2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

WIRING HARNESS CONFIGURATION DIAGRAMS
D-13
D-27
D-08
D-09
D-10
D-12
D-28 Y
9
10
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-31
D-18 (1) Cigarette lighter
D-19 (1-B) Cigarette lighter
D-20 (2-B) Ashtray illumination lamp
D-21 (2-B) Cigarette lighter illumination lamp
D-22 (4) Oxygen sensor (Rear)
D-23 (1-B) Parking brake switch
D-26 (2-R) Seat belt pretensioner (RH)
D-27 (2) Fuel gauge unit (Sub)
D-28 (2-R) Seat belt pretensioner (LH)D-29 (1) Floor wiring harness (RH) and fuel wiring
harness combination
D-30 (8) Floor wiring harness (RH) and fuel wiring
harness combination
D-32 (3-B) G sensor (Longitudinal)
D-33 (3-B) G sensor (Lateral)
D-34 (6) Intercooler water spray switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
D
D-01D-26D-02D-03D-04D-05D-06
D-34D-15D-33D-32D-30D-29
D-23
D-22
D-21
D-20
D-19
D-18Y
B-32
FLOOR AND ROOF
R.H. drive vehicles
D-01 (3) Door switch (Front: RH)
D-02 (8) Floor wiring harness (RH) and rear door
wiring harness (RH) combination
D-03 (2) Room lamp
D-04 (2-B) Wheel speed sensor (Rear: RH)

D-05 (2-GR) Rear room lamp
D-06 (3) Door switch (Rear: RH)
D-08 (3) Door switch (Rear: LH)D-09 (5-GR) Fuel pump and fuel gauge unit (Main)
D-10 (2-B) Wheel speed sensor (Rear: LH)

D-12 (8) Floor wiring harness (LH) and rear door
wiring harness (LH) combination
D-13 (3) Door switch (Front: LH)
D-15 (4) Instrument panel wiring harness and
console wiring harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
D-27
D-13
D-08
D-09
D-10
D-12
D-28
9
10
Y
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-33
D-18 (1) Cigarette lighter
D-19 (1-B) Cigarette lighter
D-20 (2-B) Ashtray illumination lamp
D-21 (2-B) Cigarette lighter illumination lamp
D-22 (4) Oxygen sensor (Rear)
D-23 (1-B) Parking brake switch
D-26 (2-R) Seat belt pretensioner (RH)
D-27 (2) Fuel gauge unit (Sub)
D-28 (2-R) Seat belt pretensioner (LH)D-29 (1) Floor wiring harness (RH) and fuel wiring
harness combination
D-30 (8) Floor wiring harness (RH) and fuel wiring
harness combination
D-32 (3-B) G sensor (Longitudinal)
D-33 (3-B) G sensor (Lateral)
D-34 (6) Intercooler water spray switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
E
Driver’s side
Front door
Rear door
E-02
E-08E-07E-05E-04
E-12E-11E-10
B-34
DOOR
L.H. drive vehicles
E-02 (3) Remote controlled mirror (LH)
E-04 (2) Spare connector (LH)>
E-05 (6-GR) Power window motor (Front: LH)
E-07 (10) Power window main switchE-08 (6-B) Door lock actuator (Front: LH)
E-10 (6-GR) Power window motor (Rear: LH)
E-11 (8) Power window sub switch (Rear: LH)
E-12 (6-B) Door lock actuator (Rear: LH)
E-13 (3) Remote controlled mirror (RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Passenger’s side
Front door
Rear door
E-13E-16
E-21E-20E-19E-18
E-25E-24E-23
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-35
E-16 (3-B) Door lock key cylinder switch (RH)
E-18 (6-B) Door lock actuator (Front: RH)
E-19 (8) Power window sub switch (Passenger’s
side)
E-20 (6-GR) Power window motor (Front: RH)E-21 (2) Spare connector (RH)>
E-23 (6-B) Door lock actuator (Rear: RH)
E-24 (8) Power window sub switch (Rear: RH)
E-25 (6-GR) Power window motor (Rear: RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
E
Driver’s side
Front door
Rear door
E-07
E-21E-20
E-18
E-13
E-25E-24E-23
B-36
DOOR
R.H. drive vehicles
E-02 (3) Remote controlled mirror (LH)
E-04 (2) Spare connector (LH)>
E-05 (6-GR) Power window motor (Front: LH)
E-07 (10) Power window main switchE-08 (6-B) Door lock actuator (Front: LH)
E-10 (6-GR) Power window motor (Rear: LH)
E-11 (8) Power window sub switch (Rear: LH)
E-12 (6-B) Door lock actuator (Rear: LH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Passenger’s side
Front door
Rear door
E-17E-19E-02
E-08E-05E-04
E-12E-11E-10
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-37
E-13 (3) Remote controlled mirror (RH)
E-17 (3-B) Door lock key cylinder switch (LH)
E-18 (6-B) Door lock actuator (Front: RH)
E-19 (8) Power window sub switch (Passenger’s
side)
E-20 (6-GR) Power window motor (Front: RH)E-21 (2) Spare connector (RH)>
E-23 (6-B) Door lock actuator (Rear: RH)
E-24 (8) Power window sub switch (Rear: RH)
E-25 (6-GR) Power window motor (Rear: RH)

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
F
F-01F-04F-05F-06F-08
F-19
F-16
F-28
F-27F-26F-25F-24F-23F-14
F-21
F-09
F-10
F-12
F-13
F-29
B-38
LUGGAGE COMPARTMENT
L.H. drive vehicles
F-01 (2) Spare connector
F-04 (2) Luggage compartment lamp
F-05 (2-B) High mounted stop lamp
F-06 (1-B) Defogger ( - )
F-08 (2) Spare connector
F-09 (6-B) Rear combination lamp (RH)
F-10 (1-B) Trunk lid latch switch
F-12 (2-GR) Licence plate lamp (RH)
F-13 (2-GR) Licence plate lamp (LH)
F-14 (2-GR) Floor wiring harness (LH) and bumper
wiring harness combinationF-16 (6-B) Rear combination lamp (LH)
F-19 (1) Defogger (+)
F-21 (2) Windshield washer motor
F-23 (2-B) Electric pump
F-24 (8-GR) Floor wiring harness (LH) and 4WD wiring
harness combination
F-25 (2-B) Direction valve (LH)
F-26 (2-B) Direction valve (RH)
F-27 (3-B) Proportioning valve (for ACD control)
F-28 (3-B) Proportioning valve (for AYC control)
F-29 (3-B) Pressure sensor
