DODGE TOWN AND COUNTRY 2001 Service Manual CABIN HEATER ASSIST C2 (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 A119 14RD/OR FUSED B(+) 2 Z149 14BK/DB GROUND CAMSHAFT POSITION SENSOR (GAS) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 F888 18BR/PK 8 VO

Page 1018 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual CENTER DOME LAMP (BASE/HIGH LINE) - GRAY 3 WAY CAV CIRCUIT FUNCTION 1 M22 20YL/OR COURTESY LAMPS DRIVER 2 Z327 20BK/OR GROUND 3 M27 20YL/LB READING LAMPS DRIVER CENTER HIGH MOUNTED STOP LAMP - BLACK 2

Page 1019 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual CLOCKSPRING C4 - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X20 20RD/BK RADIO CONTROL MUX 2 X920 20RD/DB RADIO CONTROL MUX RETURN CLOCKSPRING C5 - YELLOW 4 WAY CAV CIRCUIT FUNCTION 1 R45 18OR/LB DRIVER SQUIB

Page 1020 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual CONTROLLER ANTILOCK BRAKE - BLACK 24 WAY CAV CIRCUIT FUNCTION 1 Z107 12BK/DG (OTHER) GROUND 1 Z107 12BK/TN (EXCEPT BUILT-UP- EXPORT/ 2.4L)GROUND 2 B1 18DG/OR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 3 B2

Page 1021 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual CRANKSHAFT POSITION SENSOR (DIESEL) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K24 20BR/LB CRANKSHAFT POSITION SENSOR SIGNAL NO. 1 2 K3 20BR/OR CRANKSHAFT POSITION SENSOR SIGNAL NO. 2 3 Z122 18WT GROUND (DR

Page 1022 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual DIAGNOSTIC JUNCTION PORT - BLACK 16 WAY CAV CIRCUIT FUNCTION 1 D25 20WT/VT PCI BUS (PCM/SKIM/ECM/THATCHAM) 2 D25 20WT/VT PCI BUS (HVAC) 3 D25 20WT/VT PCI BUS (RADIO) 4 D25 20WT/VT PCI BUS (ORC) 5 D25

Page 1023 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual DRIVER BLEND DOOR ACTUATOR (ATC) - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 C61 20DB/LG DRIVER BLEND DOOR DRIVER (A) 2 C161 20LB/WT DRIVER BLEND DOOR DRIVER (B) DRIVER BLEND DOOR ACTUATOR (MTC) - GRAY 2 WAY

Page 1024 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual DRIVER HEATED SEAT CUSHION - BLACK 4 WAY CAV CIRCUIT FUNCTION A P87 16LG/OR HEATED SEAT DRIVER B P88 16LG/LB HEATED SEAT DRIVER C P89 20LG/BR HEATED SEAT BACK D Z848 18BK/OR GROUND DRIVER HEATED SEAT
