1998 SSANGYONG MUSSO Workshop Repair Manual

5A-96 AUTOMATIC TRANSMISSION
9. Check that the cam collar slides freely on the rod.
10. Insert the cross shaft into the case, from the side opposite
to the inhibitor switch, then install the anti-rattle spring on
the shaft.
11. Position the manual valve detent lever, aligning it with the
cross-shaft bore in the case.
12. Push the shaft through the detent lever until it starts in the
detent lever side of the case.
13. Install the detent lever drive pin in the shaft using tool No.
0555-331897 with the adaptor over the pin.
14. Press the pin into the shaft until the tool bottoms.
15. Remove the tool and fit the spring retaining circlip to the
shaft.
16. Install the new cross shaft seals using tool No. 0555-
331894.
17. Install the inhibitor switch on the case. Torque the screws
as per specifications. Press the pin into the shaft until the
tool bottoms (4WD models) using tool No.0555-332942.
18. Thoroughly check the terminal wiring loom for condition
and continuity.
19. Position the loom and locate the solenoid 7 contact and
terminal in the pump mounting flange at the front of the
case. The solenoid 7 wire is routed under the park rod
and cross shaft in the case.

AUTOMATIC TRANSMISSION 5A-97
20. Install the ten pin connector in the case engaging the tangs
on the connector in the notches in case.
4WD MODELS ONLY
21. Route the portion of the wiring loom coming out of the
case down between the inhibitor switch and the case.
Position the ten pin plug on the wiring loom bracket .

5A-98 AUTOMATIC TRANSMISSION
Rear Band Assembly
To assemble the rear band assembly proceed as follows:
1. Check the rear band for any cracks or damage along the
lining and metal backing.
2. Install the reaction anchor strut into the main case, without
shims.
Notice
If fitting a new band, soak the new band in automatic
transmission fluid (or a minimum of five minutes prior to
assembly.
3. Carefully install the rear band into the transmission case
and ensure that it is properly fitted in the case.
4. Position the apply strut on the rear band then engage the
apply strut in the servo lever.
5. Install the cam plate and tighten the screws to specification.
Figure 8.19 - Thrust Bearing and Washer LocationsFigure 8.18 - Rear Servo and Band

AUTOMATIC TRANSMISSION 5A-99
Output Shaft and Gear Assembly
To assemble the output shaft and gear assembly (refer to
(figure 8.19), proceed as follows:
1. Check that the output shaft bush is not won or damaged.
Replace if necessary.
2. Check for damage to parking pawl teeth on the ring gear.
Replace if necessary.
3. Check that the sealing ring grooves have not been
damaged.
4. Lubricate the sealing rings with automatic transmission fluid.
5. Assemble the sealing rings to the output shaft with the scat
cut uppermost.
6. If previously dismantled, assemble the ring gear to the output
shaft and secure with circlip. Ensure that the circlip is firmly
seated in its groove.
7. Fit the thrust bearing assembly No. 10 onto the output shaft
using petroleum jelly.
8. Carefully install the output shaft assembly in the case to
prevent damage to the sealing rings.
Rear Servo Assembly
To assemble the rear servo assembly (refer to figure 8.18),
proceed as follows.
1. Check the servo piston ‘O’ rings and gasket for any damage.
2. Lubricate the servo piston ‘O’ rings with automatic
transmission fluid, and fit the ‘O’ rings to the piston grooves.
3. Assemble the piston to the cover, ensuring that ‘O’ ring
compression is adequate but not excessive.
4. Align the spring on the piston spigot, then position the rear
servo rod into the spigot.
Notice
Do not use petroleum jelly on the gasket.
5. Assemble the gasket to the cover and fit the assembly to
the case.
6. Apply Loctite 567 sealant to the bolts. Install the bolts and
tighten to specification.

5A-100 AUTOMATIC TRANSMISSION
Planet Carrier Assembly and Centre Support
To assemble the planet carrier assembly and centre support,
proceed as follows.
1. Check the carrier and planet assembly for any damage or
irregularity and ensure that all pinions rotate freely and
that the pinion end float is within the tolerance stated in
section 9.2.
2. Install the one way clutch (OWC) retainer to the planet
carrier with the inner edge pointing downwards. Inspect
the OWC race and the sprag assembly for wear or damage.
Replace if necessary.
3. Install the outer race in the drum. Press the race to the
bottom of the drum and install the retaining circlip. Ensure
the circlip is firmly seated in its groove.
Refer to figure 8.21.
4. Install the OWC into the outer race with the lip edge
uppermost. Lubricate the sprags with automatic
transmission fluid. Refer to figure 8.20.
5. Check that the plugs are fitted to the centre support, then
assemble the centre support into the OWC, ensuring that
the support will rotate in an anti-clockwise direction only.
Refer to figure 8.21.
Figure 8.20 - Planet Carrier Assembly and
Centre Support
6. Lubricate the No.9 needle thrust bearing and the thrust
washer with petroleum jelly and fit them to the rear face of
the planet carrier. Refer to figure 8.19.
7. Install the planet assembly and the centre support into the
case, and align the centre support mounting bolt holes.
8. Install the centre support bolts finger tight.
9. Install the circlip retainer ensuring that the circlip is
completely seated in the groove of the case.
10. Remove the centre support bolts and apply Loctite 222 or
equivalent to the threads. Install the bolts and torque to
specifications.

AUTOMATIC TRANSMISSION 5A-101
Extension Housing Assembly
To assemble the extension housing assembly, proceed as
follows.
1. Check the condition of the extension housing roller bearing.
Replace if necessary (RWD models). Install the new bearing
from rear of extension housing. Press on the branded face
of bearing only.
2. Install a new seal to the extension housing or adaptor
housing. Refer to figure 8.21.
Notice
Do not use petroleum jelly to hold the gasket in position.
3. Position a new gasket onto the extension housing or adaptor
housing.
Notice
See section 8.3.17 for the procedure to assemble the output
flange assembly - RWD models.
4. Install the extension housing (RWD) or adaptor housing
(4WD) and torque the bolts to specification.
Front Servo Assembly
NOTICE
Ensure that the front servo snap ring is installed correctly.
Orient the circlip with the gap at the bottom, near the pan rail.
Refer to figure 8.22.
To assemble the front servo assembly (refer to figure 8.22),
proceed as follows.
1. Lubricate the cover ‘O’ ring with automatic transmission fluid
and fit to the cover.
2. Lubricate the piston ‘O’ rings with automatic transmission
fluid and fit to the piston.
3. Assemble the piston, push rod, spring, belleville washer,
seat and retaining ring.
4. Fit the piston push rod assembly into the front servo cover.
5. Install the front servo block and spring into the case.
6. Install the front servo assembly into the case.
7. Compress the servo cover and fit the servo cover retaining
circlip, aligning the gap with the pan rail, and ensuring that
it is completely seated in its groove.
Figure 8.21 - Extension Housing
Figure 8.22 - Front Servo and Band

5A-102 AUTOMATIC TRANSMISSION
Front Band Assembly
To assemble the front band assembly, proceed as follows.
1. Install the reaction anchor strut to the case.
2. Check the band for ally cracks or damage along its lining
and metal backing.
3. Position the strut retainers on the band (refer to figure
8.23).
NOTICE
If fitting a new band, soak the band in automatic
transmission fluid for a minimum of 5 minutes prior to
assembly.
4. Install the front band into the transmission case, ensuring
that it is properly seated in place.
5. Position the reaction strut in its retaining clip and engage
it with the band and anchor strut.
Position the apply strut in its retaining clip and engage it
with the band and the servo piston rod.
C2/C4 Clutch Assembly
Notice
1. Check pistons for cracks.
2. Do not mix the clutch piston return springs.
3. Ensure that the snap rings are fitted correctly.
To assemble the C2/C4 clutch assembly (refer to figure 8.24),
proceed as follows.
1. Check the feed orifices in the cylinder bore are clear of
obstructions.
2. Check the C2 piston bleed orifices are clear of obstructions.
3. Lubricate the ‘O’ rings with automatic transmission fluid.
Notice
‘O’ rings must not be twisted in the grooves.
4. Fit the small ‘O’ ring onto the inner groove, and the large
‘O’ ring onto the outer groove of the piston.
5. Check the C4 piston bleed orifices are clear of obstructions.
6. Lubricate the ‘O’ rings with automatic transmission fluid.
7. Fit the small ‘O’ rings onto the inner groove and the large
‘O’ rings onto the outer groove of the piston.
8. Position the clutch cylinder with the C2/C4 cavity facing
upwards.
9. Fit the C4 piston into the C2 piston with the bleed orifices
in alignment.
10. Install the C2/C4 piston assembly into the cylinder, with the
piston bleed orifices aligned with the holes on the outside
of the cylinder, until the outer diameter of the C2 piston
enters the inner diameter of the cylinder.
Figure 8.23 - Front Band Strut Installation
Figure 8.24 - Typical C2/C4 Clutch Assembly

AUTOMATIC TRANSMISSION 5A-103
11. Assemble the piston return spring to the piston, and fit the
spring retainer over the spring.
Notice
The wire diameter of this spring is 4.3 mm.
12. Using special tool No. 0555-331899, compress the spring
sufficiently to enable the installation of the retaining circlip
ensuring that the circlip is firmly seated in its groove, then
remove the tool.
13. Check the C1 piston check valves are not damaged and
are free to move, and that the cylinder feed orifices are
clear of obstructions.
14. Lubricate the’0’rings with automatic transmission fluid and
fit them to their respective grooves.
Notice
‘O’ rings must not be twisted in the grooves.
15. Position the cylinder with the C1 cavity upwards. Install the
piston into the cylinder until the outer diameter of the piston
enters the inner diameter of the cylinder.
16. Install the spring and spring retainer onto the piston.
Notice
The wire diameter of this spring is 5.26 mm.
17. Using special tool No. 0555-331899, compress the spring
sufficiently to enable the installation of the retaining circlip
ensuring that the circlip is firmly seated in its groove, then
remove the tool.
18. Install the C2 wave washer into the cylinder with the crest
of one wave covering one of the bleed orifices in the C2
piston.
19. Measure and record the thickness of the flange of the C2
sleeve. Refer to figure 8.25.
20. Install the C4 clutch plates and wave washer into the C2
actuating sleeve, with the rounded edge of the steel plates
down, in the following sequence:
lSteel plate (selective)
lFriction disc
lSteel plate
lFriction disc
lSteel plate
lFriction disc
lSteel plate
lWave washer
