1998 SSANGYONG MUSSO Workshop Repair Manual

MANUAL & SEMIAUTO-HVAC 7B/C-23
Gasoline Engine
1 Low Pressure Pipe
2 High Pressure Pipe3 Compressor Bracket
4 Compressor
Removal & Installation Procedure
1. Disconnect the negative(-) terminal from the battery.
2. Discharge refrigerant from the system.
Notice
By connecting a manifold gauge connection hose to High/
Low pressure line, discharge the refrigerant.
3. Disconnect the high / low pressure pipe and wire connectors.

7B/C-24 MANUAL & SEMIAUTO-HVAC
4. Remove the mounting bolt from the compressor bracket
and remove compressor assembly.
Notice
Place the removed compressor in vertical position.
5. Installation should follow the removal procedure in the
reverse order.

MANUAL & SEMIAUTO-HVAC 7B/C-25
HEATER AND AIR CONDITIONER CONTROL BOX
1 Blower Switch
2 Recirculation Switch
3 Mode Switch4 A/C Switch
5 Temperature Control Lever
6 In-vehicle Sensor
MANUAL
SATC

7B/C-26 MANUAL & SEMIAUTO-HVAC
Removal & Installation Procedure
1. Remove the switch panel.
Notice
Be careful not to damage the switch panel.
2. Remove the fixing screws (4 screws) of the control box.
3. Disconnect the wire connectors and remove the control box.
4. Installation should follow the removal procedure in the
reverse order.

SECTION 8A
SEAT BELTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 8A-1
Fastener Tightening Specifications . . . . . . . . . 8A-1
Component Locator . . . . . . . . . . . . . . . . . . . 8A-2
Front Seat Belt . . . . . . . . . . . . . . . . . . . . . . . . 8A-2
Rear Seat Belt . . . . . . . . . . . . . . . . . . . . . . . . 8A-3
TABLE OF CONTENTS
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
General Description and System
Operation . . . . . . . . . . . . . . . . . . . . . . . . . 8A-4
Driver Seat Belt Warning . . . . . . . . . . . . . . . . 8A-4
Operation and Functional Checks . . . . . . . . . 8A-4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application
Anchor BoltNlm
35 - 55

8A-2 SEAT BELT
COMPONENT LOCATOR
FRONT SEAT BELT
1 Seat Belt Assembly (3-Point)
2 Buckle Assembly
3 Seat Belt Dust Cover
4 Seat Belt Webbing Guide5 Seat Belt Reel Assembly
6 Anchor Bolt..........................................35-55 Nm
7 Anchor Bolt..........................................35-55 Nm
8 Anchor Bolt..........................................35-55 Nm

SEAT BELTS 8A-3
REAR SEAT BELT
1 Seat Belt Assembly (3-point)
2 Seat Belt Stalk Plate Assembly
3 Seat Belt Assembly (2-Point)
4 Webbing Buckle Assembly (Center)5 Webbing Buckle Assembly (Rear)
6 Webbing Hanger
7 Seat Belt Dust Cover
8 Webbing Guide

8A-4 SEAT BELT
GENERAL DESCRIPTION
AND SYSTEM OPERATION
DRIVER SEAT BELT WARNING
The driver's safety belt incorporates a safety belt reminder
light in the instment cluster remind the driver if the safety belt
is not fastened when the ignition is turnd ON.
OPERATION AND FUNCTIONAL
CHECKS
Caution:
lKeep sharp objects and potentially damaging objects
away from the seat belts.
lAvoid bending or damaging any portion of the buckle
or the latch plate.
lDo not bleach or dye the belt webbing. Use only mild
soap and water in order to clean the belts.
lWhen installing the seat belt anchor bolts and the
screws, start the bolts and screws by hand in order
to prevent crossthreading.
lDo not attempt any repairs on the retractor
mechsemblies with new assemblies.
lReplace any belts that are cut r damaged in any way.
1. Inspect all saet belt anchor bolts and the screw in order to
verify that they are secure.
2. Inspect the seat belt buckle. The buckle must lock and
unlock easily.
3. After inserting the latch into the buckle, tug sharply on the
belt. The buckle must remain locked.
4. Fully extend the shoulder belt portion to make sure that
there is no twisting or tears in the belt.
5. Let the shoulder belt retract fully. The belt should retract
easily.
