EXTERIOR TRIM 9M – 3
DAEWOO V–121 BL4
Installation Procedure
1. Press the roof molding onto the metal clips.
MUD GUARDS
Removal Procedure
1. Remove the screw and the bolts and the mud
guard.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the mud guard with the bolts and the screw.
Tighten
Tighten the mud guard bolts to 2 NSm (18 lb–in).
J4D39M01
HATCHBACK REAR SPOILER
Removal Procedure
1. Open the tailgate.
2. Remove the Hatchback Door upper Garnish mold-
ing.
3. Remove the rear spoiler from the tailgate.
Page 2402 of 2643
9M – 4IEXTERIOR TRIM
DAEWOO V–121 BL4
J4D39M01
Installation Procedure
1. Install the rear spoiler on the tailgate with the nuts.
Page 2403 of 2643
EXTERIOR TRIM 9M – 5
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
EMBLEMS AND LETTERING
The emblems and lettering on the vehicle are attached by
adhesive. The company emblem appears on the hood.
The lettering, which appears in several places on the body
of the vehicle, features the model, the grade, and the com-
pany name.
MUD GUARDS
Front and rear mud guards are standard equipment on all
models. Mud guards will help prevent an excessive build-
up of mud on the body.
Page 2404 of 2643
SECTION : 9N
FRAME AND UNDERBODY
TABLE OF CONTENTS
SPECIFICATIONS9N–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9N–1. . . . . . . . . . .
Notchback Underbody Dimensions 9N–2. . . . . . . . . . .
Hatchback Underbody Dimensions 9N–4. . . . . . . . . . .
MAINTENANCE AND REPAIR9N–6 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9N–6. . . . . . . . . . . . . . . . . . . . . Alignment Checking 9N–6. . . . . . . . . . . . . . . . . . . . . . . .
Floor Pan Insulators 9N–6. . . . . . . . . . . . . . . . . . . . . . . .
Engine Under Covers 9N–7. . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9N–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Body Construction 9N–8. . . . . . . . . . . . . . . . .
Engine Under Covers 9N–8. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Engine Under Cover Bolts3.5–31
Page 2405 of 2643
9N – 2IFRAME AND UNDERBODY
DAEWOO V–121 BL4
NOTCHBACK UNDERBODY DIMENSIONS
Page 2406 of 2643
FRAME AND UNDERBODY 9N – 3
DAEWOO V–121 BL4
Page 2407 of 2643
9N – 4IFRAME AND UNDERBODY
DAEWOO V–121 BL4
HATCHBACK UNDERBODY DIMENSIONS
