DODGE TOWN AND COUNTRY 2001 Service Manual PASSENGER HEATED SEAT BACK - GREEN 2 WAY CAV CIRCUIT FUNCTION A S1 18WT (LHD) HEATED SEAT DRIVER A S2 18GY (RHD) GROUND B S2 18GY (LHD) GROUND B S1 18WT (RHD) HEATED SEAT DRIVER PASSENGER HEATED SEAT

Page 1066 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual PASSENGER HEATED SEAT MODULE C3 - GREEN 4 WAY CAV CIRCUIT FUNCTION 1 P87 16LG/OR HEATED SEAT DRIVER 2 P88 16LG/LB HEATED SEAT DRIVER 3 P89 20LG/BR HEATED SEAT BACK 4 Z848 18BK/OR GROUND PASSENGER POWE

Page 1067 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual PASSENGER POWER SEAT SWITCH - GREEN 10 WAY CAV CIRCUIT FUNCTION 1 Z848 14BK/OR GROUND 2 P44 14LG/VT PASSENGER RECLINER UP SWITCH SENSE 3 P16 14LG/WT PASSENGER HORIZONTAL REARWARD SWITCH SENSE 4 P42 14

Page 1068 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual PASSENGER SEAT BELT TENSIONER-2WAY CAV CIRCUIT FUNCTION 1 R54 18LB/YL PASSENGER SEAT BELT TENSIONER LINE 2 2 R56 18LB/DG PASSENGER SEAT BELT TENSIONER LINE 1 POWER FOLDING MIRROR SWITCH (BUILT-UP-EXPO

Page 1069 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual POWER LIFTGATE MODULE C2 - BLACK/RED 20 WAY CAV CIRCUIT FUNCTION 1 Q90 20TN/VT LIFTGATE HALL EFFECT SIGNAL 2- - 3 Q151 20TN/DB LIFTGATE ENGAGE/DISENGAGE SWITCH SENSE 4- - 5 Q76 20OR/LB PINCH SENSOR SI

Page 1070 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual POWER MIRROR SWITCH - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 P70 20TN/LB RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 1 P70 18TN/LB (MEMORY) RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 2- - 3- - 4- - 5 E18 20OR/L

Page 1071 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual POWERTRAIN CONTROL MODULE C1 (2.4L/3.3L/3.8L) - GRAY/BLACK 40-WAY CAV CIRCUIT FUNCTION 1- - 2 K18 16DB/OR (3.3L/3.8L) IGNITION COIL NO. 3 DRIVER 3 K17 16DB/TN IGNITION COIL NO. 2 DRIVER 4- - 5 V32 18V

Page 1072 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual POWERTRAIN CONTROL MODULE C2 (2.4L/3.3L/3.8L) - GRAY/GRAY 40 WAY CAV CIRCUIT FUNCTION 41 V37 18VT SPEED CONTROL SWITCH SIGNAL 42 C18 18LB/BR A/C PRESSURE SENSOR SIGNAL 43 K900 18DB/DG SENSOR GROUND 44
