1998 SSANGYONG MUSSO Workshop Repair Manual

MANUAL & SEMIAUTO-HVAC 7B/C-15
Removal & Installation Procedure
1. Disconnect the inlet and outlet pipes of condenser.
Notice
Before disconnection, evacuate the refrigerant from the
system.
2. Remove the mounting bolts (4 EA) and condenser assembly.
3. Installation should follow the removal procedure in the
reverse order.

7B/C-16 MANUAL & SEMIAUTO-HVAC
1 Main Condenser Fan
2 Auxiliary Condenser Fan3 Bolt
4 Condenser
Gasoline Engine

MANUAL & SEMIAUTO-HVAC 7B/C-17
Removal & Installation Procedure
1. Disconnect the inlet and outlet pipes of condenser.
Notice
Before disconnection, evacuate the refrigerant from the
system.
2. Remove the mounting bolts (4bolts) and condenser
assembly.
3. Remove the main condenser fan from condenser.
4. Installation should follow the removal procedure in the
reverse order.

7B/C-18 MANUAL & SEMIAUTO-HVAC
RECEIVER DRIER
Diesel Engine
1 Condenser
2 Receiver Drier
3 Bolt......................................................... 4-6 Nm4 Bolt..........................................................5-8 Nm
5 Bracket

MANUAL & SEMIAUTO-HVAC 7B/C-19
Removal & Installation Procedure
1. Disconnect the negative(-) terminal from the battery.
2. Discharge refrigerant from the system.
Notice
By connecting a manifold gauge connection hose to High/
Low pressure line, discharge the refrigerant.
3. Disconnect the inlet and outlet pipes of receiver drier.
Notice
When installing, check the O-ring and apply the compressor
oil.
Installation Notice
4. Remove the bracket bolt and then remove the receiver drier.
Installation Notice
Tightening Torque
4 - 6 Nm
5. Installation should follow the removal procedure in the
reverse order.
Tightening Torque
5 - 8 Nm

7B/C-20 MANUAL & SEMIAUTO-HVAC
1 Condenser
2 Receiver Drier3 Bracket
Removal & Installation Procedure
1. Disconnect the dual pressure switch connector from the
receiver drier.
2. Discharge refrigerant from the system.
3. Remove the high pressure pipe from the inlet / outlet of
receiver drier.
4. Remove the bracket bolts and remove the receiver drier.
5. Installation should follow the removal procedure in the
reverse order.
Gasoline Engine

MANUAL & SEMIAUTO-HVAC 7B/C-21
COMPRESSOR
Preceding Work : Removal of the poly V-belt
Diesel Engine
1 Low Pressure Pipe
2 High Pressure Pipe3 Compressor Bracket
4 Compressor

7B/C-22 MANUAL & SEMIAUTO-HVAC
Removal & Installation Procedure
1. Disconnect the negative(-) terminal from the battery.
2. Discharge refrigerant from the system.
Notice
By connecting a manifold gauge connection hose to High/
Low pressure line, discharge the refrigerant.
3. Disconnect the high / low pressure pipe and wire connectors.
Installation Notice
Notice
Before tightening, apply the compressor oil to O-ring.
Tightening Torque
20 - 30 Nm
4. Remove the mounting bolt from the compressor bracket
and remove compressor assembly.
Notice
Place the removed compressor in vertical position.
Installation Notice
5. Installation should follow the removal procedure in the
reverse order.
Tightening Torque
21 - 26 Nm
