2007 MITSUBISHI LANCER EVOLUTION Service Repair Manual

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-13
A-43
A-39
A-44
A-21A-23A-16
14
B-7
A-21 (3-GR) Fan controller
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-43 (8-B) Front wiring harness (LH) and control
wiring harness combination
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
A
A-01
A-37
A-36
A-34
A-48
A-40
A-31
A-28
A-47A-46A-45
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
1
B-8
ENGINE COMPARTMENT
R.H. drive vehicles
A-01 (2-GR) Side turn signal lamp (RH)
A-02 (2-GR) Side turn signal lamp (LH)
A-03 (2-B) Wheel speed sensor (Front: LH)
A-04X (4) Spare connector (for front fog lamp relay)
A-05X (4) Horn relay
A-06X (4) Condenser fan relay (LO)
A-07X (4) Condenser fan relay (HI)
A-08X (4) No connectionA-09X (4) Radiator fan relay
A-10X (11) Front-ECU
A-11X (11) Front-ECU
A-12 (2-B) Front wiring harness (LH) and control
wiring harness combination
A-16 (2-B) Headlamp (HI: LH)
A-21 (3-GR) Fan controller

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-39
A-44
A-16
A-21A-23
14
B-9
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-34 (2) No connection
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-01
thru
-37
B
B-37
B-34
B-23
B-01B-27B-26
Earth cable
B-21B-22
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-10
ENGINE AND TRANSMISSION
L.H. drive vehicles
B-01 (5-GR) Windshield wiper motor
B-02 (4-B) Throttle position sensor
B-03 (3-B) Vehicle speed sensor
B-04 (2-GR) Brake fluid level switch
B-05X (1) Engine speed detection connector
B-06X (5) No connection
B-07X (4) No connectionB-08X (4) No connection
B-09X (4) No connection
B-10X (4) No connection
B-11X (4) Engine control relay
B-12X (4) A/C compressor relay
B-14 (10-B) Control wiring harness and battery wiring
harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
B-25
B-18
B-24B-02B-04
B-05X
B-06X
B-07X
B-08X
B-09X
B-10X
B-11X
B-12X
B-14
B-03
B-36
B-19B-20B-31
4
11
12
B-11
B-18 (1) Starter
B-19 (1-B) Starter
B-20 (1-B) Oil pressure switch
B-21 (1) Alternator
B-22 (4-GR) Alternator
B-23 (2-B) Purge control solenoid valve
B-24 (2-B) Injector 4B-25 (2-B) Injector 3
B-26 (2-B) Injector 2
B-27 (2-B) Injector 1
B-31 (7-B) Air flow sensor
B-34 (4-B) Oxygen sensor
B-36 (2-GR) Waste gate solenoid valve
B-37 (2-B) Fuel pressure solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-108
thru
-142
BEarth cable
B-123B-138B-139B-140B-141
B-119
B-121
B-122B-112B-142
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-12
L.H. drive vehicles
B-108 (2-B) Back-up lamp switch
B-110 (1-B) Engine coolant temperature gauge unit
B-112 (2-BR) EGR solenoid valve
B-114 (3-GR) Ignition coil 1B-115 (6-B) Idle speed control servo
B-116 (3-B) Camshaft position sensor
B-118 (2-B) Engine coolant temperature sensor
B-119 (3-GR) Ignition coil 2

WIRING HARNESS CONFIGURATION DIAGRAMS
B-115
B-114
B-118
B-108
B-116B-110
4
11
12
B-13
B-121 (3-B) Crank angle sensor
B-122 (2-GR) Detonation sensor
B-123 (34-B) ABS-ECU
B-138 (6-B) ResistorB-139 (5-B) Electric pump relay
B-140 (4) Fuel pump relay 3
B-141 (2-B) Fuel pump resistor
B-142 (2-B) Secondary air control solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-01
thru
-37
B
Earth cable
B-27B-26B-04
B-22B-21
B-37
B-34
B-23
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-14
ENGINE AND TRANSMISSION
R.H. drive vehicles
B-01 (5-GR) Windshield wiper motor
B-02 (4-B) Throttle position sensor
B-03 (3-B) Vehicle speed sensor
B-04 (2-GR) Brake fluid level switch
B-05X (1) Engine speed detection connector
B-06X (5) No connection
B-07X (4) No connectionB-08X (4) No connection
B-09X (4) Ignition coil relay
B-10X (4) No connection
B-11X (4) Engine control relay
B-12X (4) A/C compressor relay
B-14 (10-B) Control wiring harness and battery wiring
harness combination
