DAEWOO LACETTI 2004 Service Repair Manual ENGINE CONTROLS 1F – 75
DAEWOO V–121 BL4
MANIFOLD ABSOLUTE PRESSURE CHECK
(1.4L/1.6L DOHC)
Circuit Description
The Manifold Absolute Pressure (MAP) sensor measures
the changes in the intake mani

Page 322 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1F – 76IENGINE CONTROLS
DAEWOO V–121 BL4
Manifold Absolute Pressure Check (1.4L/1.6L DOHC)
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Connect a scan tool to the Data Link Connec-
tor

Page 323 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ENGINE CONTROLS 1F – 77
DAEWOO V–121 BL4
MANIFOLD ABSOLUTE PRESSURE CHECK (1.8L DOHC)
Circuit Description
The Manifold Absolute Pressure (MAP) sensor measures
the changes in the intake manifold p

Page 324 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1F – 78IENGINE CONTROLS
DAEWOO V–121 BL4
Manifold Absolute Pressure Check (1.8L DOHC)
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Connect a scan tool to the Data Link Connec-
tor (DLC)

Page 325 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ENGINE CONTROLS 1F – 79
DAEWOO V–121 BL4
IDLE AIR CONTROL SYSTEM CHECK (1.4L/1.6L DOHC)
Circuit Description
The aim of the MTIA (Main Throttle Idle Actuator) is to con-
trol the idle speed with t

Page 326 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1F – 80IENGINE CONTROLS
DAEWOO V–121 BL4
Idle Air Control System Check (1.4L/1.6L DOHC)
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the system check complete?

1F – 80IENGINE CONTROLS
DAEWOO V–121 BL4
Idle Air Control System Check (1.4L/1.6L DOHC)
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the system check complete?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
2Turn the ignition switch to ON.
Is the Malfunction Indicator Lamp (MIL) on steady?–Go to Step 4Go to Step 3
3Turn the ignition switch to LOCK.
Connect the scan tool to the DLC.
Turn the Turn the ignition switch to ON.
Are any diagnostic trouble codes (DTCs) displayed?–Go to Step 4Try with
another scan
tool
4Refer to the applicable DTC table.
Is only one DTC identified as valid trouble code
P0122?–Go to Step 5Go to
applicable DTC
table And go to
”Multiple DTC”
51. Connect the scan tool to the DLC.
2. Turn the ignition switch to ON.
3. Press the accelerator pedal while watching
TPS for smooth changes in the voltage.
Does the scan tool show the TPS voltage change
smoothly within the value specified?0.3V–4.8VGo to
”Diagnostic
Aids”Go to Step 6
61. Turn the ignition switch to lock.
2. Disconnect the MTIA connector.
3. Measure the voltage between terminal 2 and 8.
Does the voltage measure within the value speci-
fied?4.8V–5.0VGo to Step 7Go to Step 8
7Connect a fused jumper between the MTIA connec-
tor terminal 2 and terminal 7.
Does the scan tool show the TPS voltage above val-
ue specified?4.8V–5.0VGo to Step 13Go to Step 11
8Measure the voltage between the MTIA connector
2 and ground.
Does the voltage measure within the value speci-
fied?>5.0VGo to Step 9Go to Step 10
91. Turn the ignition switch to lock.
2. Check for an open or low voltage in the wire
between the MTIA connector 8 and ECM con-
nector 19.
Is the problem found?–Go to Step 12Go to Step 14
101. Turn the ignition switch to LOCK.
2. Check for an open or low voltage in the wire
between the MTIA connector 2 and ECM con-
nector 79.
Is the problem found?–Go to Step 12Go to Step 14
111. Turn the ignition switch to LOCK.
2. Check for an open or low voltage in the wire
between the MTIA connector 7 and ECM con-
nector 74.
Is the problem found?–Go to Step 12Go to Step 14

Page 327 of 2643

DAEWOO LACETTI 2004 Service Repair Manual ENGINE CONTROLS 1F – 81
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
121. Repair the wire or the connector terminal as
needed.
2. Clear any DTCs from ECM.
3. Perform the Diagnostic System Check

Page 328 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1F – 82IENGINE CONTROLS
DAEWOO V–121 BL4
IDLE AIR CONTROL SYSTEM CHECK (1.8L DOHC)
Circuit Description
The Engine Control Module (ECM) controls the engine idle
speed with the Idle Air Control (IAC

1F – 82IENGINE CONTROLS
DAEWOO V–121 BL4
IDLE AIR CONTROL SYSTEM CHECK (1.8L DOHC)
Circuit Description
The Engine Control Module (ECM) controls the engine idle
speed with the Idle Air Control (IAC) valve. To increase the
idle speed, the ECM pulls the IAC pintle away from its seat,
allowing more air to pass by the throttle body. To decrease
the idle speed, it extends the IAC valve pintle toward its
seat, reducing bypass air flow. A scan tool will read the
ECM commands to the IAC valve in counts. The higher
counts indicate more air bypass (higher idle). The lower
counts indicate less air is allowed to bypass (lower idle).
Diagnostic Aids
If the idle is too high, stop the engine. Fully extend the Idle
Air Control (IAC) valve with a IAC driver. Start the engine.
If the idle speed is above 800 rpm, locate and repair the
vacuum leak. Also, check for a binding throttle plate or
throttle linkage or an incorrect base idle setting.
Test Description
The number(s) below refer to step(s) on the diagnostic
table.
2. The IAC valve is extended and retracted by the IAC
driver. IAC valve movement is verified by an engine
speed change. If no change in engine speed oc-
curs, the valve can be removed from the throttle
body and tested. Connect the IAC driver to the re-
moved IAC valve and turn the ignition ON. Do not
start the engine.5. This step checks the quality of the IAC valve move-
ment in Step 2. Fully extending the IAC valve may
cause an engine stall. This may be normal.
6. Steps 2 and 5 verify proper IAC valve operation.
This step checks the IAC circuit for a wiring or ECM
fault.
Idle Air Control Valve Reset Procedure
Whenever the battery cable or the Engine Control Module
(ECM) connector or the ECM fuse Ef11 is disconnected or
replaced, the following idle learn procedure must be per-
formed:
1. Turn the ignition ON for 5 seconds.
2. Turn the ignition OFF for 10 seconds.
3. Turn the ignition ON for 5 seconds.
4. Start the engine in park/neutral.
5. Allow the engine to run until the engine coolant is
above 185°F (85°C).
6. Turn the A/C ON for 10 seconds, if equipped.
7. Turn the A/C OFF for 10 seconds, if equipped.
8. If the vehicle is equipped with an automatic trans-
axle, apply the parking brake. While pressing the
brake pedal, place the transaxle in D (drive).
9. Turn the A/C ON for 10 seconds, if equipped.
10. Turn the A/C OFF for 10 seconds, if equipped.
11. Turn the ignition OFF. The idle learn procedure is
complete.
