2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

EXTERIOR -Windshield Wiper and Washer51-17
INSPECTIONS
WINDSHIELD WIPER MOTOR CHECK
Inspection of windshield wiper motor is conducted by removing
the harness connector with the motor attached to the vehicle.
DOperation inspection of windshield wiper motor
rotation in a low or high speed
Connect the battery to the windshield wiper motor to
inspect the operation of motor rotation in a low or high
speed.
DInspection of windshield wiper motor stop position
(1) Connect the battery to the windshield wiper motor
to rotate the motor in a low speed as shown in the
illustration (A) and disconnect the battery during
rotation to stop the motor.
(2) Connect between the terminals and the battery as
shown in the illustration (B) and confirm whether the
motor stops at the automatic stop position after
rotating in a low speed.
FRONT WASHER MOTOR CHECK
(1) The inspection of front washer motor is conducted with
the washer hose connected after removing the washer
tank assembly and pouring water in the washer tank.
(2) Check that the water is supplied with strong pressure
after energizing terminal number 2 with battery voltage
and earthing terminal number 1.
(B) Automatical stop
Operation inspection
Low speedHigh speed
Stop position inspection
(A) Low speed

EXTERIOR -Windshield Wiper and Washer51-18
WINDSHIELD WASHER NOZZLE INJECTION POSITION
CHECK
Move the nozzle to adjust the position so that the injection
can be done in an area shown in the illustration.
Caution
On R.H. drive vehicles, the illustration is symmetrical.
100 200
50 50
50 50
90 220
35
75
25
85
600 310
180340
170
Windshield washer
nozzle perpendicular
Windshield washer
nozzle perpendicular
Ceramic line terminal
Windshield washer nozzle

Unit:mm

EXTERIOR -Windshield Wiper and Washer51-19
WINDSHIELD WIPER AND WINDSHIELD WASHER
SWITCH AND WINDSHIELD INTERMITTENT WIPER
INTERVAL ADJUSTING KNOB CHECK

(1) Windshield wiper and washer switch, rear wiper and
washer switch.
Switch positionTerminal No.p
6789101167891011
OFF
Windshield wiper mist switch ON
Windshield intermittent wiper switch ON
Windshield low-speed wiper switch ON
Windshield high-speed wiper switch ON
Windshield washer switch ON
(2) Windshield intermittent wiper interval adjusting knob
Measure the resistance value at terminal numbers 3 and
6. The resistance value should rise smoothly from
approximately 0Ω(“FAST” position) to apporoximately
1kΩ(“SLOW” position).
WINDSHIELD INTERMITTENT WIPER INTERVAL
ADJUSTING KNOB CHECK

Measure the resistance value at terminal numbers 4 and
6. The resistance value should rise smoothly from
approximately 0 W (“FAST” position) to approximately 1 kW
(“SLOW” position).
NOTE
The windshield washer switch and windshield wiper switch
is integrated in the column-ECU, so can not be checked as
an individual part. However, its operation can be checked
by the input signal check. (GROUP 54B - Troubleshooting.)

EXTERIOR -Marks51-20
MARKS
REMOVAL AND INSTALLATION
2
3
45
1
1. Three-diamond mark
"
AA2. Three-diamond mark
"
AA3. Evolution - VII mark"
AA4. LANCER mark
"
AA5. RECARO decal
INSTALLATION SERVICE POINT
"AAATTACHMENT OF EACH MARK
1. ATTACHED POSITION

EXTERIOR -Marks51-21
(2) Three - diamond mark, (3) Evolution - VII mark
Press line 73 mm
23 mm
73 mm
134 mm
204 mm
247 mm 8.5 mmPress line
Press line
View A
AB
Vehicle centerline
Press line Press line
Three - diamond
mark 73 mmC C
Section C - C
Vehicle centerline
14 mm
225 mm58 mm
97 mm
151 mm8.5 mm
3.5 mm
Press line
View BVehicle centerline
(4) Lancer mark
20±1mm 30±1mm
Trunk lid terminal

EXTERIOR -Marks51-22
(5) RECARO decal
RECARO decal terminal
52 mm
Stationary window
weather strip terminal 15 mm31 mm
16 mm
RECARO decal terminal
16 mm 19 mm28 mm
52 mm Stationary
window glass
Stationary window
weather strip terminalStationary
window glass
Application tape terminalApplication tape terminal

2. Installation steps
(1) Remove grease on the marked surface of the
body with unlead gasoline.
(2) Peel off the protection sheet on the back of the
mark to paste it on the installation position.
Caution
1) Carry out the operation in a dust-free place where
the room temperature is between 20 and 38.
2) If the room temperature is below 20, heat the mark
and the body (pasted area) between 20 and 30.
3) Be sure to pressure the mark immediately after
the pasting is done.

EXTERIOR -Outside Mirror51-23
OUTSIDE MIRROR
SPECIAL TOOL
ToolNumberNameApplication
MB990784Ornament removerRemoval of power remote control outside
mirror switch
OUTSIDE MIRROR
REMOVAL AND INSTALLATION
123 4
6 7
1
Claw
A
A
Section A - A5
AA
2
7.4±1.4 N·m
Outside mirror removal steps
1. Cover
2. Delta inner cover
3. Outside mirror assembly
4. Outside mirror
A
A"5. MirrorRemote control outside mirror switch
removal steps
6. Instrument panel ornament (Refer to
GROUP 52A - Instrument Panel.)
7. Remote control mirror switch

EXTERIOR -Outside MirrorEXTERIOR -Outside Mirror51-24
REMOVAL SERVICE POINT
AA"MIRROR REMOVAL
Tilt the mirror upward, insert the flat-tipped screw driver
wrapped around with the protection tape between the notch
located behind the mirror and pivot plate, and pry off the
mirror.
INSPECTIONS
REMOTE CONTROLLED MIRROR ASSEMBLY CHECK

Battery connection terminalOperation of mirror
123
Up
Down
Right
Left
THERMAL PRINTED WIRE FUNCTION CHECK
For vehicles with thermal printed wires, check that there is
continuity between terminals (1) and (4).
Section A – A
Notch Flat-tipped
screw driver
Pivot plate
AMirrorFlat-tipped screw driverA
