FRONT AXLE -Drive Shaft26-17
10. Fill the inside of the B.J. boot with the specified amount
of the specified grease.
Specified grease: Repair kit grease
Amount to use: 110±10 g
Caution
The drive shaft joint uses special grease. Do not mix
old and new or different types of grease.
11. Install the groove in the center of the large diameter part of
the resin boot by fitting to the groove of the shaft.
12. Follow the same procedure as in step 5 to adjust the
size of the opening (W) on the special tool so that it
is at the standard value.
Standard value (W): 3.2 mm
13. Install the boot band(large) in order to create clearance
as D and E in the illustration.
14. Use the special tool to crimp the B.J. boot band (large)
in the same way as in step 7.
15. Check that the crimping amount (F) of the B.J. boot band
is at the standard value.
Standard value (F): 2.4 - 2.8 mm

Readjust the value of (W) in step 12 according
to the following formula, and then repeat the
operation in step 14.
W = 5.8 mm - F
Example: If F = 2.9 mm, then W = 2.9 mm.

Remove the B.J. boot band, readjust the value
of (W) in step 12 according to the following
formula, and then repeat the operations in
steps 13 and 14 using a new B.J. boot band.
W = 5.8 mm - F
Example: If F = 2.3 mm, then W = 3.5 mm.
16. Check that the B.J. boot band is not sticking out past
the place where it has been installed.
If the B.J. boot band is sticking out, remove it and then
repeat the operations in steps 13 to 15 using a new
B.J. boot band.
B.J. boot
Projection
B.J. boot band
(large)
D
E
F

NOTES

27B-1
REAR AXLE
CONTENTS
GENERAL INFORMATION 2...................
SERVICE SPECIFICATIONS 3.................
LUBRICANTS 3..............................
SEALANTS 4................................
SPECIAL TOOLS 4...........................
TROUBLESHOOTING (AYC) 8.................
ON-VEHICLE SERVICE 16....................
Rear Axle Total Backlash Check 16...............
Gear Oil Level Check 16........................
Gear Oil Change 17............................
Fluid Level Check 19............................
Bleeding 19....................................
AYC Operation Check 20........................
Oil Pressure Check 21..........................Wheel Bearing Axial Play Check 22...............
Wheel Bearing Rotary-sliding Resistance Check 22.
Hub Bolt Replacement 23.......................
Differential Carrier Oil Seal Replacement 23........
Action When Battery Runs Out 24................
REAR HUB ASSEMBLY 25....................
KNUCKLE 28................................
DRIVE SHAFT 29.............................
DIFFERENTIAL CARRIER
35......
DIFFERENTIAL CARRIER
55...................
HYDRAULIC UNIT
61..............

REAR AXLE -General Information27B-2
GENERAL INFORMATION
The rear axle consists of rear hubs, wheel bearings,
drive shafts, and rear differential and, it has the
following features.
DThe wheel bearing is a unit bearing (double-row
angular contact ball bearing).
DThe drive shaft incorporates B.J.-T.J. type
constant velocity joints with high transmission
efficiency and low vibration and noise.DABS rotors for detecting the wheel speeds are
press-fitted to the B.J. outer wheels in vehicles
with ABS or ACD.
NOTE
1. B.J.: Birfield Joint
2. T.J.: Tripod Joint
SPECIFICATIONS
ItemVehicles without AYCVehicles with AYC
Wheel
bearingsWheel bearing typeUnit bearing (Double-row angular contact ball
bearing)
g
Bearing (outside diameter×inside diameter) mm78×40
Drive
shaft
Joint typeOutsideB.J.
shaftInsideT.J.
Shaft length*1×Shaft diameter
mm
Left483×25426×25
mmRight573×25446×25
NOTE
*1: The shaft length indicates the length between the center points of each joint.
STRUCTURAL DIAGRAM
Oil sealRear hub Differential carrier
B.J.
Drive shaftT. J .

REAR AXLE -Service Specifications/Lubricants27B-3
SERVICE SPECIFICATIONS
ItemStandard valueLimit
Rear axle total backlash mm-6
Wheel bearing rotation starting torque N·m-1.0
Wheel bearing axial play mm-0.05 or less
Wheel bearing rotary-sliding resistance N-22 or less
TJ boot assembly dimension mm90±3-
Drive gear backlash mm0.11 – 0.16-
Drive gear runout mm-0.05
Drive pinion turning
torqueN·m
Without oil seal0.88 – 1.17-
torqueN·m
With oil sealCompanion flange (oil seal contact-
ing area) with anti-rust agent0.98 – 1.27-
Companion flange (oil seal contact-
ing area) with gear oil applied0.49 – 0.58-
Vehicles with mechani-
cal LSDRight-to-left difference in combined thickness of friction
plate and friction disc
mm
0 – 0.05-
Clearance between spring plate and differential case
mm
0.06 – 0.25-
LSDdifferential
torqueN·m
When new clutch plate is installed5–19-
torqueN·m
When existing clutch plate is
installed2–19-
Distortion of friction plate and friction discmm-0.08
Difference in thickness between friction plate, friction
disc, and spring plate
mm
-0.1
Vehicles with ACD and
AY CPressure generated by hydraulic unit (pressure sensor
value
)MPa
0.9 – 1.1-
LUBRICANTS
ItemSpecified lubricantsQuantity
Vehicles with
mechanical
S
Gear oilHypoid gear oil
MITSUBISHI Genuine Gear Oil Part No. 81496300.55L
LSDMITSUBISHIGenuineGearOilPartNo.8149630
EX, CASTROL HYPOY LS (GL-5, SAE 90),
SHELL-LSD (GL-5, SAE 80W - 90) or equivalent
Vehicles with
ACD and
AY CGear oilDifferentialHypoid gear oil
API classification GL-5 or higher SAE viscosity
No.90, 80W0.55±0.02L
Torque transfer
mechanismATF-SP™0.65 - 0.7L

REAR AXLE -Lubricants/Sealants/Special tools27B-4
ItemQuantity Specified lubricants
Vehicles with
ACDand
Hydraulic piping fluidATF-SP™1L
ACDand
AY CTorque transfer mechanism oil
seal lipsVaselineAs required
B.J. jointRepair kit grease85±10 g
T.J. jointRepair kit grease105±10 g
SEALANTS
ItemsSpecified sealantsRemarks
Vehicles with me-
chanicalLSD
Vent plug3M ATD Part No. 8661, 8663 or
equivalent
Semi-drying sealant
chanicalLSD
Differential cover assembly
equivalent
Vehicles with ACD
andAYC
Vent plug
andAYC
Differential carrier cover
mounting part
Vehicles with me-
chanical LSDDrive gear and differential
case mounting part3M Stud Locking 4170 or equivalentAnaerobic sealant
SPECIAL TOOLS
ToolNumberNameUse
MB991502MUT-IIsub as-
semblyInspection of AYC (diagnosis display by
MUT-II)
MB991529Diagnosis code
check harnessInspection of AYC
(diagnosis display by ACD mode indicator
lamp)
MD998330
(MD998331)Oil pressure gaugeHydraulic pressure measurement with AYC>
MB991705Hose adapter
MB990925Bearing and oil
seal installer setRemoval of wheel bearing

REAR AXLE -Special Tools27B-5
Tool UseName Number
MB991115Oil seal installerPress-fitting of oil seal
(AYC differential: used in combination with
MB990938)
MD998812Installer capPress-fitting of oil seal
(torque transfer mechanism of vehicles with
AYC)
MD998813Installer100
MD998829Installer adapter
(60)
MB990767Front hub and
flange yoke holderRemoval, installation of the drive shaft nut
A
B
MB990241
A: MB990242
B: MB990244Rear axle shaft
puller
A:Puller shaft
B:Puller barDRemoval of drive shaft
DRemoval of rear hub assembly
MB991354Puller body
A
CB
00005697
A: MB991017
B: MB990998
C: MB991000A,B: Front hub re-
mover and in-
staller
C: SpacerDTemporary fixing of wheel bearing
DMeasurement of wheel bearing rotation
starting torque
DMeasurement of wheel bearing axial play
Use MB991000 (component of MB990998)
for the spacer.

REAR AXLE -Special Tools27B-6
ToolNumberNameUse
MB990685Torque wrenchMeasurement of the starting torque of wheel
bearing
MB990326Preload socket
MB991113 or
MB990635Steering linkage
pullerDisconnection of ball joint
MB990641Lower arm bush
(A) remover & in-
stallerRemoval and press-fitting of differential
support member bush
MB991439Bush remover &
installerRemoval and press-fitting of differential
support arm bush
MB991460PlugPrevention of differential oil from being
discharged and entry of foreign matter differential>
MB990909Working baseSupporting of the differential carrier
MB991116AdapterSupport of differential carrier assembly
MB990810Side bearing pullerDRemoval of the side bearing inner race
DRemoval of the companion flange
