2023 HYUNDAI PALISADE Owners Manual

04
4-33
B0802EU01
Drive info
Trip distance M, t
otal driving time N and
average fuel economy O are displayed.
The information is combined for each
ignition cycle. However, when the engine
has been OFF for 3 minutes or longer the
Drive Info screen will reset.
To reset manually, press the OK switch
on the steering wheel for more than 1
second when ‘Drive Info’ is displayed.
B0802EU02
Since refueling
Trip distance M, t
otal driving time N and
average fuel economy O after the vehicle
has been refueled are displayed.
To reset manually, press the OK switch
on the steering wheel for more than
1 second when ‘Since Refueling’ is
displayed.
B0802EU03
Accumulated info
Accumulated trip distance M, t
otal
driving time N and average fuel
economy O are displayed.
The information is accumulated starting
from the last reset.
To reset manually, press the OK switch
on the steering wheel for more than
1 second when ‘Accumulated Info’ is
displayed.
B0802EU04
Auto stop (if equipped)
AUTO STOP display shows the elapsed
time o
f engine stop by Idle Stop and Go
system.
For more details, refer to “Idle Stop and
Go (ISG)” section in chapter 6.

Instrument Cluster4-34
Trip Computer (Type B)
The trip computer is a microcomputer-
controlled driver information system that
displays information related to driving.
Information
Some driving information stored in the
trip computer (for example, Average
Vehicle Speed) resets if the battery is
disconnected.
Trip modes
Drive Info

[ Trip distance

[ Total driving time

[ Average fuel economy

Since refueling

[ Trip distance

[ Total driving time

[ Average fuel economy

Accumulated Info

[ Trip distance

[ Total driving time

[ Average fuel economy

Auto Stop (if equipped)

Digital speedometer
B0090KO01
To change the trip mode, toggle the
", " switch on the steering wheel

[ Manual reset
To clear the average fuel economy
manually, press the OK switch on the
steering wheel for more than 1 second
when the Average Fuel Economy is
displayed.

[ Automatic reset
To automatically reset the average
fuel economy, select between ‘After
Ignition’ or ‘After Refueling’ from
the Settings menu in the instrument
cluster.

- After Ignition: When the engine has
been OFF for 3 minutes or longer
the average fuel economy will reset
automatically.
- After Refueling: The average fuel economy will reset automatically
after adding 1.6 gallons (6 liters) of
fuel or more and after driving speed
exceeds 1 mph (1 km/h).

à For 10.25-inch instrument cluster, you
can check the fuel economy in the
center bottom of the cluster.

04
4-35
B0803EU01
Drive info
Trip distance M, t
otal driving time N and
average fuel economy O are displayed.
The information is combined for each
ignition cycle. However, when the engine
has been OFF for 3 minutes or longer the
Drive Info screen will reset.
To reset manually, press the OK switch
on the steering wheel for more than 1
second when ‘Drive Info’ is displayed.
B0803EU02
Since refuel(l)ing
Trip distance M, t
otal driving time N and
average fuel economy O are displayed.
To reset manually, press the OK switch
on the steering wheel for more than
1 second when ‘Since Refueling’ is
displayed.
B0803EU03
Accumulated info
Accumulated trip distance M, t
otal
driving time N and average fuel
economy O are displayed.
The information is accumulated starting
from the last reset.
To reset manually, press the OK switch
on the steering wheel for more than
1 second when ‘Accumulated Info’ is
displayed.
B0802EU04
Auto stop (if equipped)
AUTO STOP display shows the elapsed
time o
f engine stop by Idle Stop and Go
system.
For more details, refer to “Idle Stop and
Go (ISG)” section in chapter 6.

Instrument Cluster4-36
B0802EU05
Digital speedometer
Digital speedometer display shows the
speed o
f the vehicle.
