1998 SSANGYONG MUSSO Workshop Repair Manual

Low (Philips H4)
Tail Lamp
Brake Lamp
High Mounted Stop Lamp
Reverse Lamp
Fog Lamp*
Turn Signal Lamp
Position Lamp
Front Lamp
Rear Lamp
Luggage Lamp
Door Courtesy Lamp
SECTION 9B
LIGHTING SYSTEM
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
SPECIFICATIONS
BULB USAGE CHART
Head Lamp
Rear
Front
Interior
Application
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 9B-1
Bulb Usage Chart . . . . . . . . . . . . . . . . . . . . . . 9B-1
Schematic and Routing Diagrams . . . . . . . . 9B-2
Tail Lamp & B/O Lamp . . . . . . . . . . . . . . . . . . 9B-2
Head Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 9B-3
Head Lamp Leveling Device . . . . . . . . . . . . . . 9B-4
Turn Signal Lamp and Hazard Lamp . . . . . . . . 9B-5Back-Up Lamp and Stop Lamp . . . . . . . . . . . . 9B-6
Front and Rear Fog Lamp . . . . . . . . . . . . . . . 9B-7
Room Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . 9B-8Maintenance and Repair . . . . . . . . . . . . . . . 9B-9
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . 9B-9
Front and Rear Lamps . . . . . . . . . . . . . . . . . . 9B-9
Hi
(Philips H1)
Hi
LowWatt/Quantity
55W / 2
55W / 2
55W / 2
5W / 4
21W / 4
21W / 1
21W / 2
55W / 2
21W / 2
5W / 2
8W / 2
10W / 1
8W / 1
5W / 4

9B-2 LIGHTING SYSTEM
TAIL LAMP & B/O LAMP
SCHEMATIC AND ROUTING DIAGRAMS
15
(NO.15)
OVPR

LIGHTING SYSTEM 9B-3
HEAD LAMP

9B-4 LIGHTING SYSTEM
HEAD LAMP LEVELING DEVICE

LIGHTING SYSTEM 9B-5
TURN SIGNAL LAMP AND HAZARD LAMP
3.0BG

9B-6 LIGHTING SYSTEM
BACK-UP LAMP AND STOP LAMP

LIGHTING SYSTEM 9B-7
FRONT AND REAR FOG LAMP

9B-8 LIGHTING SYSTEM
ROOM LAMP
