2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

WIRING HARNESS CONFIGURATION DIAGRAMS
JUNCTION BLOCK
(Front view)(Rear view)
Dedicated
fuse
C-208C-209C-210C-226
C-220C-219C-218C-216C-228C-227
C-211
C-213
C-214
C-215
C-225
C-224
C-223
C-222
C-221
B-23
C-214 (5) Defogger relay
C-215 (5) Blower relay
C-216 (15) Floor wiring harness (LH) and J/B
combination
C-218 (3) Roof wiring harness (RH) and J/B
combination
C-219 (4) Rear fog lamp relay
C-220 (4) No connection
C-221 (4) Fuel pump relay 2C-222 (4) Intercooler water spray relay
C-223 (4) Fuel pump relay 1
C-224 (5) Power window relay
C-225 (2) No connection
C-226 (20) ETACS-ECU
C-227 (24) ETACS-ECU
C-228 (24-GR) ETACS-ECU
C-230 (5) Steering wheel sensor

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-01
thru
-46
C
C-46
C-24
C-04C-32C-03C-05C-28C-10
C-14C-16C-44C-43C-35C-41C-21
15
16
17
3
56Y
Y
B-24
DASH PANEL
R.H. drive vehicles
C-01 (21) Combination meter
C-02 (21-L) Combination meter
C-03 (4) Hazard warning switch
C-04 (4) Clock
C-05 (22-GR) J/C (1)
C-08 (22-GR) J/C (3)
C-10 (7) Outside/Inside air selection damper
control motor and potentiometerC-14 (2) Blower motor
C-16 (4) Resistor
C-21 (20-Y) SRS-ECU
C-22 (16-B) Diagnosis connector
C-23 (12) Diagnosis connector
C-24 (16) Instrument panel wiring harness and front
door wiring harness (LH) combination

WIRING HARNESS CONFIGURATION DIAGRAMS
C-22C-23C-34
C-01C-08C-02C-26
C-36
2
7
J/B
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-25
C-26 (22-B) J/C (4)
C-28 (13) J/C (5)
C-32 (12-B) A/C-ECU or heater control unit
C-34 (2) No connection
C-35 (3) Instrument panel wiring harness and
instrument panel wiring harness com-
bination
C-36 (6-GR) Headlamp leveling switchC-41 (22-Y) SRS-ECU
C-43 (22) 4WD-ECU
C-44 (26) 4WD-ECU
C-46 (1-GR) Control wiring harness and floor wiring
harness (LH) combination

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-101
thru
-147
C
C-109C-107C-108C-141C-104C-131
C-136
C-135
C-134
C-133C-132C-115C-118C-122C-126C-130C-129C-128C-147
3
56
1516
17Y
Y
B-26
R.H. drive vehicles
C-101 (1) Spare connector (for front fog lamp
switch)
C-102 (22-L) J/C (2)
C-103 (4) Stop lamp switch
C-104 (14) Spare connector (for radio)
C-107 (7) Instrument panel wiring harness and A/C
wiring harness combination
C-108 (33) J/C (6)
C-109 (2-R) Air bag module (squib) side>
C-110 (20) Instrument panel wiring harness and front
door wiring harness (RH) combinationC-111 (25) Front wiring harness (RH) and instrument
panel wiring harness combination
C-112 (13) Instrument panel wiring harness and floor
wiring harness (RH) combination
C-115 (22-Y) Engine-ECU
C-118 (12-Y) Engine-ECU
C-122 (16-Y) Engine-ECU
C-126 (26-Y) Engine-ECU
C-128 (22-L) Instrument panel wiring harness and
control wiring harness combination
C-129 (10-GR) Instrument panel wiring harness and
control wiring harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
C-101
C-142
C-138
C-137
C-110
C-111
C-146
C-112
C-102C-103
2
7
J/B
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-27
C-130 (25) Instrument panel wiring harness and
control wiring harness combination
C-131 (6) Blower switch
C-132 (3) Front wiring harness (LH) and instrument
panel wiring harness combination
C-133 (13) Instrument panel wiring harness and floor
wiring harness (LH) combination
C-134 (11-GR) Instrument panel wiring harness and floor
wiring harness (LH) combination
C-135 (25) Front wiring harness (LH) and instrument
panel wiring harness combinationC-136 (16) Front wiring harness (LH) and control
wiring harness combination
C-137 (6) Fog lamp switch
C-138 (11-GR) Remote controlled mirror switch
C-141 (1) Roof antenna
C-142 (6) ACD mode changeover switch
C-146 (9-GR) Instrument panel wiring harness and floor
wiring harness (RH) combination
C-147 (11) Instrument panel wiring harness and
control wiring harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
Connector
symbol
-201
thru
-230
CSTEERING COLUMN
C-201
C-207
C-206
C-202C-203C-230C-204C-205 Y
B-28
R.H. drive vehicles
C-201 (6) Ignition switch
C-202 (7) Key reminder switch
C-203 (10) Column switch
C-204 (2-Y) Clock spring
C-205 (4) Clock spring
C-206 (1) Horn switch
C-207 (2) Air bag module (squib)
C-208 (13) Instrument panel wiring harness and J/B
combinationC-209 (14) Instrument panel wiring harness and J/B
combination
C-210 (6) Instrument panel wiring harness and J/B
combination
C-211 (1-B) Instrument panel wiring harness and J/B
combination
C-213 (28) Instrument panel wiring harness and J/B
combination

WIRING HARNESS CONFIGURATION DIAGRAMS
JUNCTION BLOCK
(Front view)(Rear view)
Dedicated fuse
C-226C-208C-209C-210
C-211
C-213
C-214
C-215
C-227C-228C-217C-218C-219C-220
C-222
C-221
C-223
C-224
C-225
B-29
C-214 (5) Defogger relay
C-215 (5) Blower relay
C-217 (15) Floor wiring harness (RH) and J/B
combination
C-218 (3) Roof wiring harness (RH) and J/B
combination
C-219 (4) Rear fog lamp relay
C-220 (4) No connection
C-221 (4) Fuel pump relay 2C-222 (4) Intercooler water spray relay
C-223 (4) Fuel pump relay 1
C-224 (5) Power window relay
C-225 (2) No connection
C-226 (20) ETACS-ECU
C-227 (24) ETACS-ECU
C-228 (24-GR) ETACS-ECU
C-230 (5) Steering wheel sensor

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
D
D-23
D-22
D-21
D-20
D-19
D-18
D-34D-15D-33D-32D-30D-29
D-06D-05D-04D-03D-02D-26D-01
Y
B-30
FLOOR AND ROOF
L.H. drive vehicles
D-01 (3) Door switch (Front: RH)
D-02 (8) Floor wiring harness (RH) and rear door
wiring harness (RH) combination
D-03 (2) Room lamp
D-04 (2-B) Wheel speed sensor (Rear: RH)

D-05 (2-GR) Rear room lamp
D-06 (3) Door switch (Rear: RH)D-08 (3) Door switch (Rear: LH)
D-09 (5-GR) Fuel pump and fuel gauge unit (Main)
D-10 (2-B) Wheel speed sensor (Rear: LH)

D-12 (8) Floor wiring harness (LH) and rear door
wiring harness (LH) combination
D-13 (3) Door switch (Front: LH)
D-15 (4) Instrument panel wiring harness and
console wiring harness combination
