DAEWOO LACETTI 2004 Service Repair Manual DOORS 9P – 29
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
DOOR LOCK STRIKER
The front and the rear door lock strikers each consist of a
striker with two screws threaded into a float

DOORS 9P – 29
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
DOOR LOCK STRIKER
The front and the rear door lock strikers each consist of a
striker with two screws threaded into a floating cage plate
in the B–pillars and the C–pillars. The door is secured in
the closed position when the door lock fork snaps over and
engages the striker.
CHILDPROOF REAR DOOR LOCK
The childproof rear door locks help prevent passengers,
especially children, from opening the rear doors of the ve-
hicle from the inside.
To activate the locks, move the levers of both rear doors
to the lock position. Then, close both doors. The rear pas-
sengers will be unable to open the doors from inside of the
vehicle.
To deactivate the locks, unlock the door from the inside of
the vehicle and open the door from the outside. Move the
lever to the unlock position. The rear door will now work
normally.
POWER DOOR LOCKS
The power door locks use a solenoid that is contained in
each door lock assembly. The door locks are activated by
the actuator on the inside door handle or by the lock cylin-
der on the driver’s side door only. When the driver’s side
door is locked or unlocked by the actuator or the lock cylin-
der, all doors are locked or unlocked accordingly.
POWER WINDOWS
The power windows are controlled by electrical switches
on the door panels and are operated by a motor at each
window regulator. Each door has a switch to control its
window, and the driver’s side door has four switches to
control all door windows on the vehicle. The windows are
lowered by pressing the switch and raised by pulling up on
the switch. The window will stop movement when the
switch is released or when the window is completely open
or closed.
The driver’s side window opens automatically. By pressing
and releasing the switch, the driver ’s side window will low-
er and will stop only when the switch is activated again, or
when the window is completely open.
The driver’s side door control also contains a window lock
button that will prevent the operation of the front passen-
ger door or the rear door windows when pressed.

Page 2450 of 2643

DAEWOO LACETTI 2004 Service Repair Manual SECTION : 9Q
ROOF
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical ter

SECTION : 9Q
ROOF
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9Q–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9Q–2. . . . . . . . . . .
SPECIAL TOOLS9Q–2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools Table 9Q–2. . . . . . . . . . . . . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9Q–3 . . . . .
Power Sunroof System 9Q–3. . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS9Q–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sunroof 9Q–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9Q–6 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9Q–6. . . . . . . . . . . . . . . . . . . . .
Power Sunroof 9Q–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun Shade 9Q–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sunroof Glass 9Q–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Formed Headliner 9Q–8. . . . . . . . . . . . . . . . . . . . . . . . .
Sun Visors with Vanity Mirror 9Q–10. . . . . . . . . . . . . . .
Passenger Assist Handles 9Q–10. . . . . . . . . . . . . . . . .
Power Sunroof Control Switch 9Q–11. . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9Q–12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Roof 9Q–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sunroof/Sunroof Control Switch 9Q–12. . . . . .
Sun Visors with Vanity Mirror 9Q–12. . . . . . . . . . . . . . .
Passenger Assist Handles 9Q–12. . . . . . . . . . . . . . . . .
Coat Hooks 9Q–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Page 2451 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 9Q – 2IROOF
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Power Sunroof Control Switch Screws2–18
Passenger Assist Handle Screws3–27
Sun Visor

Page 2452 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ROOF 9Q – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
POWER SUNROOF SYSTEM

Page 2453 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 9Q – 4IROOF
DAEWOO V–121 BL4
DIAGNOSIS
POWER SUNROOF
Power Sunroof Does Not Work
StepActionValue(s)YesNo
1Check fuse F8.
Is either fuse blown?–Go to Step 2Go to Step 3
21. Check for a short cir

Page 2454 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ROOF 9Q – 5
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
10Repair the open circuit between the interior courtesy
lamp/power sunroof control switch and the sunroof
module connector.
Is the repair c

Page 2455 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 9Q – 6IROOF
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
POWER SUNROOF
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the headliner. Refer to ”Formed Hea

Page 2456 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ROOF 9Q – 7
DAEWOO V–121 BL4
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent prematur
