WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
F
F-01F-04F-05F-08F-19
F-27F-26F-25F-24F-23F-14
F-21
F-09
F-10
F-12
F-13
F-06
F-16
F-29
F-28
B-39
LUGGAGE COMPARTMENT
R.H. drive vehicles
F-01 (2) Spare connector
F-04 (2) Luggage compartment lamp
F-05 (2-B) High mounted stop lamp
F-06 (1-B) Defogger ( - )
F-08 (2) Spare connector
F-09 (6-B) Rear combination lamp (RH)
F-10 (1) Trunk lid latch switch
F-12 (2-GR) Licence plate lamp (RH)
F-13 (2-GR) Licence plate lamp (LH)
F-14 (2-GR) Floor wiring harness (LH) and bumper
wiring harness combinationF-16 (6-B) Rear combination lamp (LH)
F-19 (1) Defogger (+)
F-21 (2) Windshield washer motor
F-23 (2-B) Electric pump
F-24 (8-GR) Floor wiring harness (LH) and 4WD wiring
harness combination
F-25 (2-B) Direction valve (LH)
F-26 (2-B) Direction valve (RH)
F-27 (3-B) Proportioning valve (for ACD control)
F-28 (3-B) Proportioning valve (for AYC control)
F-29 (3-B) Pressure sensor

SINGLE PART INSTALLATION POSITION -Relay
A
Electric
pump relay
Hydraulic unit
Fuel pump
relay 3
B
Electric pump relay
Fuel pump
relay 3
C
Ignition coil relay
Radiator fan relay
A/C compressor relay
Engine control relay
Condenser fan relay (HI)
Condenser fan relay (LO)
Horn relay
B-40
SINGLE PART INSTALLATION POSITION
RELAY
NameSymbolNameSymbol
A/C compressor relayCFuel pump relay 2D
Blower relayDFuel pump relay 3L.H. drive vehiclesA
Condenser fan relay (HI)CR.H. drive vehiclesB
Condenser fan relay (LO)CHorn relayC
Defogger relayDIgnition coil relay C
Electric pump relay

L.H. drive vehiclesAIntercooler water spray relayD
R.H. drive vehiclesBPower window relayD
Engine control relayCRadiator fan relayC
Fuel pump relay 1DRear fog lamp relayD
ABCD

SINGLE PART INSTALLATION POSITION -Relay/ECU
D
Intercooler water
spray relay
Fuel pump
relay 2
Rear fog
lamp relay
Fuel
pump relay 1
Power
window
relay
Defogger
relay
Blower relay
J/B
B-41
ECU
NameSymbolNameSymbol
4WD-ECU L.H. drive vehiclesLFront-ECUC
R.H. drive vehiclesKHeater control unit H
A/C-ECUHImmobilizer-ECUG
ABS-ECUL.H. drive vehiclesAPower window main switch
(incorporatingECU)
M
R.H. drive vehiclesB(incorporating ECU)
Column switch (incorporating column-ECU)FPower window motor
(incorporatingECU)
FrontN
ETACS-ECUE(incorporating ECU)RearO
Engine-ECUISRS-ECUJ
Fan controllerD
NOTE
*: also equipped at the right side.
ABC
D
EFGHI
JKL
MNO**

SINGLE PART INSTALLATION POSITION -ECU
A
ABS-ECU
B
ABS-ECU
C
Front-ECU
D
Fan controller
E
ETACS-
ECU
J/B
F
Column switch
column-ECU>
G
Ignition key cylinder
Immobilizer-
ECU
H
Heater control unit
A/C> or A/C-ECU

I
Engine-ECU
J
SRS-ECU
B-42

SINGLE PART INSTALLATION POSITION -ECU/Sensor
K
4WD-ECU
Glove box
L
Door check (front
door: RH side)
4WD-ECU
MPower window
main switch
(incorporating
ECU)N
Power window
motor (Front)
ECU>
O
Power window
motor (Rear)
ECU>
B-43
SENSOR
NameSymbolNameSymbol
Air flow sensorGOxygen sensorE
Air thermo sensor JOxygen sensor (rear)L
Camshaft position sensorFPressure sensor N
Crank angle sensorDSteering wheel sensor H
Detonation sensorAThrottle position sensorB
Engine coolant temperature sensorFVehicle speed sensorC
G sensor (longitudinal) IWheel speed sensorFrontK
G sensor (lateral) IRearM

SINGLE PART INSTALLATION POSITION -Sensor
A
Intake
manifold
Detonation sensor
B
Throttle position
sensor
C
Vehicle
speed sensor
Transfer
D
Crank angle sensor
Crankshaft sprocket
B-44
ABC
DEFG
H
IJ
KLMN

SINGLE PART INSTALLATION POSITION -Sensor
E
Oxygen sensor
F
Camshaft
position
sensor
Engine coolant
temperature sensor
G
Air flow sensor
H
Steering wheel
sensor
I
G sensor
(Lateral)
Parking brake lever
G sensor
(Longitudinal)
J
Air thermo sensor
K
Wheel speed
sensor (front)
L
Oxygen sensor (rear)
M
Wheel speed
sensor (rear)
N
Pressure sensor
Hydraulic unit
B-45

SINGLE PART INSTALLATION POSITION -Solenoid Valve
A
Purge control
solenoid valve
Fuel pressure
solenoid valveB
Secondary air
control solenoid
valve
Alternator
EGR solenoid valve
C
Hydraulic unit
(incorporating
solenoid valve)
D
Air cleaner
Waste gate
solenoid valve
B-46
SOLENOID VALVE
NameSymbolNameSymbol
EGR solenoid valveBHydraulic unit
(incorporatingsolenoidvalve)
E
Fuel pressure solenoid valveA(incorporating solenoid valve)
Hydraulic unit (incorporating solenoid valve)

CPurge control solenoid valveA
Secondary air control solenoid valveB
Waste gate solenoid valveD
ABC
D
E
