1998 SSANGYONG MUSSO Workshop Repair Manual

FRAME AND UNDERBODY 9N-5
1 Mounting Bolt.......................................28-47 Nm
SKID PLATE
.
2 Skid Plate
Removal & Installation Procedure
1. Remove 6 mounting bolts and carefully remove the skid
plate.
Installation Notice
2. Installation should follow the removal procedure in the
reverse order.
Tightening Torque 28 - 47 Nm

SECTION 9O
BUMPERS AND FASCIAS
TABLE OF CONTENTS
Maintenance and Repair . . . . . . . . . . . . . . . 9O-2
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9O-2Front Bumper . . . . . . . . . . . . . . . . . . . . . . . . . 9O-2
Rear Bumper . . . . . . . . . . . . . . . . . . . . . . . . . 9O-4

9O-2 BUMPERS AND FASCIAS
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
FRONT BUMPER
Notice
Removal and installation is as shown in upper drawings.

BUMPERS AND FASCIAS 9O-3
Mounting Inspection
1. Clearance between the upper bumper and radiator grille.
2. Clearance between the upper bumper and headlamp
moding.
Clearance
12 ± 1.0 mm
Clearance
9 mm
2. Clearance between the bumper and wheel arch.
Clearance
10 mm

9O-4 BUMPERS AND FASCIAS
REAR BUMPER
Notice
Removal and installation is as shown in upper drawings.

BUMPERS AND FASCIAS 9O-5
Mounting Inspection
1. Clearance between the upper bumper facia and tailgate.
2. Clearance between the rear bumper facia and rear bumper
molding.
Clearance
12 ± 1.0 mm
Clearance
11.0 mm
3. Clearance between the quarter outer panel and rear
bumper facia.
Clearance
10.0 mm

SECTION 9P
DOORS
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Schematic and Routing Diagrams . . . . . . . . 9P-2
Power Window . . . . . . . . . . . . . . . . . . . . . . . . 9P-2
Maintenance and Repair . . . . . . . . . . . . . . . 9P-3
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . 9P-3Front Door . . . . . . . . . . . . . . . . . . . . . . . . . . . 9P-3
Rear Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9P-4
Tail Gate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9P-5

9P-2 DOORS
SCHEMATIC AND ROUTING DIAGRAMS
POWER WINDOW
