Page 985 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual BODY CONTROL MODULE C3 - BLACK/WHITE 34 WAY CAV CIRCUIT FUNCTION 1 G23 20VT/DB (POWER SLIDING DOOR)SLIDING DOORS OVERHEAD SWITCH MUX 2 D23 20WT/BR FLASH PROGRAM ENABLE 3 G152 20VT/GY (POWER SLIDING DO

Page 986 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual BODY CONTROL MODULE C4 - BLACK/GRAY 34 WAY CAV CIRCUIT FUNCTION 1 E18 20OR/LB (POWER MIRRORS) PANEL LAMPS DRIVER (MIRROR SWITCH) 2 E12 20OR/GY PANEL LAMPS DRIVER (HVAC) 3 E19 20OR/BR PANEL LAMPS DRIVE

Page 987 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual BODY CONTROL MODULE C5 - BLACK/BLACK 34 WAY CAV CIRCUIT FUNCTION 1 L91 20WT/DB HAZARD SWITCH SENSE 2- - 3- - 4- - 5- - 6- - 7- - 8- - 9- - 10 G20 20VT/BR IGNITION SWITCH SENSE 11 - - 12 - - 13 - - 14

Page 988 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual BRAKE FLUID LEVEL SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION A B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE B Z420 20BK/OR GROUND BRAKE LAMP SWITCH - BLACK 6 WAY CAV CIRCUIT FUNCTION 1 A103 18GY/RD FUSED

Page 989 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual C100 - BLACK (POWERTRAIN SIDE) CAV CIRCUIT 1 D21 18WT/BR 2 D16 18WT/OR (EATX) 3 D20 18WT/LG (GAS) 3 K119 20DB/LG (DIESEL) 4 D25 20WT/VT (DIESEL) 4 D25 18WT/VT (GAS) 5 Z111 18BK/WT 6 N1 18DB/OR (DIESEL

Page 990 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual C102 (2.4L) - BLACK (FUEL RAIL SIDE) CAV CIRCUIT 1 K11 16BR/YL 2 K12 16BR/DB 3 K13 16BR/LB 4 K14 16BR/TN 5 K342 16BR/WT 6 K900 18DB/DG 7 K2 18VT/OR 8 K1 18VT/BR 9- 10 F855 18PK/YL (BUILT-UP-EXPORT) 10

Page 991 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual C102 (3.3L/3.8L) - BLACK (POWERTRAIN SIDE) CAV CIRCUIT 1 K342 16BR/WT 2 K1 18VT/BR 3 K11 16BR/YL 4 K12 16BR/DB 5 K13 16BR/LB 6 K14 16BR/TN 7 K900 18DB/DG 8 K38 16BR/OR 9 K58 16BR/VT 10 F855 18PK/YL C1

Page 992 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual C106 (BUILT-UP-EXPORT) - BLACK/YELLOW (COMPONENT SIDE) CAV CIRCUIT 1 L43 16WT 2 L33 16GY 3 L77 16BK 4 L61 16YL 5 Z343 16BR 6 L13 16RD 7 Z2O3 16BR 8- C107 (BUILT-UP-EXPORT) - BLACK (FRONT END LIGHTING
