GI-18
HOW TO USE THIS MANUAL
Revision: June 20062007 Versa
14 Wire color
This shows a code for the color of the wire.
B = Black
W = White
R = Red
G = Green
L = Blue
Y = Yellow
LG = Light GreenBR = Brown
OR or O = Orange
P = Pink
PU or V (Violet) = Purple
GY or GR = Gray
SB = Sky Blue
CH = Dark Brown
DG = Dark Green
When the wire color is striped, the base color is given first, followed by the stripe color as shown
below:
Example: L/W = Blue with White Stripe
15 Option description
This shows a description of the option abbreviation used on the page.
16 Switch
This shows that continuity exists between terminals 1 and 2 when the switch is in the A posi-
tion. Continuity exists between terminals 1 and 3 when the switch is in the B position.
17 Assembly parts
Connector terminal in component shows that it is a harness incorporated assembly.
18 Cell code
This identifies each page of the wiring diagram by section, system and wiring diagram page
number.
19 Current flow arrow
Arrow indicates electric current flow, especially where the direction of standard flow (vertically
downward or horizontally from left to right) is difficult to follow.
A double arrow “ ” shows that current can flow in either direction depending on cir-
cuit operation.
20 System branch
This shows that the system branches to another system identified by cell code (section and
system).
21 Page crossing
This arrow shows that the circuit continues to another page identified by cell code.
The C will match with the C on another page within the system other than the next or preced-
ing pages.
22 Shielded line
The line enclosed by broken line circle shows shield wire.
23Component box in
wave line
This shows that another part of the component is also shown on another page (indicated by
wave line) within the system.
24 Component name
This shows the name of a component.
25 Connector number
This shows the connector number.
The letter shows which harness the connector is located in.
Example: M : main harness. For detail and to locate the connector, refer to PG section "Main
Harness", “Harness Layout”. A coordinate grid is included for complex harnesses to aid in
locating connectors.
26 Ground (GND)
The line spliced and grounded under wire color shows that ground line is spliced at the
grounded connector.
27 Ground (GND)
This shows the ground connection. For detailed ground distribution information, refer to
"Ground Distribution" in PG section.
28 Connector views
This area shows the connector faces of the components in the wiring diagram on the page.
29 Common component
Connectors enclosed in broken line show that these connectors belong to the same compo-
nent.
30 Connector color
This shows a code for the color of the connector. For code meaning, refer to wire color codes,
Number 14 of this chart.
31Fusible link and fuse
box
This shows the arrangement of fusible link(s) and fuse(s), used for connector views of
"POWER SUPPLY ROUTING" in PG section.
The open square shows current flow in, and the shaded square shows current flow out.
32 Reference area
This shows that more information on the Super Multiple Junction (SMJ) and Joint Connectors
(J/C) exists on the PG section. Refer to "Reference Area" for details. Num-
berItem Description
Page 2097 of 2896
IDX-4
ALPHABETICAL INDEX
EC-398, EC-406
EVAP control system pressure sensor .... EC-382, EC-
385, EC-391
EVAP control system purge flow monitoring diagnosis
EC-340
EVAP vapor lines inspection ............................. MA-19
Evaporative emission (EVAP) system ............... EC-31
Evaporator ...................................................... MTC-90
Exhaust manifold .............................................. EM-21
Exhaust system inspection ................... MA-20, MA-22
Expansion valve .............................................. MTC-91
F
F/FOG - Wiring diagram ..................................... LT-43
F/PUMP - Wiring diagram ................................ EC-571
Final drive (FF M/T) ........................................... MT-22
Floor trim ............................................................. EI-37
Flow charts ......................................................... GI-27
Fluid temparature sensor (CVT) ...................... CVT-85
Fluid temperature sensor (A/T) ........................ AT-106
Fluids ................................................................ MA-11
Fluorescent leak detector ............................... MTC-92
Flywheel (clutch) ................................................ CL-13
Flywheel runout .............................................. EM-103
Fork rod (M/T) .................................................... MT-21
Freeze frame data ............................... EC-52, EC-116
Front bumper ...................................................... EI-14
Front door ......................................................... GW-43
Front passenger air bag .................................. SRS-46
Front seat belt ...................................................... SB-3
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-51
Front washer ...................................................... WW-4
Front wiper ......................................................... WW-4
FTS - Wiring diagram ......................... AT-103, CVT-86
FTTS - Wiring diagram ...................... EC-293, EC-298
FUEL - Wiring diagram ...................... EC-278, EC-286
Fuel cut control (at no load high engine speed) . EC-26
Fuel gauge ............................................................ DI-5
Fuel injection system ......................... EC-276, EC-284
Fuel injector ..................................................... EC-564
Fuel injector and fuel tube ................................ EM-33
Fuel level sensor ................. EC-415, EC-417, EC-419
Fuel line inspection .................................. FL-4, MA-15
Fuel precautions ................................................... GI-6
Fuel pressure check .......................................... EC-81
Fuel pressure release ........................................ EC-81
Fuel pump ........................................................ EC-570
Fuel systemCommercial Service Tools ................ FL-3
Fuel systemPREPARATION ................................. FL-3
Fuel tank temperature sensor ............ EC-291, EC-297
Fuel tank vacuum relief valve ............................ EC-34
Fuse ................................................................... PG-16
Fuse and fusible link box ................................... PG-77
Fusible link ......................................................... PG-16
G
Gauges ................................................................. DI-5
Gear components (M/T) .................................... MT-18
Generic scan tool (GST) ................................. EC-126
Glass ...................................... GW-11, GW-43, GW-47
Grille - See Exterior ............................................. EI-19
Ground distribution ............................................ PG-30
H
H/LAMP - Wiring diagram .................................... LT-8
H/PHON - Wiring diagram .................................. AV-52
Handling precautions for plastics ..................... BL-255
Harness connector ............................................ PG-68
Harness layout .................................................. PG-39
Hazard warning lamp ......................................... LT-51
Headlining - See Roof trim .................................. EI-39
Heated oxygen sensor 2 ..... EC-248, EC-257, EC-267
Heated oxygen sensor 2 heater ...................... EC-166
HEATER - Wiring diagram .............................. MTC-28
Heater system - Wiring diagram ..................... MTC-28
HFC134a (R134a) system precaution .............. MTC-4
HFC134a (R134a) system service procedure . MTC-80
HFC134a (R134a) system service tools ......... MTC-12
HFC134a system service equipment precaution MTC-9
HO2S2 - Wiring diagram ..... EC-251, EC-260, EC-270
HO2S2H - Wiring diagram .............................. EC-168
Horn ................................................................. WW-46
HORN - Wiring diagram ................................... WW-46
How to erase DTC for OBD system .................. EC-60
I
IATS - Wiring diagram ..................................... EC-197
Idle air volume learning ..................................... EC-78
Idle speed ......................................................... EC-75
Idle speed control (ISC) .................... EC-423, EC-425
Ignition coil ...................................................... EC-576
Ignition control system .................................... EC-576
Ignition timing .................................................... EC-75
IGNSYS - Wiring diagram ............................... EC-577
ILL - Wiring diagram ......................................... LT-111
Illumination control ........................................... LT-108
In-cabin Microfilter ............................................. MA-20
INJECT - Wiring diagram ................................ EC-565
Input shaft (FF M/T) .......................................... MT-18
Input/Output signal of TCM ............................. CVT-25
Instrument panel ................................................. IP-10
INT/L - Wiring diagram ....................................... LT-96
Intake air temperature sensor ........... EC-195, EC-215
Intake door control linkage adjustment ........... MTC-69
Intake manifold .................................................. EM-18
Intake valve timing control .............................. EC-156
Intake valve timing control solenoid valve ....... EC-173
Interior ................................................................. EI-32
Interior lamp ....................................................... LT-91
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-17
IVC - Wiring diagram ....................................... EC-174
