMOVAL
Bend the headlining to remove from the front passenger’s
door.
Sunvisor holder
MB990784
MB990784

INTERIOR -Seat52A-19
SEAT
FRONT SEAT
REMOVAL AND INSTALLATION
1
1
2
2 3
3
44±10 NSm
44±10 NSm
30±5NSm
30±5NSm
1. HeadrestFront seat assembly removal steps
2. Front seat anchor cover
"AA3. Front seat assembly
INSTALLATION SERVICE POINT
"AAINSTALLATION OF FRONT SEAT ASSEMBLY
(1) Temporarily tighten the nuts and bolts in all mounting
locations shown in the illustration with no load applied
to the front seat cushion and check the operation of the
seat slide.
(2) Tighten the nuts and bolts in all mounting locations to
the specified torque.

INTERIOR -Seat52A-20
DISASSEMBLY AND REASSEMBLY
HIGHT ADJUSTER SEAT
8, 9
20
Section A - A
Claw
1
2345
6
7
8
910
11 12
13
14
15
1720
44±10 NSm
44±10 NSm 12±2NSm
A
A
A9±2NSm
18
1619
A
Disassembly steps
1. Reclining knob
2. Pin
3. Height adjuster knob
4. Front seat cushion assembly
5. Front seat cushion cover
6. Front seat cushion pad
7. Front seat cushion frame
8. Reclining cover
9. Shield cover
10. Front seatback assembly
AA"11. Headrest guide
12. Front seatback cover
13. Front seatback pad
14. Front seatback frame
15. Inner seat belt
16. Shaft
17. Seat slide handle
18. Shaft
19. Shaft protector
20. Seat slide adjuster

INTERIOR -Seat52A-21
RECARO SEAT
1
2
3 45
6
87
22±3NSm
22±3NSm
Disassembly steps
1. Reclining knob
2. Reclining cover
3. Cap
4. Front seat cushion assembly5. Front seat back assembly
6. Seat rail R.H.
7. Seat rail L.H.
8. Seat slide lever

INTERIOR -Seat52A-22
REMOVAL SERVICE POINT
AA"REMOVAL OF HEADREST GUIDE
REAR SEAT
REMOVAL AND INSTALLATION
12
3
22±4NSm
3
Disassembly steps
"BA1. Rear seat cushion assembly
"AA2. Rear seatback assembly3. Rear seat hook
