1998 SSANGYONG MUSSO Workshop Repair Manual

DOORS 9P-3
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
FRONT DOOR
Removal & Installation Procedure
1. Remove the pin from the center hinge of the door.
2. Remove the upper/lower hinge bolts from the body and
remove the door assembly.
3. Installation should follow the removal procedure in the
reverse order.

9P-4 DOORS
REAR DOOR
Removal & Installation Procedure
1. Remove the pin from the center hinge of the door.
2. Remove the upper/lower hinge bolts from the body and
remove the door assembly.
3. Installation should follow the removal procedure in the
reverse order.

DOORS 9P-5
TAIL GATE
Removal & Installation Procedure
1. Remove the shock absorber mounting bolts.
2. Disconnect the tailgate wiring harness.
3. Remove the tailgate by removing the tailgate bracket bolts.
4. Installation should follow the removal procedure in the
reverse order.

9P-6 DOORS
Adjustment Procedure

1. Adjust the striker in forward / rearward and left / right
directions. Adjust striker height by increasing / decreasing
the shims.

2. Adjust the position of the striker as described above.
3. Adjust the position of the safety hook as described above.

SECTION 9Q
ROOF
TABLE OF CONTENTS
Schematic and Routing Diagrams . . . . . . . . 9Q-2
Sun Roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9Q-2
Maintenance and Repair . . . . . . . . . . . . . . . 9Q-3
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9Q-3
Sun Roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9Q-3

9Q-2 ROOF
SUN ROOF
SCHEMATIC AND ROUTING DIAGRAMS

ROOF 9Q-3
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
SUN ROOF
1 Inner Sliding Sun Roof Assembly
2 Sun Roof Body Mounting Bracket
3 Drain Hose Rear Grommet
4 Sun Roof Motor Spanner
5 Mounting Clip6 Mounting Bracket
7 Mounting Bracket Assembly
8 Sun Roof Mounting Bracket
11 Sun Roof Module Assembly

9Q-4 ROOF
Removal & Installation Procedure
1. Disconnect the connector and remove the sun roof module
assembly.
2. Disconnect the front and rear drain hose.
3. Unscrew the sun roof mounting bracket bolts(arrows) and
remove the inner sliding and sun roof assembly
