Page 1625 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-456Revision: June 2006 DTC P1217 ENGINE OVER TEMPERATURE 2007 Versa 11 . CHECK MAIN 13 CAUSES If the cause cannot be isolated, go to EC-458, " Main 13 Causes of Overheating" . >>INSPECTION END PRO

Page 1626 of 2896

NISSAN LATIO 2007 Service Repair Manual DTC P1217 ENGINE OVER TEMPERATURE EC-457 C D E F G H I J K L MA EC Revision: June 20062007 Versa 3. CHECK COOLING FAN MOTOR CIRCUIT 1. Disconnect cooling fan motor harness connector (1). –: Vehicle

Page 1627 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-458Revision: June 2006 DTC P1217 ENGINE OVER TEMPERATURE 2007 Versa Main 13 Causes of OverheatingUBS00QKZ *1: Turn the ignition switch ON. *2: Engine running at 3,000 rpm for 10 minutes. *3: Drive

Page 1628 of 2896

NISSAN LATIO 2007 Service Repair Manual DTC P1217 ENGINE OVER TEMPERATURE EC-459 C D E F G H I J K L MA EC Revision: June 20062007 Versa Component InspectionUBS00QL0 COOLING FAN MOTOR Model with A/C 1. Disconnect cooling fan motor harness c

Page 1629 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-460Revision: June 2006 DTC P1225 TP SENSOR 2007 Versa DTC P1225 TP SENSORPFP:16119 Component DescriptionUBS00QL1 Electric throttle control actuator consists of throttle control motor, throttle posi

Page 1630 of 2896

NISSAN LATIO 2007 Service Repair Manual DTC P1225 TP SENSOR EC-461 C D E F G H I J K L MA EC Revision: June 20062007 Versa Diagnostic ProcedureUBS00QL4 1. CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY 1. Turn ignition switch OFF. 2. Rem

Page 1631 of 2896

NISSAN LATIO 2007 Service Repair Manual EC-462Revision: June 2006 DTC P1226 TP SENSOR 2007 Versa DTC P1226 TP SENSORPFP:16119 Component DescriptionUBS00QL6 Electric throttle control actuator consists of throttle control motor, throttle posi

Page 1632 of 2896

NISSAN LATIO 2007 Service Repair Manual DTC P1226 TP SENSOR EC-463 C D E F G H I J K L MA EC Revision: June 20062007 Versa Diagnostic ProcedureUBS00QL9 1. CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY 1. Turn ignition switch OFF. 2. Rem
