DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 139 DAEWOO V–121 BL4 9. Using transaxle housing oil seal installer DW260–031–01 and a hammer, drive in a new transaxle housing oil seal. S Oil seal in depth:

Page 1730 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 140IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 14. Install the shim to the transaxle case. Notice : First install a shim of the same thickness as be- fore. 15. Install a new bearing outer

Page 1731 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 141 DAEWOO V–121 BL4 20. Install the differential gear to the transaxle case. 21. Install the transaxle housing and tighten the 16 bolts of the transaxle housing

Page 1732 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 142IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 25. Remove the transaxle housing and install the counter driven gear. 26. Install the transaxle housing and tighten the 16 bolts of the trans

Page 1733 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 143 DAEWOO V–121 BL4 If the preload of counter driven gear does not satisfy the specification, select the adjuster shim from the table below and remeasure the valv

Page 1734 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 144IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 32. Coat 2 new O–rings with ATF, install them to the 1st & reverse piston. 33. Install the 1st & reverse brake piston to the trans- axle ca

Page 1735 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 145 DAEWOO V–121 BL4 36. Using 1st & reverse brake adapter DW240–070 and brake spring compressor bolt/nut DW240–060–01, install the snap ring. Notice : Make

Page 1736 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 146IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 41. Install the parking lock rod to the manual valve le- ver. 42. Install a new spacer to the manual valve lever. 43. Install the manual val
