2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

CHASSIS ELECTRICAL-Rear Combination Lamp
ILL
ILL
54A-33
INSPECTION
REAR FOG LAMP SWITCH CONTINUITY CHECK
Switch positionTerminal No.p
123456
ON
OFF
REAR FOG LAMP RELAY CONTINUITY CHECK
Battery VoltageTerminal No.yg
1423
De-energized
Energized
Rear fog lamp relay

CHASSIS ELECTRICAL-High-Mounted Stop Lamp54A-34
HIGH-MOUNTED STOP LAMP
ON-VEHICLE SERVICE
HIGH-MOUNTED STOP LAMP BULB
REPLACEMENT
Remove socket from trunk compartment, and replace bulb.
Caution
Do not touch bulb surface bare-handed or with dirty
gloves. If dirt is attached on glass surface of the bulb,
immediately use alcohol or thinner to remove dirt, and
install the bulb after well dried.
HIGH-MOUNTED STOP LAMP
REMOVAL AND INSTALLATION
1
5
2
4
3
6
7
8
Removal steps
1. Socket assembly
2. Socket
3. Bulb
4. High-mounted stop lamp assembly5. Socket holder
6. High-mounted stop lamp cover (front)
7. High-mounted stop lamp cover (rear)
8. High-mounted stop lamp body
High-mounted
stop lamp

CHASSIS ELECTRICAL-License Plate Lamp54A-35
LICENSE PLATE LAMP
ON-VEHICLE SERVICE
LICENSE PLATE LAMP REPLACEMENT
Remove socket between rear bumper and body, and remove
bulb.
Caution
Do not touch bulb surface bare-handed or with dirty
gloves. If dirt is attached on glass surface of the bulb,
immediately use alcohol or thinner to remove dirt, and
install the bulb after well dried.
LICENSE PLATE LAMP
REMOVAL AND INSTALLATION
12 3
X0261AU
456
Removal steps
1. License plate lamp lens
2. Packing
3. License plate lamp body
4. Bulb
5. Socket
6. Harness
License plate lamp

CHASSIS ELECTRICAL-Hazard Warning Lamp Switch54A-36
HAZARD WARNING LAMP SWITCH
SPECIAL TOOL
ToolNumberNameUse
MB990784Ornament removerCenter panel assembly removal
HAZARD WARNING LAMP SWITCH
REMOVAL AND INSTALLATION
3
4 2
1
Removal steps
1. Center panel assembly (Refer to
GROUP 52A - Instrument Panel.)
2. Meter bezel (Refer to P.54A-22
.)
3. Center air outlet panel (Refer to
GROUP 52A - Instrument Panel.)
4. Hazard warning lamp switch

CHASSIS ELECTRICAL-Hazard Warning Lamp Switch/Horn/Cigarette Lighter
ILL
ILL
54A-37
INSPECTION
HAZARD WARNING LAMP SWITCH CONTINUITY
CHECK
Switch PositionTerminal No.
1234
OFF
ON
HORN
INSPECTION
HORN RELAY CONTINUITY CHECK
Switch PositionTerminal No.
1432
De-energized
Energized
CIGARETTE LIGHTER
INSPECTION
DRemove plug and check for wear on spot.
DCheck for residual cigarette or foreign object on element.
DWith circuit tester, check for element continuity.

Horn relay
Spot
Element

CHASSIS ELECTRICAL-Column Switch54A-38
COLUMN SWITCH
SPECIAL TOOL
ToolNumberNameUse
MB990784Ornament removerColumn cover removal
COLUMN SWITCH
REMOVAL AND INSTALLATION
2
1
Section A - A
1 34A
A
Pawls
2
A
A
A
A
A
A
Removal steps
1. Lower column cover
2. Upper column cover
3. Lighting switch
4. Wiper/Washer switch

CHASSIS ELECTRICAL-Column Switch54A-39
INSPECTION
LIGHTING SWITCH CONTINUITY CHECK DRIVE>
Switch PositionTerminal No.
3567891011
OFF
Headlamp
Tail lamp
Passing
Dimmer
Turn signal lamp RH
Turn signal lamp LH
NOTE
On L.H. drive vehicles, integrated column ECU does not allow
lighting switch continuity test. For inspection, troubleshooting
in GROUP 54B should be performed.
COLUMN SWITCH CONTINUITY CHECK (AT SWITCH
BODY)
1. Remove lighting switch and wiper/washer switch.
2. Among individual connectors of column switch body
remaining in steering column, check for continuity between
same number terminals (No. 3 - 11).
Terminal No.Connector at lighting switch side
34567891011
Connector at wiper/
hit hid
3p
washer switch side4
5
6
7
8
9
10
11
At lighting
switch sideAt wiper/washer
switch side

CHASSIS ELECTRICAL-Clock54A-40
CLOCK
SPECIAL TOOL
ToolNumberNameUse
MB990784Ornament removerCenter panel assembly and center air outlet
panel removal
CLOCK
REMOVAL AND INSTALLATION
2
3 4
1
Removal steps
1. Center panel assembly (Refer to
GROUP 52A - Instrument Panel.)
2. Meter bezel (Refer to P.54A-22.)3. Center air outlet panel (Refer to
GROUP 52A - Instrument Panel.)
4. Clock
