EXTERIOR -Side Air Dam, Molding and Garnish51-9
SIDE AIR DAM, MOLDING AND GARNISH
REMOVAL AND INSTALLATION
11
ClipClip
Clip
1
Section A – A
Section B – B
Section C – C
Section F – F
Clip2,3
1
Clip
Section D – D
1
2
3 1
Clip
Section E – E
NOTE: Refer to P.51-14 for more information regarding removal and
installation of front deck garnish.
F F
A AB BC CD
D
EE
F
F B
B
B BA
A




Double-sided tape: Generic products: 5mm width, 1.2mm thickness3
AA"1. Roof drip molding
2. Delta outer garnishAB""AA3. Side air dam

EXTERIOR -Side Air Dam, Molding and Garnish51-10
REMOVAL SERVICE POINTS
AA"ROOF DRIP MOLDING REMOVAL
Use the special tool to pry the molding from the rear of the
body for removal.
Caution
Do not use the deformed mold again.
AB"SIDE AIR DAM REMOVAL
1. Attach protection tape all the way along the edges of
the double-sided tape which is still adhering to the body.
2. Use a resin spatula to scrape off the double-sided tape.
3. Peel off the protection tape.
4. Wipe the body surface and clean it with a rag moistened
with isopropyl alcohol.
INSTALLATION SERVICE POINTS
"AASIDE AIR DAM INSTALLATION
Double-sided tape affixing to the side air dam (when
reusing)
1. Scrape off the double-sided tape with a resin spatula
or gasket scraper.
2. Wipe off the side air dam adhesion surface and clean
it with a shop towel moistened with isopropyl alcohol.
3. Affix the specified double sided tape to the side air dam.
(Refer to P.51-9.)
MB990449
Protection tape
Double-sided tape

EXTERIOR -Side Air Dam, Molding and Garnish51-11
4. Remove strip paper from the pressure sensitive
double-sided tape.
NOTE
Affix double-sided tape to the end of strip paper for ease
of strip paper removal. (Refer to P.51-9.)
5. Install the side air dam.
NOTE
If it is hard to affix the double-sided tape in winter, heat
the application surfaces at both the vehicle body and
the side air dam.
Body 40 - 60_C
Side air dam 20 - 30_C
Apply pressure fully to the side air dam.
Adhesive tape Backing paper

EXTERIOR -Rear Spoiler51-12
REAR SPOILER
ADHESIVE
ApplicationBrand
Rear spoilerDouble-sided tape [15 mm width 1.2 mm thickness, 30 mm width 1.2 mm
thickness]
REAR SPOILER
REMOVAL AND INSTALLATION
1
12
3
2
5.2±0.2 N·m
5.2±0.2 N·m5.2±0.2 N·m
5.2±0.2 N·m
A A
B
B
Steel plate hook
2
Claw
2
3
3 3
Double-sided tape:
Generic products: A : 15mm width, 1.2mm thickness,
B : 30mm width, 1.2mm thickness Section A – A
Section B – BA
B
Removal steps
DTrunk lid bumper
(Refer to Group 42.)
1. Gasket
2. Cap
A
A""
AA3. Rear spoilerNOTE:
The removal and installation service points are the
same as SIDE AIR DAM , MOLDING AND GARNISH.
(Refer to P.51-10)

EXTERIOR -Windshield Wiper and Washer51-13
WINDSHIELD WIPER AND WASHER
SERVICE SPECIFICATIONS
ItemStandard value
Stopposition of the windshield wiper arm/blade assembly(distance between the edgeof34±5Stoppositionofthewindshieldwiperarm/bladeassembly(distancebetweentheedgeof
the wiper blade and the end of the deck garnish) mm
34±5
TROUBLESHOOTING
The windshield wiper-washer is controlled by the smart wiring system (SWS). Refer to Group 54B for
troubleshooting.
NOTE
If ETACS-ECU is faulty, the windshield wiper can be operable in LO mode only as the fail - safe function.
(Normally the windshield wiper is operable when the ignition switch is turned to the ACC position. When
the fail - safe function is enabled, it is operable only when the ignition switch is turned to the ON position.)
ON-VEHICLE SERVICE
WINDSHIELD INTERMITTENT WIPER
INSPECTIONS
(1) Check the change in the intermittent time of the wiper
operation by using the windshield intermittent wiper
volume.
(2) Carry out troubleshooting if any of them is faulty.
(Refer to Group 54B.)

EXTERIOR -Windshield Wiper and Washer51-14
WINDSHIELD WIPER AND WASHER
REMOVAL AND INSTALLATION
NOTE
indicates the clip A location. indicates the clip B location.
Section A - A
Section B - B View A
3,4
Clip A
13±2NSmA
5 4
8.9±1.9 NSm
1
3
Clip B
3, 4
7.4±1.4 NSm
6 43
A
AB B
2
Windshield wiper motor assembly
and link assembly removal steps
"AA1. Wiper arm/blade assembly
2. Hood weather strip
3. Front deck garnish (driver’s side)4. Front deck garnish (passenger’s side)
AA"5. Windshield wiper motor assembly
6. Link assembly

EXTERIOR -Windshield Wiper and Washer51-15
5.0±1.0 NSm
4
1 3
2
NOTE: Refer to P.51-19 for more information regarding removal and installation of rear washer nozzle.
5
Washer hose removal steps
DSplash shild (Refer to
GROUP 42 – Fender.)
DCowl side trim, front scuff plate, center
pillar trim, lower, rear scuff plate (Refer
to GROUP 52A – Trim.)
DRear seat (Refer to GROUP
52A – Seat.)
1. Washer hose
Windshield washer nozzle removal
steps
DConnection of washer hose
2. Windshield washer nozzleWasher tank and windshield washer
motor assembly removal steps
DRear end trim, trunk side trim (Refer
to GROUP 52A – Trim.)
DConnection of front washer hose
3. Washer tank assembly
4. Washer tank bracket
5. Washer motor
NOTE: Refer to GROUP 54A– Column Switch for
removal and installation of wiper washer switch.

EXTERIOR -Windshield Wiper and Washer51-16
REMOVAL SERVICE POINT
AA"WINDSHIELD WIPER MOTOR ASSEMBLY
REMOVAL
1. Remove the windshield wiper motor assembly mounting
bolt.
2. Use the flat-tipped screw driver to disengage the link
between the windshield wiper motor assembly and the
link assembly to remove the windshield wiper motor
assembly.
Caution
Be careful not to damage the windshield glass when
the windshield wiper motor assembly is removed.
INSTALLATION SERVICE POINT
"AAWIPER ARM/BLADE ASSEMBLY INSTALLATION
Assemble the parts so that the edge of the wiper blade can
stop in the specified position (standard value).
Standard value:(A) 34±5mm
Windshield wiper
motor assembly
Flat-tipped screw driver
Link assembly
connection
Front deck garnish terminal
