WELDED PANEL REPLACEMENT -Fender ShieldC-5
C
D
B
C
B
E
D
(With the upper frame extension outer removed)

WELDED PANEL REPLACEMENT -Fender ShieldC-6
G
H
I
FE
G
H
17 points, left side only
4 points,
left side only


H
5 points,
left side only

WELDED PANEL REPLACEMENT -Front PillarC-7
FRONT PILLAR
SymbolOperation description
Spot welding
MIG plug welding (J: indicates two panels to be
welded
Y: indicates three panels to be welded)
MIG spot welding
MIG arc welding (continuous)
Braze welding
Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded
joints.)
2point
passenger’s
side
B
C B
C
180±20mm
60±10 mm
A
A
D
D
REPAIR WELDS
Foam acoustic material
(With the upper frame extension outer removed)RS-II
Caution
Do not use heat at areas using foam material as the foam material may burn.

WELDED PANEL REPLACEMENT -Front PillarC-8
NOTE ON REPAIR WORK
REMOVAL
As the front pillar reinforcement lower and side sill outer
reinforcement front are welded at the side sill, cut the side
outer panel at the position shown in the illustration where
the weld points of the reinforcement can be seen, remove,
and then remove the weld points of the front pillar
reinforcement lower.
INSTALLATION
1. To ensure the strength of the cut area of the front pillar,
cut the front pillar inner 100 mm above the cut area,
and the side outer panel 50 mm above the cut area as
shown in the illustration.
Cut the new center pillar at the same positions.
2. Attach the front pillar inner upper assembly of the new
front pillar to the body.
3.When installing a new front pillar outer, install a front
pillar silencer protector filling up the gap with butyl
tapeandthenapplybodysealantand
structural adhesive on the area shown in the illustration.
: Body sealant
: Adhesive
AdhesiveTypeBRAND
Epoxyayresin
adhesive3M DP-460, 3M DP-420 or
equivalent
to RS-II.>
4.After attaching the front pillar outer, seal the holes
and flanges with bolts and plate tape, fill the foam
material through the holes as shown in the illustration.
Foam materialTypeBrand Used
Foam acoustic
materialTwo - part ex-
panded urethane3M ULTRAPRO
Panel foam - Yellow
5. About two hours after filling the foam material, remove the
bolts and plate tape, and solder the sealed holes until a
clip, etc. can be inserted completely.
Weld points
Side sill outer reinforcement
front Front pillar
reinforce-
ment lower
50 mm
100 mm
Side outer panel
Front pillar
inner upper
Front pillar
silencer protector

WELDED PANEL REPLACEMENT -Center PillarC-9
CENTER PILLAR
SymbolOperation description
Spot welding
MIG plug welding (J: indicates two panels to be
welded
Y: indicates three panels to be welded)
MIG spot welding
MIG arc welding (continuous)
Braze welding
Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded
joints.)
125±10mm
290±10mm125±10mm
A
B
CD
D
B
A
C
Foam acoustic material
REPAIR WELDS

Caution
Do not use heat at areas using foam material as the foam material may burn.

WELDED PANEL REPLACEMENT -Center PillarC-10
NOTE ON REPAIR WORK
REMOVAL
1.As the center pillar reinforcement and side sill outer
reinforcement center are welded at the side sill, cut
the side outer panel at the position shown in the
illustration where the weld points of the reinforcement
can be seen, remove, and then remove the weld
points of the center pillar reinforcement.
2. To cut the weld points of the center pillar seatbelt
reinforcement and center pillar reinforcement, cut at the
bottom of the roof side rail inner as shown in the illustration.
NOTE
Keep the separated side roof rail inner (A) for the
future use.
INSTALLATION
1. Remove the side outer panel, side sill outer reinforcement
center, side sill bulkhead, and side sill reinforcement
support from the new center pillar.
2.To ensure the strength of the cut area of the front
pillar, cut the side outer panel 30 mm above the cut
area.
Cut the new center pillar at the same positions.
3. To prevent damage of the center pillar seatbelt
reinforcement, align the new center pillar reinforcement
only to the body side and cut.
Caution
If the center pillar seatbelt reinforcement has been
damaged, repair by welding.
4. When attaching the center pillar reinforcement, apply
adhesive to the locations indicated in the illustration.
: Adhesive
AdhesiveTypeBRAND
Epoxyayresin
adhesive3M DP-460, 3M DP-420
or equivalent
Center pillar
reinforcement
Side sill outer
reinforcement center
Weld pointsWeld
points
(A)
30 mm
Center pillar seatbelt
reinforcement
Center pillar
reinforcement

WELDED PANEL REPLACEMENT -Center PillarC-11
RS-II.>
5. When attaching the center pillar inner, attach the center
pillar silencer protector to the center pillar inner, and seal
the holes of the center pillar silencer protector with butyl
tape.
6. After attaching the center pillar outer, seal the holes and
flanges with bolts and plate tape,fill the foam material
through the holes as shown in the illustration.
Foam materialTypeBrand Used
Foam acoustic
materialTwo - part ex-
panded urethane3M ULTRAPRO
Panel foam - Yellow
7. About two hours after filling the foam material, remove
the bolts and plate tape, and solder the sealed holes
until a clip, etc. can be inserted completely.
Center pillar
silencer
protector

WELDED PANEL REPLACEMENT -Side SillC-12
SIDE SILL
SymbolOperation description
Spot welding
MIG plug welding (J: indicates two panels to be
welded
Y: indicates three panels to be welded)
MIG spot welding
MIG arc welding (continuous)
Braze welding
Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded
joints.)
290mm
A
B
C
DE
ABC
D
F E
70mm
70mm
F
REPAIR WELDS
Foam
acoustic
material

Caution
Do not use heat at areas using foam material as the foam material may burn.
