NISSAN LATIO 2007 Service Repair Manual EM-56Revision: June 2006
CAMSHAFT
2007 Versa
At the same time, make sure that both intake and exhaust
cam noses of No. 1 cylinder face inside ( ) as shown.
If they do not face inside, rotate cranksh

Page 1866 of 2896

NISSAN LATIO 2007 Service Repair Manual CAMSHAFT
EM-57
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
Rotate crankshaft pulley (1) one revolution (360 degrees) and
align TDC mark (no paint) (B) to timing indicator (A) on front
cov

Page 1867 of 2896

NISSAN LATIO 2007 Service Repair Manual EM-58Revision: June 2006
CAMSHAFT
2007 Versa
Thickness of new valve lifter (B) can be identified by stamp
mark (A) on the reverse side (inside the cylinder).
Stamp mark “302” indicates 3.02 mm (0

Page 1868 of 2896

NISSAN LATIO 2007 Service Repair Manual OIL SEAL
EM-59
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
OIL SEALPFP:12279
Removal and Installation of Valve Oil SealEBS00T6H
REMOVAL
1. Remove camshafts. Refer to EM-47, "Components" .

Page 1869 of 2896

NISSAN LATIO 2007 Service Repair Manual EM-60Revision: June 2006
OIL SEAL
2007 Versa
Removal and Installation of Front Oil SealEBS00T6I
REMOVAL
1. Remove the following parts.
Front fender protector (RH); Refer to EI-22, "FENDER PROTECTOR"

Page 1870 of 2896

NISSAN LATIO 2007 Service Repair Manual OIL SEAL
EM-61
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
Removal and Installation of Rear Oil SealEBS00T6J
REMOVAL
1. Remove transaxle assembly. Refer to MT-15, "TRANSAXLE ASSEMBLY" (M/T

Page 1871 of 2896

NISSAN LATIO 2007 Service Repair Manual EM-62Revision: June 2006
CYLINDER HEAD
2007 Versa
CYLINDER HEADPFP:11041
On-Vehicle ServiceEBS00T6K
CHECKING COMPRESSION PRESSURE
1. Warm up engine thoroughly. Then, stop it.
2. Release fuel pressure.

Page 1872 of 2896

NISSAN LATIO 2007 Service Repair Manual CYLINDER HEAD
EM-63
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
If the engine speed is out of the specified range, check battery liquid for proper gravity. Check engine
speed again with n

CYLINDER HEAD
EM-63
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
If the engine speed is out of the specified range, check battery liquid for proper gravity. Check engine
speed again with normal battery gravity.
If compression pressure is below minimum value, check valve clearances and parts associated with
combustion chamber (Valve, valve seat, piston, piston ring, cylinder bore, cylinder head, cylinder head
gasket). After the checking, measure the compression pressure again.
If some cylinder has low compression pressure, pour small amount of engine oil into the spark plug hole
of the cylinder to re-check it for compression.
–If the added engine oil improves the compression, piston rings may be worn out or damaged. Check
piston rings and replace if necessary.
–If the compression pressure remains at low level despite the addition of engine oil, valves may be mal-
functioning. Check valves for damage. Replace valve or valve seat accordingly.
If two adjacent cylinders have respectively low compression pressure and their compression remains
low even after the addition of engine oil, cylinder head gasket is leaking. In such a case, replace cylin-
der head gasket.
9. After inspection is completed, install removed parts.
10. Start the engine, and confirm that the engine runs smoothly.
11. Perform trouble diagnosis. If DTC appears, erase it. Refer to EC-83, "
TROUBLE DIAGNOSIS" .
ComponentsEBS00U7R
Removal and InstallationEBS00U7S
REMOVAL
WA RN ING:
Put a “CAUTION: FLAMMABLE” sign in the workshop.
Be sure to work in a well ventilated area and furnish workshop with a CO2 fire extinguisher.
Do not smoke while servicing fuel system. Keep open flames and sparks away from the work area.
1. Release the fuel pressure. Refer to EC-81, "
FUEL PRESSURE RELEASE" .
2. Drain engine coolant and engine oil. Refer to CO-8, "
ENGINE COOLANT" and LU-5, "ENGINE OIL" .
3. Remove front fender protector (RH). Refer to EI-22, "
FENDER PROTECTOR" .
4. Remove drive belt. Refer to EM-13, "
Removal and Installation" .
5. Remove the following components and related parts.
Exhaust manifold; Refer to EM-21, "EXHAUST MANIFOLD" .
Intake manifold; Refer to EM-18, "INTAKE MANIFOLD" .
Fuel tube and fuel injector assembly; Refer to EM-33, "FUEL INJECTOR AND FUEL TUBE" .
1. Cylinder head assembly 2. Cylinder head bolt 3. Cylinder head gasket
A. Refer to EM-65
PBIC3542J
