DODGE TOWN AND COUNTRY 2001 Service Manual LEFT PARK LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z343 16BR GROUND 2 L77 16BK FUSED PARK LAMP RELAY OUTPUT(LEFT) LEFT POWER MIRROR - BLACK 12 WAY CAV CIRCUIT FUNCTION 1 P171 20TN/Y

Page 1050 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LEFT REAR PILLAR SPEAKER - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X157 20DG LEFT REAR PILLAR SPEAKER (+) 2 X151 20DG/WT LEFT REAR PILLAR SPEAKER (-) LEFT REAR READING LAMP (LUXURY) - GRAY 3 WAY CAV CIRCUI

Page 1051 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LEFT REMOTE RADIO SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X20 20RD/BK RADIO CONTROL MUX 2 X920 20RD/DB RADIO CONTROL MUX RETURN LEFT REPEATER LAMP (BUILT-UP-EXPORT) - GRAY 2 WAY CAV CIRCUIT FUNCTI

Page 1052 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LEFT SLIDING DOOR CONTROL MODULE C2 (POWER SLIDING DOOR) - BLACK/RED 20 WAY CAV CIRCUIT FUNCTION 1 Q71 20TN/VT LEFT DOOR MOTOR HALL EFFECT SUPPLY 2- - 3 Q35 20OR/GY LEFT DOOR LOCK SENSE 4 Q55 20OR/BR

Page 1053 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LEFT SLIDING DOOR LOCK MOTOR/AJAR SWITCH (MANUAL SLIDING DOOR) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 P5 20BK/DB LEFT SLIDING DOOR UNLOCK DRIVER 2 P32 20BK/TN LEFT SLIDING DOOR LOCK DRIVER 3 G77 20BK/DG

Page 1054 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LEFT TURN SIGNAL LAMP (BUILT-UP-EXPORT) - ORANGE 2 WAY CAV CIRCUIT FUNCTION 1 Z343 16BR GROUND 2 L61 16YL LEFT FRONT TURN SIGNAL DRIVER LEFT VISOR/VANITY LAMP (PREMIUM/LUXURY) - BLACK 2 WAY CAV CIRCUI

Page 1055 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LICENSE LAMP (POWER RELEASE) - DK. GRAY 4 WAY CAV CIRCUIT FUNCTION 1 L77 18WT/BR FUSED PARK LAMP RELAY OUTPUT (LEFT) 2 Z367 20BK/BR GROUND 3 P30 20TN/DG LIFTGATE HANDLE SWITCH SENSE 4 Z430 20BK/LG GRO

Page 1056 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual LIFTGATE LEFT PINCH SENSOR (POWER LIFTGATE) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Q77 20OR/DB RIGHT PINCH SENSOR SIGNAL 2 Q76 20OR/LB PINCH SENSOR SIGNAL LIFTGATE RIGHT PINCH SENSOR (POWER LIFTGATE) -
