Page 1521 of 2643
5A1 – 172IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1868
EDS 6 OUTPUT SHORTED TO POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output voltage of the EDS 6 (at ON) is 12 volt.
S No DTC P1867, P1869.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1868 sets, the possible cause of fault
could be TCM.
Page 1522 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 173
DAEWOO V–121 BL4
DTC P1868 – EDS 6 Output Shorted To Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 6 ON/OFF.
Does the EDS 6 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Remove the oil pan.
2. Disconnect the wiring connector of EDS 6.
3. Turn the ignition ON, with the engine OFF.
4. Measure the voltage terminal 2 of the EDS 6
wiring connector.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the internal line(EDS 6) for a short to power.
Is the repair complete?–System OK–
5Replace the EDS 6.
Is the replacement complete?–Go to Step 6–
61. Check if any DTCs are set.
2. Are any DTCs displayed that have not been
diagnosed?–Go to ”Applica-
ble DTC table”System OK
Page 1523 of 2643
5A1 – 174IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1869
EDS 6 OUTPUT OPEN
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output ampere of the EDS 6 is less than 10mA.
S No DTC P1867, P1868.
S Immediately after the above condition occurs.
Action Taken When The DTC SetsS The Malfunction Indicator Lamp(MIL) will illuminate.
S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1869 sets, the possible cause of fault
could be EDS valve.
Page 1524 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 175
DAEWOO V–121 BL4
DTC P1869 – EDS 6 Output Open
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 6 ON/OFF.
Does the EDS 6 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 11 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 6.
3. Measure the resistance between terminal 2 of
the EDS 6 and terminal 5 of the transaxle con-
nector.
4. Measure the resistance between terminal 1 of
the EDS 6 and terminal 11 of the transaxle
connector.
Is the resistance within the values shown? 0 WGo to Step 6Go to Step 5
51. Repair the circuit (between terminal 2 and ter-
minal 5) for an open.
2. Repair the circuit (between terminal 1 and ter-
minal 11) for an open.
Is the repair complete?–System OK–
6Replace the EDS 6.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and terminal C7
of the TCM wiring connector.
3. Measure the resistance between terminal 11 of
the transaxle wiring connector and terminal
A12 of the TCM wiring connector.
Is the resistance within the values shown? 0 WGo to Step 9Go to Step 8
8Repair the transaxle wiring harness for an open.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
3. Has the last test failed or is the current DTC
displayed?–Begin diagno-
sis againRepair verified
exit DTC chart
Page 1525 of 2643
5A1 – 176IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1871
EDS VALVE POWER SUPPLY CIRCUIT SHORTED TO
POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S If the voltage applied to high side driver is higher
than the threshold(6V) with high side driver switch
off status then a fault is detected.
S No DTC P1870.
S Immediately after the above condition occurs.
Action Taken When The DTC SetsS The Malfunction Indicator Lamp(MIL) will illuminate.
S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1871 sets, the possible cause of fault
could be EDS valve power supply line.
Page 1526 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 177
DAEWOO V–121 BL4
DTC P1871 – EDS Valve Power Supply Circuit Shorted to Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Start engine and allow it to warm up at idle.
4. Put gear selector in Part and set the parking
brake.
5. Observe ”EDS 3,4,5,6’s input ampere and out-
put ampere” on the scan tool.
Is the amperes within the values shown?EDS ampere
(0–2 Amp)Go to Diag-
nostic Aids"Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector and
TCM connector.
3. Measure the voltage of the transaxle wiring
terminal 5.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the circuit for a short to power.
Is the action complete?–System OK–
51. Remove the oil pan.
2. Disconnect the EDS valve wiring connector.
3. Turn the ignition ON.
4. Measure the voltage of the EDS 3 terminal 2.
5. Measure the voltage of the EDS 4 terminal 2.
6. Measure the voltage of the EDS 5 terminal 2.
7. Measure the voltage of the EDS 6 terminal 2.
Is the voltage within the values shown?11–14VGo to Step 6Go to Step 7
6Repair the circuits(power supply lines) for a short to
power.
Is the action complete?–System OK–
7Replace the TCM.
Is the action complete?–Go to Step 8–
81. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
Page 1527 of 2643
5A1 – 178IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1874
SOLENOID VALVE POWER SUPPLY CIRCUIT SHORTED
TO POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S No DTC P1873.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1874 sets, the possible cause of fault
could be solenoid valve power supply line.
Page 1528 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 179
DAEWOO V–121 BL4
DTC P1874 – Solenoid Valve Power Supply Circuit Shorted to
Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
Then, start engine and allow it to warm up at
idle.
3. Put gear selector in Park and set the parking
brake.
4. Observe ”solenoid 1,2” on the scan tool.
Is the solenoid ON ?–Go to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector and
TCM connector.
3. Measure the voltage of the transaxle wiring
terminal 3.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the circuit for a short to power.
Is the action complete?–System OK–
51. Remove the oil pan.
2. Disconnect the solenoid 1,2 wiring connector.
3. Turn the ignition ON.
4. Measure the voltage of the solenoid 1 terminal
2.
5. Measure the voltage of the solenoid 2 terminal
2.
Is the voltage within the values shown?11–14VGo to Step 6Go to Step 7
6Repair the circuits(power supply lines) for a short to
power.
Is the action complete?–System OK–
7Replace the TCM.
Is the action complete?–Go to Step 8–
81. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
