2004 DAEWOO LACETTI Service Repair Manual

airbag check engine door lock fuel tank removal reset tire type

Load previous 8 pages

Page 937 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 2C – 20IFRONT SUSPENSION
DAEWOO V–121 BL4
6. Install the crossmember link–to–transaxle bracket
nut.
Tighten
Tighten the crossmember link–to–transaxle bracket
nut to 169 NSm (125 lb–ft).

Page 938 of 2643

DAEWOO LACETTI 2004 Service Repair Manual FRONT SUSPENSION 2C – 21
DAEWOO V–121 BL4
UNIT REPAIR
BALL JOINT
Disassembly Procedure
1. Remove the control arm. Refer to ”Control Arm” in
this section.
2. Drill off the heads of the two

Page 939 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 2C – 22IFRONT SUSPENSION
DAEWOO V–121 BL4
Assembly Procedure
1. Press the control arm rear damping bushing into
the control arm using a press and the remover/in-
staller KM–158.
2. Install the

Page 940 of 2643

DAEWOO LACETTI 2004 Service Repair Manual FRONT SUSPENSION 2C – 23
DAEWOO V–121 BL4
Important : Record the position of the front spring locator
relative to the strut assembly–to–knuckle bracket. Place
the front spring locator back in

Page 941 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 2C – 24IFRONT SUSPENSION
DAEWOO V–121 BL4
Assembly Procedure
1. Install the brake splash shield. Refer to Section 4D,
Front Disc Brakes.
2. Install the hub and bearing assembly. Refer to ”Hub

Page 942 of 2643

DAEWOO LACETTI 2004 Service Repair Manual FRONT SUSPENSION 2C – 25
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
FRONT SUSPENSION
The front suspension for this vehicle is a combination of
a strut assembly and a knuckle assemb

Page 943 of 2643

DAEWOO LACETTI 2004 Service Repair Manual SECTION : 2D
REAR SUSPENSION
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed ele

SECTION : 2D
REAR SUSPENSION
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS2D–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 2D–2. . . . . . . . . . .
SPECIAL TOOLS2D–2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools Table 2D–2. . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS2D–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Excessive Friction Check 2D–3. . . . . . . . . . . . . . . . . . .
Strut Dampener 2D–3. . . . . . . . . . . . . . . . . . . . . . . . . . .
COMPONENT LOCATOR2D–4 . . . . . . . . . . . . . . . . . . . .
Rear Suspension 2D–4. . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR2D–6 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 2D–6. . . . . . . . . . . . . . . . . . . . .
Strut Assembly 2D–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Knuckle Assembly 2D–9. . . . . . . . . . . . . . . . . . . . . . . . .
Trailing Link 2D–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Trailing Link Bracket 2D–11. . . . . . . . . . . . . . . . . . . . . .
Front Parallel Link 2D–12. . . . . . . . . . . . . . . . . . . . . . . .
Rear Parallel Link 2D–13. . . . . . . . . . . . . . . . . . . . . . . . .
Stabilizer Shaft 2D–13. . . . . . . . . . . . . . . . . . . . . . . . . . .
Stabilizer Link 2D–14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Crossmember 2D–14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hub and Bearing Assembly 2D–15. . . . . . . . . . . . . . . .
UNIT REPAIR 2D–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Springs and Insulators 2D–17. . . . . . . . . . . . . . . . . . . . .
Knuckle 2D–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hub and Bearing 2D–19. . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION 2D–20 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Suspension 2D–20. . . . . . . . . . . . . . . . . . . . . . . . .

Page 944 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 2D – 2IREAR SUSPENSION
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Crossmember–to–Body Bolts11 283–
Strut Dampener–to–Strut Mount Nut7
