1998 SSANGYONG MUSSO Workshop Repair Manual

5A-128 AUTOMATIC TRANSMISSION
FRONT AND REAR BAND ADJUSTMENT
Front Band Setting Procedure
To set the front band, proceed as follows.
1. Measure the projection of the front servo push rod from the transmission case. Refer to figure 8.66, dimension A.
a. Apply air at 650/700 kPa to the front servo apply area (B1 outer). (Refer to figure 8.67.)
b. Measure the travel of the push rod and subtract 3 mm to find the shim size required.
c. Release the air.
Notice
A minimum of one shim is required at all times - minimum shim size is 1 mm. The thicknesses of available shims
are listed in table 8.2.
2. Fit the selected shim(s) to the shank of the anchor strut as follows:
a. Inspect the shim(s) for damage, wear or corrosion. Replace as necessary.
b. The shim(s) are to be installed between the case abutment face and the anchor strut flange. Refer to figure
8.66.
c. The shim(s) are to be fitted by hand and under no circumstances to be hammered or forced.
d. Shim(s) are to be pressed on by hand until an audible click is heard. The click indicates that the shim is clipped
home correctly.
3. Re-check that the push rod travel is 3 mm ± 0.25 mm.
Figure 8.66 - Front Band Settings

AUTOMATIC TRANSMISSION 5A-129
Figure 8.68 - Rear Band Settings
Rear Band Setting Procedure
To set the rear band, proceed as follows.
1. Measure distance ‘A’ from the rear servo piston to the inner face of the transmission case using vernier calipers.
Refer to figure 8.68.
a. Apply air at 650/700 kPa to the rear servo apply area (B2 outer). Refer to figure 8.67.
b. Measure the travel of the piston, subtract 3.75 mm and divide the remainder by 2.5 to find shim size.
c. Release the air.
Notice
A minimum of one shim is required at all times - minimum shim size is 1 mm. The thickness of available shims
are listed in table 8.2.
2. Fit the selected shim(s) to the shank of the anchor strut as follows.
a. Inspect the shim(s) for damage, wear or corrosion and replace as necessary. The shim(s) are to be installed
between the case abutment face and the anchor strut flange. Refer to figure 8.68.
c. The shim(s) are to be fitted by hand and under no circumstances to be hammered or forced.
d. The shim(5) are to be pressed on by hand until an audible click is heard. The click indicates that the shim is
clipped home correctly.
3. Re-check that the piston travel is 3.75 mm ± 0.625 mm.

5A-130 AUTOMATIC TRANSMISSION
Table 8.2 - Thickness of Available Shims
Thickness
0.95/1.05
1.15/1.25
1.44/1.56
1.73/1.87Part Number
0574-037017
0574-037018
0574-037019
0574-037020Thickness
1.93/2.07
2.12/2.28
2.42/2.58
2.61/2.79Part Number
0574-037021
0574-037022
0574-037023
0574-037024
Figure 8.68 - Thickness of Available Shims

Model
Type
Gear Ratio
Oil
Weight (Dry)
SECTION 5B
MANUAL TRANSMISSION
TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 5B-1
General Specifications . . . . . . . . . . . . . . . . . . 5B-1
Fastener Tightening Specifications . . . . . . . . . 5B-2
External View . . . . . . . . . . . . . . . . . . . . . . . . 5B-3
Gear Train . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-3
Power Flow . . . . . . . . . . . . . . . . . . . . . . . . . 5B-4
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-5
Will not Shift (Control Lever Moves) . . . . . . . . 5B-5
Hard Shift or Control Lever Will not Move Into
Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-5
Gears Crash When Shifting . . . . . . . . . . . . . . 5B-5
Transmission Jumps Out . . . . . . . . . . . . . . . . . 5B-6
Transmission Locked in One Gear . . . . . . . . . 5B-6
Transmission Noise . . . . . . . . . . . . . . . . . . . . . 5B-6
Transmission Leakage . . . . . . . . . . . . . . . . . . 5B-7Diagnosis Table . . . . . . . . . . . . . . . . . . . . . . . 5B-8
Component Locator . . . . . . . . . . . . . . . . . . . 5B-9
Maintenance and Repair . . . . . . . . . . . . . . 5B-11
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . 5B-11
Shift Control Cable . . . . . . . . . . . . . . . . . . . . 5B-11
Transmission . . . . . . . . . . . . . . . . . . . . . . . . 5B-14
Unit Repair . . . . . . . . . . . . . . . . . . . . . . . . . 5B-17
Major Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-17
Main Shaft . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-27
Input Shaft . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-32
Counter Shaft . . . . . . . . . . . . . . . . . . . . . . . . 5B-34
Extension Housing . . . . . . . . . . . . . . . . . . . . 5B-35
Shift Cover . . . . . . . . . . . . . . . . . . . . . . . . . . 5B-36
Inspection of Components . . . . . . . . . . . . . . 5B-40
Pre-Installation Checks . . . . . . . . . . . . . . . . . 5B-45
SPECIFICATIONS
GENERAL SPECIFICATIONS
Application
Description
T5WC
Floor Change
3.97 : 1
2.34 : 1
1.46 : 1
1.00 : 1
0.85 :1
3.71 : 1
ATF DEXRON II / III
3.4 L
Check : Every 15,000km, Replace : Every 50,000km
33kg 1st
2nd
3rd
4th
5th
Reverse
Specification
Capacity(litre)
Change Interval
Notice
Add LUBRIZOL (280cc) in oil after overhauling.

5B-2 MANUAL TRANSMISSION
FASTENER TIGHTENING SPECIFICATIONS
Application
Transmission
Oil Filler Plug
Transmission Mounting Bolt (Housing)
Oil Drain Plug
Front Propeller Shaft (T/C)
Rear Propeller Shaft (T/C)
Cross Member Bolt (Center)
Cross Member Bolt (Side)
Control Cable
Shift Lever BoltNlm
25
77 - 87
25
81 - 89
70 - 90
21 - 35
62 - 93
20 - 30

MANUAL TRANSMISSION 5B-3
EXTERNAL VIEW
GEAR TRAIN

5B-4 MANUAL TRANSMISSION
POWER FLOW

MANUAL TRANSMISSION 5B-5
Check
Clutch not releasing.
Improper or low transmission oil.
Shift or shift rail binding.
Binding of sliding synchronizers or gears.
If reverse only, faulty backup switch.
Worn or damaged flywheel pilot bushing.Check
Control lever assembly broken or damaged.
Damaged offset lever, shift fork, selector place or
selector arm.
DIAGNOSIS
WILL NOT SHIFT(CONTROL LEVER MOVES)
Action
Replace control lever and housing assembly.
Remove extension, adapter or case cover.
Check or replace damaged parts.
HARD SHIFT OR CONTROL LEVER WILL NOT MOVE INTO GEAR
Action
Adjust or replace clutch.
Add or replace with specified oil.
Remove extension, adapter or case cover.
Check or replace damaged parts.
Remove extension, adapter or case cover.
Check synchronizers and gears and replace
damaged parts.
Check or replace backup switch.
Replace pilot bushing.
GEARS CRASH WHEN SHIFTING
Check
Engine idle speed too high.
Damaged or faulty clutch.
Pilot bearing between input shaft and output shaft binding.
Damaged synchronizer.
Bell housing misaligned.
Damaged gear(s).
Worn or damaged flywheel pilot bushing.Action
Adjust idle speed to specified speed.
Adjust or replace clutch.
Replace or check roller bearings.
Check or replace synchronizer parts.
Align bell housing and bore.
Check or replace gear(s).
Replace pilot bushing.
