Page 1689 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 99
DAEWOO V–121 BL4
FLUID COOLER FLUSHING
Flushing Procedure
1. Drain the fluid from the transaxle and refill the
transaxle with new transaxle fluid. Refer to ”Fluid
Drain Procedure” in this section.
2. Let the engine idle for 5 minutes.
3. Drain the fluid from the transaxle and refill the
transaxle with new transaxle fluid. Refer to ”Fluid
Drain Procedure” in this section.
CONTROL CABLE ADJUSTMENT
Adjustment Procedure
The various shift control cable positions must match at the
shift control lever in the vehicle and at the selector lever
on the transaxle to provide proper transaxle shifting.
Place the shift control lever in the PARK position and
check the selector lever connection to verify that it is in the
forward most position. If it is not, the following adjustment
must be performed:
1. Disconnect the negative battery cable.
2. Remove the floor console. Refer to Section 9G,
Interior Trim.
3. Place the shift control lever in the PARK position.
4. Loosen the control cable adjusting nut.
5. Move the Transmission Range (TR) switch lever
counterclockwise until stopping the lever.
Page 1690 of 2643
5A2 – 100IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
6. Pull the shift control cable until it is tight and tighten
the control cable adjusting nut.
Tighten
Tighten the control cable adjusting nut to 8 NSm (71
Ib–in).
7. Install the floor console. Refer to Section 9G, Interi-
or Trim.
8. Connect the negative battery cable.
SHIFT CONTROL LEVER ASSEMBLY
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the floor console. Refer to Section 9G,
Interior Trim.
3. Disconnect the wiring harness connectors from the
shift control lever.
4. Loosen the control cable adjusting nut.
5. Disconnect the control cable from the shift control
lever assembly.
6. Remove the shift control lever assembly mounting
bolts and nuts.
7. Remove the shift control lever assembly.
Page 1691 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 101
DAEWOO V–121 BL4
Installation Procedure
1. Install the shift control lever assembly and mount-
ing bolts and nuts.
Tighten
Tighten the shift control lever assembly mounting
bolts and nuts to 8 NSm (71 Ib–in).
2. Connect the control cable to the shift control lever
assembly.
3. Tighten the control cable adjusting nut.
Tighten
Tighten the control cable adjusting nut to 8 NSm (71
Ib–in).
4. Connect the harness connector.
5. Adjust the control cable. Refer to ”Control Cable
Adjustment” in this section.
6. Install the floor console. Refer to Section 9G, Interi-
or Trim.
7. Connect the negative battery cable.
TRANSMISSION RANGE (TR)
SWITCH
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the Transmission Range (TR) switch
electrical connector from the wiring harness.
Page 1692 of 2643
5A2 – 102IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
3. Remove the E–ring.
4. Disconnect the shift control cable from the TR
switch lever.
5. Remove the retaining nut and then remove the
washer and the control lever.
6. Using a driver, unstake the lock washer and re-
move the nut.
Installation Procedure
1. Install the Transmission Range (TR) switch onto the
manual valve lever shaft and temporarily install the
2 adjusting bolts.
2. Install the new lock washer and nuts.
Tighten
Tighten the nuts to 12 NSm (106 Ib–in).
3. Temporarily install the control lever.
4. Turn the lever counterclockwise until it stops, then
turn it clockwise 2 notches.
5. Remove the control lever.
Page 1693 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 103
DAEWOO V–121 BL4
6. Aligh the groove with the neutral basic line, then
install the 2 bolts.
Tighten
Tighten the 2 bolts to 5.4 NSm (48 Ib–in).
7. Using a screw driver, stake the nut with the lock
washer.
8. Install the control lever, washer and nut.
Tighten
Tighten the nut to 12 NSm (106 Ib–in).
9. Connect the control cable to TR switch.
10. Connect the TR switch electrical connector.
11. Adjust the control cable. Refer to ”Control Cable
Adjustment” in this section.
12. Install the control cable adjusting nut.
Tighten
Tighten the control cable adjusting nut to 8 NSm (71
Ib–in).
13. Connect the negative battery cable.
Page 1694 of 2643
5A2 – 104IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
SHIFT CONTROL CABLE
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the floor console. Refer to Section 9G,
Interior Trim.
3. Remove the cable adjusting nut.
4. Disconnect the shift control cable from the shift
control lever assembly.
5. Remove the shift control cable retaining E–ring.
6. Disconnect the shift control cable from the TR
switch.
7. Remove the E–ring from the shift control cable
bracket and disconnect the shift control cable.
8. Disconnect the shift control cable from the shift
control cable fastener.
9. Remove the shift control cable from the vehicle.
Installation Procedure
1. Install the shift control cable to the vehicle.
2. Connect the shift control cable to the shift control
cable fastener.
3. Install the E–ring to the shift control cable bracket
and connect the shift control cable.
Page 1695 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 105
DAEWOO V–121 BL4
4. Connect the shift control cable to the TR switch.
5. Install the shift control cable retaining E–ring.
6. Connect the shift control cable to the shift control
lever assembly.
7. Install the cable adjusting nut.
Tighten
Tighten the cable adjusting nut to 8 NSm (71 Ib–in).
8. Install the trim panel to the floor console. Refer to
Section 9G, Interior Trim.
9. Connect the negative battery cable.
SHIFT SELECT COVER
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the floor console. Refer to Section 9G,
Interior Trim.
3. Remove the shift select lever knob.
4. Disconnect the connectors.
5. Remove the shift select cover from the shift select
housing.
Page 1696 of 2643
5A2 – 106IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Installation Procedure
1. Connect the connectors to the shift select cover.
2. Install the shift select cover to the housing.
3. Install the shift select lever knob.
4. Install the floor console. Refer to Section 9G, Interi-
or Trim.
5. Connect the negative battery cable.
INPUT SHAFT SPEED (ISS) SENSOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the input shaft speed (ISS) sensor elec-
trical connector.
3. Remove the ISS sensor retaining bolt.
4. Remove the ISS sensor from the transaxle.
