1998 SSANGYONG MUSSO Workshop Repair Manual

LIGHTING SYSTEM 9B-9
FRONT AND REAR LAMPS
1 Low-beam Head Lamp
2 High-beam Head Lamp
3 Turn Signal Lamp
4 Position Lamp5 Back-up Lamp
6 Tail / Stop Lamp
7 Turn Signal Lamp
8 Tail / Stop Lamp
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE

9B-10 LIGHTING SYSTEM
Head Lamp Focusing
When using the beam setting device
1. The head lamp focus should be adjusted by using a proper
beam setting device.
2. Adjust the head lamp focus by using Up/Down, Left/Right
adjusting screws.
When using the screen
1. Put the vehicle on the leveling surface.
2. One person is needed to seat on the driver's seat without
other loads(CVW) and check the tire pressure if it is in the
specification.
3. The distance between the headlamp and the screen is 25m.
4. Draw the vertical line (crossing the center of each headlamp)
on the screen.
5. Start the engine.
6. Check if the cut-off line of the headlamp on the screen is in
the specification.
1) Left/right direction
- The degree of the cross point at the cut-off line of the
headlamp and the vertical line should be 15.
2 ) Up/down direction
- The distance between the cut-off line of the headlamp
and the horizontal line should be 25cm.
7. Adjust the focus if the cut-off line of the headlamp is out of
the specification by using up/down, left/right adjusting
screws.
A : Up/down direction adjusting screw
B : Left/right direction adjusting secrw

LIGHTING SYSTEM 9B-11
Head Lamp
Removal & Installation Procedure
1. Unscrew upper 2(10mm) bolts and lower 1(10mm) bolt of
head lamp.
2. Disconnect connector and remove the headlamp.
3. Installation should follow the removal procedure in the
reverse order.
Bulb Replacement
1. Turn the dust cap of the head lamp to the left and remove
it.
2. If it is high/low head lamp, loosen the screw and pull out the
return spring and replace the bulb.
Notice
For correct installation, check the original position of the
return spring and remove.
High/low-beam head lamp replacement
High-beam head lamp replacement
3. If it is high-beam head lamp, pull out the return spring
and replace the bulb.
Notice
Refern to lamp specifications.

9B-12 LIGHTING SYSTEM
Tail/stop and turn signal lamp
Tail/stop Lamp and backup lamp
Rear Combination Lamp
Removal & Installation Procedure
1. Open the tailgate and remove the inner cover of the rear
combination lamp.
2. Unscrew 4(8mm) nuts of tail/stop lamp and turn signal lamp
assembly.
3. Unscrew 6(8mm) nuts of tail/stop lamp and back-up
lamp assembly.
4. Disconnect each connectors and remove the rear
combination lamp. Replace with specified bulb, if
necessary.
Notice
Refer to lamp specification.

SECTION 9C
HORNS
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Schematic and Routing Diagrams . . . . . . . . 9C-2Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9C-2

9C-2 HORN
HORN
SCHEMATIC AND ROUTING DIAGRAMS

SECTION 9D
WIPERS/WASHER SYSTEM
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Schematic and Routing Diagrams . . . . . . . . 9D-2
Rear Wiper and Washer . . . . . . . . . . . . . . . . . 9D-2
Maintenance and Repair . . . . . . . . . . . . . . . 9D-3
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9D-3
Front Wiper and Washer . . . . . . . . . . . . . . . . 9D-3
Rear Wiper and Washer . . . . . . . . . . . . . . . . . 9D-5

9D-2 WIPERS/WASHER SYSTEM
SCHEMATIC AND ROUTING DIAGRAMS
REAR WIPER AND WASHER
