2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

CIRCUIT DIAGRAMSB-71
MULTI-PURPOSE FUSE (In junction block)
Power supply
circuitNo.Rated
capacity (A)Identification
colourCircuit
Ignition
switch
IG1110RedIgnition coil
switch
27.5BrownColumn switch, combination meter, ETACS-ECU,
SRS-ECU, vehicle speed sensor and ACD mode
changeover switch
37.5BrownETACS-ECU and SRS-ECU
4---
IG257.5BrownA/C compressor relay, A/C-ECU, blower relay,
condenser fan relay, defogger relay, front-ECU,
4WD-ECU, steering wheel sensor and inter cooler
water splay relay
Multi-purpose fuse
No. 20 (Defogger
relay)6---
Ignition
switch
ACC720YellowFront-ECU and windshield wiper motor
switch
IG187.5BrownEngine-ECU and fuel pump relay (1) and fuel pump
relay (2)
ACC915BlueCigarette lighter
10---
117.5BrownA/C-ECU and remote controlled mirror switch
IG2127.5BrownABS-ECU, G-sensor (longitudinal) and G-sensor
(lateral)
ACC13---
14---
Fusible link No. 1
Battery/alternator
1515BlueDiagnosis connector
Battery/alternator
1610RedRear fog lamp relay
1710RedETACS-ECU
18---
1930GreenBlower motor and resistor
2030GreenDefogger

CIRCUIT DIAGRAMSB-72
1 23456
789
10 11 12
13 14 15 16 17 1819
20

CIRCUIT DIAGRAMSB-73
CENTRALIZED RELAY (relay box in engine compartment)
Connector
No.NameConnector
No.Name
A-04XSpare connector (for front fog lamp relay)B-05XEngine speed detection connector
A-05XHorn relayB-06X-
A-06XCondenser fan relay (LO)B-07X-
A-07XCondenser fan relay (HI)B-08X-
A-08X-B-09XIgnition control relay
A-09XRadiator fan relayB-10X-
A-10XFront-ECUB-11XEngine control relay
A-11XFront-ECUB-12XA/C compressor relay
Front of vehicle
Front of
vehicle
A-04X A-05X A-06X A-07X A-08X
A-09XA-10X
A-11X
B-05XB-06X B-07X B-08X B-09X B-10X B-11X B-12X

CIRCUIT DIAGRAMS
H1J01X08AA
B-74
POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS
H1J01X08AB
B-75

CIRCUIT DIAGRAMS
H1J01X08BA
B-76
POWER DISTRIBUTION SYSTEM (CONTINUED)

CIRCUIT DIAGRAMS
H1J01X08BB
B-77

CIRCUIT DIAGRAMS
H1J01X08CA
B-78
POWER DISTRIBUTION SYSTEM (CONTINUED)
