DAEWOO LACETTI 2004 Service Repair Manual 5A1 – 212IZF 4 HP 16 AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 UNIT REPAIR TORQUE CONVERTER Disassembly and Assembly Procedure 1. Remove the transaxle assembly. Refer to ”Trans- axle Assembly” in

Page 1562 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 213 DAEWOO V–121 BL4 3. Remove valve body fixing bolts and transaxle input speed sensor bolt on the valve body. 4. Remove the holder for the transaxle input

Page 1563 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A1 – 214IZF 4 HP 16 AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 CLUTCH B/E Tools Required DW260–140 Clutch B Stop Ring Remover/Installer DW260–150 Clutch B Stop Ring Remover/Installer Disassembly an

Page 1564 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 215 DAEWOO V–121 BL4 7. Take out the piston B. 8. Remove disc set B. 9. Take out the piston rings. Removal Notice S Remove the rectangular–section ring

Page 1565 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A1 – 216IZF 4 HP 16 AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 11. Take out the snap ring. 12. Remove disc set E. 13. Press down cup spring(clutch E) with cup spring press fixture. 14. Remove the s

Page 1566 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 217 DAEWOO V–121 BL4 17. Press down cup spring(clutch B)with cup spring press fixture. 18. Remove the split stop ring. 19. Remove the cup spring. 20. Inst

Page 1567 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A1 – 218IZF 4 HP 16 AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Tools Required DW260–090 Clutch B/E (snap ring play, installation space) Measuring Fixture Measuring Installation Space, Clutch B (EB) 1

Page 1568 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 219 DAEWOO V–121 BL4 Tools Required DW260–100 Brake B/E Disc Thickness Measuring Fixture Determining Adjusting Disc B(PB) 1. Using disc thickness gauge, de
