Page 2377 of 2896

NISSAN LATIO 2007 Service Repair Manual TRANSAXLE ASSEMBLY MT-15 D E F G H I J K L MA B MT Revision: June 20062007 Versa TRANSAXLE ASSEMBLYPFP:32010 Removal and InstallationUCS005LQ CAUTION: If transaxle assembly is removed from the vehicle

Page 2378 of 2896

NISSAN LATIO 2007 Service Repair Manual MT-16 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa If transaxle is removed from the vehicle, always replace CSC. Refer to CL-11, "Removal and Installation" . When installing the transaxle assemb

Page 2379 of 2896

NISSAN LATIO 2007 Service Repair Manual TRANSAXLE ASSEMBLY MT-17 D E F G H I J K L MA B MT Revision: June 20062007 Versa Disassembly and AssemblyUCS005LR COMPONENTS Case and Housing Components 1. Filler plug 2. Gasket 3. Transaxle case 4. B

Page 2380 of 2896

NISSAN LATIO 2007 Service Repair Manual MT-18 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa Gear Components 1. Input shaft front bearing 2. Input shaft 3. 3rd input gear 4. Washer 5. Snap ring 6. 3rd baulk ring 7. 3rd-4th coupling sleeve

Page 2381 of 2896

NISSAN LATIO 2007 Service Repair Manual TRANSAXLE ASSEMBLY MT-19 D E F G H I J K L MA B MT Revision: June 20062007 Versa 1. Main shaft front bearing outer race2. Main shaft front bearing inner race 3. Main shaft 4. 1st main gear 5. 1st inn

Page 2382 of 2896

NISSAN LATIO 2007 Service Repair Manual MT-20 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa 1. Reverse output gear 2. Snap ring 3. Reverse baulk ring 4. Return spring 5. Needle bearing 6. Reverse idler shaft 7. Seal washer 8. Washer 9. R

Page 2383 of 2896

NISSAN LATIO 2007 Service Repair Manual TRANSAXLE ASSEMBLY MT-21 D E F G H I J K L MA B MT Revision: June 20062007 Versa Shift Control Components 1. Reverse fork rod 2. Selector 3. Retaining pin 4. 5th-6th shift fork 5. 3rd-4th shift fork

Page 2384 of 2896

NISSAN LATIO 2007 Service Repair Manual MT-22 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa Final Drive Components 1. Side gear 2. Pinion mate gear 3. Thrust washer 4. Pinion mate shaft 5. shim 6. Differential side bearing outer race (t
