Page 1281 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-112Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)100 G ASCD brake switch[Ignition switch: ON]
Brake ped

Page 1282 of 2896

NISSAN LATIO 2007 Service Repair Manual TROUBLE DIAGNOSIS
EC-113
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
CONSULT-II Function (ENGINE)UBS00PKN
FUNCTION
*: The following emission-related diagnostic information is cleared when

Page 1283 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-114Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
ItemDIAGNOSTIC TEST MODE
WORK
SUP-
PORTSELF-DIAGNOSTIC
RESULTS
DATA
MONI-
TORDATA

Page 1284 of 2896

NISSAN LATIO 2007 Service Repair Manual TROUBLE DIAGNOSIS
EC-115
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
X: Applicable
*1: This item includes 1st trip DTCs.
*2: This mode includes 1st trip freeze frame data or freeze frame d

Page 1285 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-116Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip

EC-116Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to EC-48, "EMISSION-RELATED DIAGNOSTIC INFORMA-
TION ITEMS" .
Freeze Frame Data and 1st Trip Freeze Frame Data
EVAP SYSTEM CLOSE CLOSE THE EVAP CANISTER VENT CONTROL VALVE IN
ORDER TO MAKE EVAP SYSTEM CLOSE UNDER THE
FOLLOWING CONDITIONS.
IGN SW “ON”
ENGINE NOT RUNNING
AMBIENT TEMPERATURE IS ABOVE 0°C (32°F).
NO VACUUM AND NO HIGH PRESSURE IN EVAP SYS-
TEM
FUEL TANK TEMP. IS MORE THAN 0°C (32°F).
WITHIN 10 MINUTES AFTER STARTING “EVAP SYS-
TEM CLOSE”
WHEN TRYING TO EXECUTE “EVAP SYSTEM CLOSE”
UNDER THE CONDITION EXCEPT ABOVE, CONSULT-
II WILL DISCONTINUE IT AND DISPLAY APPROPRI-
ATE INSTRUCTION.
NOTE:
WHEN STARTING ENGINE, CONSULT-II MAY DISPLAY
“BATTERY VOLTAGE IS LOW. CHARGE BATTERY”,
EVEN IN USING CHARGED BATTERY.When detecting EVAP vapor leak
point of EVAP system
TARGET IDLE RPM ADJ*
IDLE CONDITION When setting target idle speed
TARGET IGN TIM ADJ*
IDLE CONDITION When adjusting target ignition tim-
ing
VIN REGISTRATION
IN THIS MODE, VIN IS REGISTERED IN ECM. When registering VIN in ECM WORK ITEM CONDITION USAGE
Freeze frame data
item*Description
DIAG TROUBLE
CODE
[PXXXX]
The engine control component part/control system has a trouble code, it is displayed as PXXXX.
(Refer to EC-8, "
INDEX FOR DTC" .)
FUEL SYS-B1
“Fuel injection system status” at the moment a malfunction is detected is displayed.
One mode in the following is displayed.
Mode2: Open loop due to detected system malfunction
Mode3: Open loop due to driving conditions (power enrichment, deceleration enleanment)
Mode4: Closed loop - using oxygen sensor(s) as feedback for fuel control
Mode5: Open loop - has not yet satisfied condition to go to closed loop
CAL/LD VALUE [%]
The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP
[°C] or [°F]
The engine coolant temperature at the moment a malfunction is detected is displayed.
L-FUEL TRM-B1 [%]
“Long-term fuel trim” at the moment a malfunction is detected is displayed.
The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule
than short-term fuel trim.
S-FUEL TRM-B1 [%]
“Short-term fuel trim” at the moment a malfunction is detected is displayed.
The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel
schedule.
ENGINE SPEED
[rpm]
The engine speed at the moment a malfunction is detected is displayed.
VEHICL SPEED
[km/h] or [mph]
The vehicle speed at the moment a malfunction is detected is displayed.

Page 1286 of 2896

NISSAN LATIO 2007 Service Repair Manual TROUBLE DIAGNOSIS
EC-117
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*: The items are the same as those of 1st trip freeze frame data.
DATA MONITOR MODE
Monitored Item
×: Applicable ABSOL

TROUBLE DIAGNOSIS
EC-117
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*: The items are the same as those of 1st trip freeze frame data.
DATA MONITOR MODE
Monitored Item
×: Applicable ABSOL TH-P/S [%]
The throttle valve opening angle at the moment a malfunction is detected is displayed.
B/FUEL SCHDL
[msec]
The base fuel schedule at the moment a malfunction is detected is displayed.
INT/A TEMP SE
[°C] or [°F]
The intake air temperature at the moment a malfunction is detected is displayed.
FUEL SYS-B2
Always “0” is displayed. L-FUEL TRM-B2 [%]
S-FUEL TRM-B2 [%]
INT MANI PRES [kPa]
FTFMCH1Freeze frame data
item*Description
Monitored item [Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSDescription Remarks
ENG SPEED [rpm]××
Indicates the engine speed computed from the
signals of the crankshaft position sensor
(POS) and camshaft position sensor (PHASE).
Accuracy becomes poor if engine
speed drops below the idle rpm.
If the signal is interrupted while
the engine is running, an abnor-
mal value may be indicated.
MAS A/F SE-B1 [V]××
The signal voltage of the mass air flow sensor
is displayed.When the engine is stopped, a
certain value is indicated.
B/FUEL SCHDL
[msec]×
“Base fuel schedule” indicates the fuel injec-
tion pulse width programmed into ECM, prior
to any learned on board correction.
A/F ALPHA-B1 [%]×
The mean value of the air-fuel ratio feedback
correction factor per cycle is indicated.
When the engine is stopped, a
certain value is indicated.
This data also includes the data
for the air/fuel ratio learning con-
trol.
COOLAN TEMP/S
[°C] or [°F]××
The engine coolant temperature (determined
by the signal voltage of the engine coolant
temperature sensor) is displayed.
When the engine coolant temper-
ature sensor is open or short-cir-
cuited, ECM enters fail-safe
mode. The engine coolant tem-
perature determined by the ECM
is displayed.
A/F SEN1 (B1) [V]××
The A/F signal computed from the input signal
of the A/F sensor 1 is displayed.
HO2S2 (B1) [V]×
The signal voltage of the heated oxygen sen-
sor 2 is displayed.
HO2S2 MNTR (B1)
[RICH/LEAN]×
Display of heated oxygen sensor 2 signal:
RICH: means the amount of oxygen after three
way catalyst is relatively small.
LEAN: means the amount of oxygen after
three way catalyst is relatively large.
When the engine is stopped, a
certain value is indicated.
VHCL SPEED SE
[km/h] or [mph]××
The vehicle speed computed from the vehicle
speed signal is displayed.
BATTERY VOLT [V]××
The power supply voltage of ECM is dis-
played.

Page 1287 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-118Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
ACCEL SEN 1 [V]××
The accelerator pedal position sensor signal
voltage is displayed.
ACCEL SEN 2 signal is con-
verted by ECM internally. Th

EC-118Revision: June 2006
TROUBLE DIAGNOSIS
2007 Versa
ACCEL SEN 1 [V]××
The accelerator pedal position sensor signal
voltage is displayed.
ACCEL SEN 2 signal is con-
verted by ECM internally. Thus, it
differs from ECM terminal voltage
signal. ACCEL SEN 2 [V]×
THRTL SEN 1 [V]××
The throttle position sensor signal voltage is
displayed.
THRTL SEN 2 signal is con-
verted by ECM internally. Thus, it
differs from ECM terminal voltage
signal. THRTL SEN 2 [V]×
FUEL T/TMP SE
[°C] or [°F]×
The fuel temperature (determined by the sig-
nal voltage of the fuel tank temperature sen-
sor) is displayed.
INT/A TEMP SE
[°C] or [°F]××
The intake air temperature (determined by the
signal voltage of the intake air temperature
sensor) is indicated.
EVAP SYS PRES [V]×
The signal voltage of EVAP control system
pressure sensor is displayed.
FUEL LEVEL SE [V]×
The signal voltage of the fuel level sensor is
displayed.
START SIGNAL
[ON/OFF]××
Indicates start signal status [ON/OFF] com-
puted by the ECM according to the signals of
engine speed and battery voltage.After starting the engine, [OFF] is
displayed regardless of the
starter signal.
CLSD THL POS
[ON/OFF]××
Indicates idle position [ON/OFF] computed by
the ECM according to the accelerator pedal
position sensor signal.
AIR COND SIG*
[ON/OFF]××
Indicates [ON/OFF] condition of the air condi-
tioner switch as determined by the air condi-
tioner signal.
P/N POSI SW
[ON/OFF]××
Indicates [ON/OFF] condition from the park/
neutral position (PNP) switch signal.
PW/ST SIGNAL
[ON/OFF]××
[ON/OFF] condition of the power steering sys-
tem (determined by the signal sent from EPS
control unit) is indicated.
LOAD SIGNAL
[ON/OFF]××
Indicates [ON/OFF] condition from the electri-
cal load signal.
ON: Rear window defogger switch is ON and/
or lighting switch is in 2nd position.
OFF: Both rear window defogger switch and
lighting switch are OFF.
IGNITION SW
[ON/OFF]×
Indicates [ON/OFF] condition from ignition
switch.
HEATER FAN SW
[ON/OFF]×
Indicates [ON/OFF] condition from the heater
fan switch signal.
BRAKE SW
[ON/OFF]×
Indicates [ON/OFF] condition from the stop
lamp switch signal.
INJ PULSE-B1
[msec]×
Indicates the actual fuel injection pulse width
compensated by ECM according to the input
signals.When the engine is stopped, a
certain computed value is indi-
cated.
IGN TIMING [BTDC]
Indicates the ignition timing computed by ECM
according to the input signals.When the engine is stopped, a
certain value is indicated.
CAL/LD VALUE [%]
“Calculated load value” indicates the value of
the current airflow divided by peak airflow.
MASS AIRFLOW
[g·m/s]
Indicates the mass airflow computed by ECM
according to the signal voltage of the mass air
flow sensor. Monitored item [Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSDescription Remarks

Page 1288 of 2896

NISSAN LATIO 2007 Service Repair Manual TROUBLE DIAGNOSIS
EC-119
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
PURG VOL C/V [%]
Indicates the EVAP canister purge volume
control solenoid valve control value computed
by the ECM a

TROUBLE DIAGNOSIS
EC-119
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
PURG VOL C/V [%]
Indicates the EVAP canister purge volume
control solenoid valve control value computed
by the ECM according to the input signals.
The opening becomes larger as the value
increases.
INT/V TIM (B1) [°CA]
Indicates [°CA] of intake camshaft advanced
angle.
INT/V SOL (B1) [%]
The control value of the intake valve timing
control solenoid valve (determined by ECM
according to the input signal) is indicated.
The advance angle becomes larger as the
value increases
AIR COND RLY*
[ON/OFF]×
The air conditioner relay control condition
(determined by ECM according to the input
signals) is indicated.
FUEL PUMP RLY
[ON/OFF]×
Indicates the fuel pump relay control condition
determined by ECM according to the input sig-
nals.
VENT CONT/V [ON/
OFF]
The control condition of the EVAP canister
vent control valve (determined by ECM
according to the input signals) is indicated.
ON: Closed
OFF: Open
THRTL RELAY
[ON/OFF]×
Indicates the throttle control motor relay con-
trol condition determined by the ECM accord-
ing to the input signals.
COOLING FAN
[HI/LOW/OFF]×
Indicates the condition of the cooling fan
(determined by ECM according to the input
signals).
HI: High speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1)
[ON/OFF]
Indicates [ON/OFF] condition of heated oxy-
gen sensor 2 heater determined by ECM
according to the input signals.
I/P PULLY SPD
[rpm]
Indicates the engine speed computed from the
turbine revolution sensor signal.
VEHICLE SPEED
[km/h] or [MPH]×
The vehicle speed computed from the vehicle
speed signal sent from TCM is displayed.
IDL A/V LEARN
[YET/CMPLT]
Display the condition of idle air volume learn-
ing
YET: Idle Air Volume Learning has not been
performed yet.
CMPLT: Idle Air Volume Learning has already
been performed successfully.
TRVL AFTER MIL
[km] or [mile]
Distance traveled while MIL is activated.
A/F S1 HTR (B1) [%]
Indicates A/F sensor 1 heater control value
computed by ECM according to the input sig-
nals.
The current flow to the heater becomes larger
as the value increases.
AC PRESS SEN [V]*×
The signal voltage from the refrigerant pres-
sure sensor is displayed. Monitored item [Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSDescription Remarks

Load next 8 pages

Page: < prev 1-10 ... 1249-1256 1257-1264 1265-1272 1273-1280 1281-1288 1289-1296 1297-1304 1305-1312 1313-1320 ... 2896 next >

display headlight bulb brake climate control jump start mirror controls
