2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

HOW TO READ THE WIRING DIAGRAMS -How to Read Configuration DiagramsA-3
HOW TO READ CONFIGURATION DIAGRAMS
The wiring harness diagrams clearly show the connector locations and harness routings at each site
on actual vehicles.
Denotes connector No.
The same connector No. is used throughout the circuit diagrams to facilitate
connector location searches.
The first alphabetical symbol indicates the location site of the connector
and a number that follows is the unique number. Numbers are assigned to
parts in clockwise order on the diagram.
A-43
Example: A-12
Number specific to connector (serial number)
Connector location site symbol
A: Engine compartment
B: Engine and transmission
assembly
C: Dash panel
Denotes earth point.
Same earth number is used throughout circuit
diagrams to facilitate search of earth point. Refer
to SINGLE PART INSTALLATION POSITION -
EARTH MOUNTING LOCATIONS for details of
earth points.
Indicates the device to which the
connector is to be connected.
A-39 (2-B) Headlamp (LO: RH)
A-40 (1) Horn (LO)
A-41 (1) Horn (HI)
A-42 (2-B) Windshield washer motor
The number of connector pins and the
connector colour (except milk white)* are
shown for ease of retrieval.
Example: (2
-B)
Connector colour
(milk white if no colour is indicated)
Number of connector pins
*: Typical connector colours
B: Black
Y: Yellow
L: Blue
G: Green
R: Red
The markLshows the
standard mounting posi-
tion of wiring harness.
R
A-44
A-45
A-42
A-39
Denotes the colour of corrugated
tube or vinyl tube. (If not specified,
it is black.)
R: Red
Y: Yellow
Denotes a section covered by a
corrugated tube.
BR: Brown
V: Violet
O: Orange
GR: Gray
None: Milk whiteD: Floor and roof
E: Door
F: Luggage compartment

HOW TO READ THE WIRING DIAGRAMS -How to Read Circuit DiagramsA-4
HOW TO READ CIRCUIT DIAGRAMS
The circuit of each system from fuse (or fusible link) to earth is shown. The power supply is shown
at the top and the earth at the bottom to facilitate understanding of the current flow.
Indicates the power supply in the control
unit. If no voltage is displayed, this
indicates SYSTEM voltage.
Indicates power take out.
Indicates connector No. The same
No. as in the wiring harness diagram
is used.
Connector numbers enclosed by
frame are indicated with the
connector symbols at the lower part
of the page.
Connector numbers not enclosed by
a frame indicate components which
are integrated with the harness.
Indicates harness junction point No. for
another system. It corresponds to the
junction point No. indicated on the
destination system circuit diagram.
Indicates the circuit name to be
connected. The arrow indicates the
current flow direction.
An “X” at the end of a connector No.
indicates that the connector is connected
to a centralized junction that is shown
in the section “CENTRALIZED JUNC-
TION”.
Indicates the operating condi-
tions of the engine coolant
temperature switch, etc.
Indicates the connector symbol.
Connectors in the circuit diagram are
indicated in numerical order.
Indicates shield wire.
Indicates that terminal is connected via
a plate in the relay box.
Each circuit diagram consists of
block(s). The blocks are divided by
page number.
Indicates that the diagram continues
at
Awhich belongs to the block
in the same circuit.2
Indicate that the current flows
from down to up. Bi-directional
arrows indicate that the
direction of current flow
changes when communication
is in progress.

HOW TO READ THE WIRING DIAGRAMS -How to Read Circuit DiagramsA-5
Indicates input/output to/from
control unit (current flow direction).
Input
OutputInput/
output
In case two or more connectors are
connected to the same device, markings
indicating the same connectors are
connected by a broken line.
Indicates current flow downward or
upward as controlled by the control unit.
Indicates harness junction where wire
diameter or colour changes.
Indicates intersections at
which the lead wire are not
connected.
Indicates intersections at
which the lead wires are
connected.
Indicates representative vehicle body
earth point. (Same No. as that of earth
point in wiring harness diagram and
installation locations of individual parts.)
Indicates that the terminal is a spare
one if the device (sensors in this
case) is not provided.
Indicates terminal No.
Indicates that the diagram comes from
Awhich belongs to the block
in the same circuit.1
A broken line indicates that these
connectors are the same intermedi-
ate connectors.
Indicates a wiring connector which is inside
the equipment and which is not shown in
the wiring harness configuration diagram.
Example C-15-2
Indicates the connector number
shown in the wiring harness
configuration diagram.Indicates a connector
which is inside the
equipment, numbered
in order starting from 1.

HOW TO READ THE WIRING DIAGRAMS -Markings for Connector EarthingA-6
MARKINGS FOR CONNECTOR EARTHING
6
5
3
4
3
8
2
7
1

HOW TO READ THE WIRING DIAGRAMS -Markings for Connector EarthingA-7
ItemNo.Connector/EarthingSymbolContents
Connector
and terminal
marking1Male connectorMale terminalThe male and female terminals are
indicated as shown. The connector
with male terminal(s) is called as
male connector and indicated by
double connector contour linens,
while the connector with female
Male
terminalMale connector
whiletheconnectorwithfemale
terminal(s) is called as female
connector and indicated by single
connector contour line.
-
Female
connec-
tor
Female terminal
Female
terminal
Female connector
Connector
symbol
marking2DeviceThe symbol indicates the vehicle
connector as viewed from the
illustrated direction. At the connec-
tion with a device, the connector
symbol on the device side is
shown, and for an intermediate
connector, a male connector sym-
bolisshownForspareconnectors
Intermediate connector
bolisshown.For spare connectors
and check connectors, no device is
connected, and so the harness-
side connector symbol is shown for
these connectors. The details for
the diagnosis connector differ from
the above description. For details,
refer to the “MUT-II operation
instructions”.
Spare connector, check connector
instructions.

HOW TO READ THE WIRING DIAGRAMS -Markings for Connector EarthingA-8
ItemNo.Connector/EarthingSymbolContents
Connector
connection
marking3Direct connection typeA connection between a device
and connector on the harness side
is either by direct insertion in the
device (direct connection type) or
by connection with a harness
connector on the device side
furnished (harness connection
type)Thetwotypesareindicated
4Harness connection type
type).Thetwotypes areindicated
as illustrated.
5Intermediate connector
Earth
markings6Body earthEarth is either by body earth,
device earth or control unit interior
earth. These are indicated as
illustrated.
7Device earth
8Earth in control unit

HOW TO READ THE WIRING DIAGRAMS -Wire Colour CodesA-9
WIRE COLOUR CODES
Wire colours are identified by the follow colour codes.
CodeWire colourCodeWire colour
BBlackPPink
BRBrownRRed
GGreenSBSky blue
GRGraySISilver
LBlueVViolet
LGLight greenWWhite
OOrangeYYellow
If a cable has two colours, the first of the two colour code
characters indicates the basic colour (colour of the cable
coating) and the second indicates the marking colour.
No.Meaning
1:Flexible wire
:Twisted wire
2Wire size(mm2)*
3Basic colour (colour of the cable coating)
4Marking colour
NOTE
*: No code indicates 0.5 mm2.
Cable colour code in parentheses indicates 0.3 mm2.
1234
Example: 1.25 G - B

HOW TO READ THE WIRING DIAGRAMS -Abbreviation SymbolsA-10
ABBREVIATION SYMBOLS
The abbreviation symbols used in wiring diagrams are defined below.
1. Abbreviation symbols used for system name
Abbreviation
symbolsMeaningAbbreviation
symbolsMeaning
A/CAir conditionerEGRExhaust gas recirculation
ABSAnti-skid braking systemETACSElectronic time alarm control system
ACDActive center differentialSRSSupplemental restraint system
AY CActive yaw control
2. Abbreviation symbols used for combination meters
Abbreviation
symbolsMeaningAbbreviation
symbolsMeaning
ABSAnti-skid braking system warning lampSNOWActive center differential mode indicator
lamp
BEAMHigh beam indicator lampSPEEDSpeedmeter
BRAKEBrake warning lampSRSSupplemental restraint system warning
lamp
CHECK
ENGINECheck engine warning lampTARMACActive center differential mode indicator
lamp
CHGCharging warning lampT/GAEngine coolant temperature gauge
DOORDoor-ajar warning lampTACHOTachometer
F/GAFuel gaugeTAILTail, position and licence plate indicator
lamp
FRONT FOGFront fog indicator lamp
lamp
FUELLow fuel warning lampTRIPTripmeter
GRAVELActive center differential mode indicator
lampTURN (LH)Turn signal indicator lamp (LH)
ODOOdometerTURN (RH)Trun signal indicator lamp (RH)
OILOil pressure warning lampWATER
SPRAY
Intercooler water spray indicator lamp
REAR FOGRear fog indicator lamp
SPRAY
3. Abbreviation symbols used for switched and relay
Name of switches and
relaysAbbreviation
symbolsOperation
Blower switchLOBlower operates at low speed
MLBlower operates at medium low speed
MHBlower operates at medium high speed
HIBlower operates at high speed
