1998 SSANGYONG MUSSO Workshop Repair Manual

SECTION 9R
BODY FRONT END
TABLE OF CONTENTS
Maintenance and Repair . . . . . . . . . . . . . . . 9R-2
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9R-2Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9R-2
Fender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9R-5

9R-2 BODY FRONT END
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
HOOD
1 Hood
2 Sping3 Hood Hinge Assembly
4 Bolt

BODY FRONT END 9R-3
Removal & Installation Procedure
1. Remove the hood striker assembly.
Notice
When installing, tighten the bolt after setting the hole
between wratch and hood striker assembly.
Installation Notice
Tightening Toque 8 - 11 Nm
2. Remove the hood Mounting bolt and hood lifter assembly.
Installation Notice
3. Remove the hood lock, hood relese from the clip.
4. Remove the cable holder screw.
5. Pull the cable nut toward driver side.
6. Installation should follow the removal procedure in the
reverse order.
Tightening Toque 14 - 26 Nm

9R-4 BODY FRONT END
Adjustment Procedure
1. Alignment between hood striker and latch hole.
lLoosen the mounting bolt of hood latch slightly and adjust
hood in forward/rearward and left/right directions. Then
align the center between hood striker and latch hole.
Notice
Tighten the bolt fully after alignment.
Installation Notice
Tightening Toque 13 - 26 Nm
2. Adjusting the height of hood overslam bumper.
Unlock the hood and check the clearance between hood
and fender by adjusting the hood overslam bumper in left/
right directions.
Normal 20 - 22 Nm
3. Hood Hinge.
lLoosen the hood lock bolts.
lAdjust the lock in forward/rearward and left/right
directions, align with the hood striker and adjust the hood
height.

BODY FRONT END 9R-5
FENDER
Removal Procedure
1. Remove the screws.
2. Remove the mudguard and wheel guard.
3. Disconnect the front lamps connectors.
4. Remove the front lamps.

9R-6 BODY FRONT END
5. Remove the fender mounting bolts.
Notice
Be careful not to damage the paintwork.
Installation Procedure
1. Installation should follow the removal procedure in the
reverse order.
Notice
Apply a tape sealer to the fender and body panel to prevent
rust in fender mounting bolts area.
Tightening Torque 7 - 9 Nm

SECTION 9T
REMOTE KEYLESS ENTRY AND
ANTI-THEFT SYSTEM
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 9T-1
REKES Specifications . . . . . . . . . . . . . . . . . . . 9T-1
Schematic and Routing Diagrams . . . . . . . . 9T-2
REKES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9T-2
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . 9T-3
SPECIFICATIONS
REKES SPECIFICATIONS
Diagnosis Test . . . . . . . . . . . . . . . . . . . . . . . . 9T-3
Maintenance and Repair . . . . . . . . . . . . . . . 9T-5
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9T-5
REKES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9T-5
Transmitter
Description
DC 3V
-10°C - 60°C
Changeable Coin Type LITHIUM Battery
(CR2032)
Above 2 years (10 times/day) Application
Rated Voltage
Rated Range of Operating Temperature
Model
Durability
Description
DC 12V
DC 8V - 16V
-30°C - +80°C
Above 5M W
Maximum 3mA Application
Rated Voltage
Rated Range of Operating Voltage
Rated Range of Operating Temperature
Insulating Resistance
Arm Current
Receiver

9T-2 REMOTE KEYLESS ENTRY AND ANTI-THEFT SYSTEM
REKES
SCHEMATIC AND ROUTING DIAGRAMS
