DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 163 DAEWOO V–121 BL4 120. Install the oil strainer to the valve body with the 3 bolts. Tighten Tighten the bolts to 9.8 NSm (87 lb–in). 121. Install the 2 magn

Page 1754 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 164IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 124. Install the No.1 breather plug. 125. Install the input shaft speed (ISS) sensor with the bolt. Tighten Tighten the bolts to 5.4 NSm (48

Page 1755 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 165 DAEWOO V–121 BL4 132. Temporarily install the control lever. 133. Turn the lever counterclockwise until it stops, then turn it clockwise 2 notches. 134. Rem

Page 1756 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 166IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 138. Install the control lever, washer and nut. Tighten Tighten the nut to 12 NSm (106 lb–in). 139. Install the torque converter to the tra

Page 1757 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 167 DAEWOO V–121 BL4 OIL PUMP 1. Oil Pump Body 2. Oil Pump Drive Gear 3. Oil Pump Driven Gear4. Stator Shaft 5. Bolt

Page 1758 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 168IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Disassembly Procedure 1. Turn the drive gear with 2 screwdrivers and make sure it rotates smoothly. Notice : Be careful not to damage the oil

Page 1759 of 2643

DAEWOO LACETTI 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 169 DAEWOO V–121 BL4 2. Measure the tip clearance between the driven gear teeth and drive gear teeth. S Standard tip clearance: 0.07  0.15 mm (0.0028  0.0059 i

Page 1760 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 5A2 – 170IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 Assembly Procedure 1. Install the oil pump drive gear and driven gear. 2. Align the stator shaft with each bolt hole. 3. Install the 8 bolts
