BODY CONSTRUCTION -Body ComponentsA-3
1. Headlamp support panel
2. Hood lock stay
3. Front end crossmember
4. Front end upper bar
5. Headlamp support panel side
6. Front fender shield
7. Front upper frame inner
8. Upper frame bulkhead front
9. Upper frame bulkhead
10. Upper frame bulkhead rear
11. Front sidemember inner
12. Engine mount bracket
13. Front sidemember rear
14. Front sidemember outer
15. Spring house panel
16. Dash panel
17. Dash panel silencer
18. Dash panel reinforcement
19. Upper frame to front pillar brace
20. Upper frame extension outer
21. Upper frame extension inner
22. Cowl top lower panel
23. Cowl top inner panel
24. Cowl top upper panel
25. Front deck crossmember
26. Hood inner panel
27. Hood outer panel
28. Front roof rail
29. Front roof bow
30. Roof panel
31. Rear roof bow
32. Rear roof rail
33. Seat back plate
34. Rear seat back panel
35. Rear shelf panel
36. Rear seat back brace
37. Trunk lid outer panel
38. Trunk lid inner panel
39. Trunk lid hinge
40. Quarter inner extension rear
41. Quarter corner panel42. Rear combination lamp housing
43. Side roof rail inner
44. Front pillar inner upper
45. Front pillar inner lower
46. Center pillar inner
47. Side outer panel
48. Rear wheel house inner panel
49. Quarter inner panel
50. Rear floor side brace
51. Quarter outer extension lower
52. Fuel filler door
53. Rear license plate bracket
54. Rear end panel outer
55. Rear end panel inner
56. Rear door outer panel
57. Rear door side door beam
58. Rear door inner panel
59. Front door outer panel
60. Front door side door beam
61. Front door inner panel
62. Fender panel
63. Front floor crossmember rear
64. Front floor crossmember front
65. Front floor side sill inner
66. Front floor sidemember
67. Backbone reinforcement
68. Installment panel center bracket reinforcement
69. Front floor pan
70. Front floor extension panel rear
71. Rear floor extension
72. Rear floor pan
73. Seat back plate extension
74. Jack bracket
75. Spare tire bracket
76. Towing hook reinforcement
77. Rear floor sidemember extension
78. Crossmember center support
79. Rear floor crossmember
80. Rear floor sidemember
81. Rear seat back reinforcement

BODY CONSTRUCTION -Body Construction CharacteristicsBODY CONSTRUCTION -Body Construction CharacteristicsA-12
Front Deck
Strut house gussetandupper frame to front pillar brace have been added to improve body rigidity.
7
1 24 56
8
9
310
11
12 13
14
15
16
1. Strut tower bar bracket
2. Cowl top lower panel
3. Cowl top upper bracket center
4. Cowl top upper reinforcement center
5. Cowl top upper bracket side (LHD)
6. Cowl top inner panel
7. Cowl top upper panel
8. Pedal support bracket9. Clutch pedal support bracket
10. A/C Unit bracket (RHD)
11. Upper frame extension outer
12. Upper frame to front pillar brace
13. Cowl top upper reinforcement
14. Cowl top lower bracket
15. Upper frame extension inner
16. Strut house gusset
Dash Panel
1. A dash panel crossmember has been added and the thickness of the dash panel lower has been
increased to improve collision stability.
2. A silencer (steel sheet binding type vibration damping material) has been added between the dash
panel and dash panel silencer to control the penetrating sound and vibration from the engine.
18 3
76 5 4
2
1. Dash panel crossmember
2. Dash panel
3. Dash silencer center
4. Dash panel silencer5. Accel pedal reinforcement (LHD)
6. Dash panel reinforcement
7. Dash lower reinforcement (LHD)
8. Dash panel lower

ENGINE -Cylinder Head Gasket11A-28
CYLINDER HEAD GASKET
REMOVAL AND INSTALLATION
Caution
If the vehicle is equipped with the Brembo disc brake, during maintenance, take care not to contact
the parts or tools to the caliper because the paint of caliper will be scratched.
Pre-removal and Post-installation Operation
DFuel Outflow Preventive Operation (Refer to GROUP 13A - On-vehicle Service.)
DFuel Leak Check
DStrut Tower Bar Removal and Installation (Refer to GROUP 42.)
DUnder Cover Removal and Installation (Refer to GROUP 51 - Front Bumper.)
DDrive Belt Tension Check (Refer to P.11A-7.)
DAccelerator Cable Adjustment (Refer to GROUP 17 - On-vehicle Service.)
DDrainage and Refilling Engine Oil (Refer to GROUP 12 - On-vehicle Service.)
DDrainage and Refilling of Engine Coolant (Refer to GROUP 14 - On-vehicle Service.)
DAir Cleaner Assembly Removal and Installation (Refer to GROUP 15.)
DAir Hose E, Air Pipe C, Air hose D Removal and Installation (Refer to GROUP 15 - Intercooler.)
DBattery Removal and Installation
DCenter Cover Removal and Installation (Refer to P.11A-17.)
DAccelerator Cable Removal and Installation (Refer to GROUP 17.)
DRadiator Removal and Installation (Refer to GROUP 14.)
DSecondary Air Control Valve Bracket Removal and Installation (Refer to GROUP 15 - Secondary Air Supply System.)
DCrossmember Bar Removal and Installation (Refer to GROUP32 - Engine Roll Stopper, Centermember.)
DFront Exhaust Pipe Removal and Installation (Refer to GROUP 15.)
DStarter Removal and Installation (Refer to GROUP 16.)
DTiming Belt Removal and Installation (Refer to P.11A-34.)

ENGINE -Engine Assembly11A-43
ENGINE ASSEMBLY
REMOVAL AND INSTALLATION
Caution
1. If the vehicle is equipped with the Brembo disc brake, during maintenance, take care not to
contact the parts or tools to the caliper because the paint of caliper will be scratched.
2. Tightening sections indicated in the mark (*) should be finally tightened with engine weight
applied on the body after lightly tightening.
Pre-removal and Post-installation Operation
DFuel Outflow Preventive Operation (Refer to GROUP 13A - On-vehicle Service.)
DFuel Leak Check
DRemoval and Installation of Hood (Refer to GROUP 42.)
DRemoval and Installation of Strut Tower Bar (Refer to GROUP 42.)
DRemoval and Installation of Under Cover (Refer to GROUP 51 - Front Bumper.)
DRemoval and Installation of Side Cover.
DDrive Belt Tension Check (Refer to P.11A - 7.)
DAccelerator Cable Adjustment (Refer to GROUP 17 - On-vehicle Service.)
DDrainage and Refilling Engine Oil(Refer to GROUP 12 - On-vehicle Service.)
DDrainage and Refilling of Engine Coolant (Refer to GROUP 14 - On-vehicle Service.)
DAir Cleaner Removal and Installation (Refer to GROUP 15)
DRemoval and Installation of Air Pipe C, Air Pipe B and Air Hose A (Refer to GROUP 15 - Intercooler.)
DBattery and Battery Tray Removal and Installation
DRemoval and Installation of Center Cover (Refer to P.11A - 17.)
DRemoval and Installation of Accelerator Cable (Refer to GROUP 17.)
DRemoval and Installation of Radiator (Refer to GROUP 14.)
DRemoval and Installation of Crossmember Bar (Refer to GROUP 32 - Engine Roll Stopper, Centermember.)
DRemoval and Installation of Front Exhaust Pipe (Refer to GROUP 15.)
DRemoval and Installation of Air Outlet Fitting (Refer to GROUP 15 - Exhaust manifold.)

MPI -Injector13A-141
INJECTOR
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DFuel Discharge Prevention (Refer to P.13A-125.)
DStrut Tower Bar Removal and Installation
(Refer to GROUP 42.)DAir Hose E, Air By-pass Hose, Air Pipe C Removal
and Installation (Refer to GROUP 15 - Intercooler.)
DFuel Leakage Check
21
3
13 5
6
7
8 9 1011 12
4
8.9±1.9N·m
8.9±1.9N·m 5.0±1.0N·m
Apply engine oil to all
moving parts during
installation.
14 15
16 12
6
5.0±1.0N·m
Removal steps
1. Control harness connector
2. Accelerator cable assembly
connection (Throttle body side)
3. Injector harness connector
"AA4. High-pressure fuel hose connection
5. O-ring
6. Fuel return hose connection
7. Vacuum sensor connector
"AA8. Fuel pressure regulator9. O-ring
10. Fuel return pipe
AA"11. Delivery pipe
12. Insulator
13. Insulator
AA""AA14. Injector
15. Grommet
16. O-ring

MPI -Throttle Body13A-143
THROTTLE BODY
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DUnder Cover Removal and Installation
(Refer to GROUP 51 - Front Bumper.)
DEngine Coolant Draining and Supplying
(Refer to GROUP 14 - On-vehicle Service.)
DStrut Tower Bar Removal and Installation
(Refer to GROUP 42.)DAir Hose E, Air By-pass Hose, Air Pipe C Removal
and Installation (Refer to GROUP 15 - Intercooler.)
DAccelerator Cable Adjustment (Refer to GROUP 17
- On-vehicle Service.)
2
19¶3 N·m5.0¶1.0 N·m
1
34
5 6
7
5
Removal steps
1. Accelerator cable connection
2. Throttle position sensor connector
3. Idle speed control servo connector
4. Vacuum hose connection5. Water hose connection
6. Throttle body
"AA7. Throttle body gasket
INSTALLATION SERVICE POINT
"AATHROTTLE BODY GASKET INSTALLATION
Place the gasket so that the projecting part is positioned
as shown in the illustration, and then install it between the
intake manifold and the throttle body.
Up
Towards front of vehicle

MPI -Engine Control Resistor, Relay13A-146
ENGINE CONTROL RESISTOR, RELAY
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DStrut Tower Bar Removal and Installation (Refer to GROUP 42.)
DHarness Connector Connection
213
4
5.0¶1.0 N·m
5.0±1.0N·m5.0±1.0N·m
2.5±0.5N·m
5.0±1.0N·m
AYC relay
4 2
5.0±1.0N·m
5.0±1.0N·mAYC relay5.0±1.0N·m5.0±1.0N·m
2.5±0.5N·m13


Removal steps
DAYC relay
1. Fuel pump relay
2. Injector resistor
3. Bracket
4. Fuel pump resistor

INTAKE AND EXHAUST -Secondary Air Supply System15-14
SECONDARY AIR SUPPLY SYSTEM
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DAir Duct Removal and Installation (Refer to P.15-8.)
DStrut Tower Bar Removal and Installation (Refer to GROUP 42.)
1
2 34
5
49±5 N·m14±1 N·m 22±4 N·m
14±1 N·m 14±1 N·m 20±2 N·m
6
8 9 10
22±4 N·m24±3 N·m23±4 N·m
11±1 N·m Air pipe C 5.9±1.0 N·m
7
7 11
Removal steps
1. Control harness connector
connection
2. Heat protector
3. Vacuum hose connection
DAir pipe C (Refer to P.15-9.)
4. Vacuum pipe
5. Secondary air hose6. Secondary air pipe assembly
"AA7. Gasket
"BA8. Gasket
9. Secondary air control valve
10. Engine hanger
11. Secondary air control valve bracket
