Page 1081 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT CYLINDER LOCK SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z462 20BK/WT GROUND 2 G162 20VT/WT RIGHT CYLINDER LOCK SWITCH MUX RIGHT DOOR SPEAKER - BLACK/RED 6 WAY CAV CIRCUIT FUNCTION 1 X154 20GY/

Page 1082 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT FRONT PARK/TURN SIGNAL LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 L60 18WT/TN RIGHT FRONT TURN SIGNAL DRIVER 2 L78 18WT/OR FUSED PARK LAMP RELAY OUTPUT (RIGHT) 3 Z378 18B

Page 1083 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT HEADLAMP LEVELING MOTOR (BUILT-UP-EXPORT) - WHITE 3 WAY CAV CIRCUIT FUNCTION 1 Z203 16BR GROUND 2 L78 16BK FUSED PARK LAMP RELAY OUTPUT (RIGHT) 3 L13 16RD HEADLAMP ADJUST SIGNAL RIGHT HIGH BEAM

Page 1084 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT MID READING LAMP (PREMIUM/LUXURY) - GRAY 3 WAY CAV CIRCUIT FUNCTION 1 M22 20YL/OR COURTESY LAMPS DRIVER 2 Z327 20BK/OR GROUND 3 M27 20YL/LB READING LAMPS DRIVER RIGHT PARK LAMP (BUILT-UP-EXPORT)

Page 1085 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT REAR PILLAR SPEAKER - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X158 20GY/YL RIGHT REAR PILLAR SPEAKER (+) 2 X152 20GY/WT RIGHT REAR PILLAR SPEAKER (-) RIGHT REAR READING LAMP (LUXURY) - GRAY 3 WAY CAV

Page 1086 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT REMOTE RADIO SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 X20 20RD/BK RADIO CONTROL MUX 2 X920 20RD/DB RADIO CONTROL MUX RETURN RIGHT REPEATER LAMP (BUILT-UP-EXPORT) - GRAY 2 WAY CAV CIRCUIT FUNC

Page 1087 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT SLIDING DOOR CONTROL MODULE C2 (POWER SLIDING DOOR) - BLACK/RED 20 WAY CAV CIRCUIT FUNCTION 1 Q72 20TN/VT RIGHT DOOR MOTOR HALL EFFECT SUPPLY 2- - 3 Q34 20OR/GY RIGHT DOOR LOCK SENSE 4 Q54 20OR/

Page 1088 of 2321

DODGE TOWN AND COUNTRY 2001 Service Manual RIGHT SLIDING DOOR LOCK MOTOR/AJAR SWITCH (MANUAL SLIDING DOOR) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 P38 20BK/DB RIGHT SLIDING DOOR LOCK DRIVER 2 P34 20BK/TN RIGHT SLIDING DOOR UNLOCK DRIVER 3 G76 20B
