DTC P1629 – Immobilizer Wrong Computation
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the system check complete?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
21. Turn the ignition OFF.
2. Install a scan too to the Data Link Connector
(DLC).
3. Turn the ignition ON.
4. Select IMMOBILIZER DIAGNOSIS STATUS
from the scan tool menu.
Is the communication established between the scan
tool and the immobilizer control unit?–Go to Step 3Go to
Section 9T, Im-
mobillzer Anti–
Theft System
31. Turn the ignition OFF.
2. Disconnect the Immobilizer Control Unit and
Engine Control Module (ECM) connectors.
3. Measure the resistance between terminal 7 of
immoblizer control unit and terminal 56 of the
ECM.
Is the resistance within the specified value?0WGo to Step 5Go to Step 4
4Repair an open circuit between terminal 7 of immobi-
lizer control unit and terminal 56 of the ECM.
Is the repair complete?–Go to Step 8–
5Check the terminals in immobilizer control unit and
the ECM for damages and repair as needed.
Is the repair complete?–Go to Step 8Go to Step 6
6Replace the immobilizer control unit.
Is the repair complete?–Go to Step 8Go to Step 7
71. Turn the ignition OFF.
2. Replace the ECM.
Is the repair complete?–Go to Step 8–
81. Using the scan tool, clear the Diagnostic
Trouble Codes (DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the Conditions for
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic has
run and passed?–Go to Step 9Go to Step 2
9Check if any additional DTCs are set.
Are any DTCs displayed that have not been diag-
nosed?–Go to
applicable DTC
tableSystem OK
Page 586 of 2643
1F – 340IENGINE CONTROLS
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P1660
MALFUNCTION INDICATOR LAMP (MIL) HIGH VOLTAGE
Circuit Description
When the ignition switch to ON, the Malfunction Indicator
Lamp (MIL) is ON steady.
When the engine cranking, the Malfunction Indicator
Lamp (MIL) is OFF after one flashing time.
If a system have some difficulties, the Malfunction Indica-
tor Lamp (MIL) is ON.
Conditions for Setting the DTC
S The Malfunction Indicator Lamp (MIL) wiring har-
ness high voltage.
Action Taken When the DTCs Sets
S The Malfunction Indicator Lamp (MIL) will illuminate
after three consecutive trip with a fail.
S The ECM will record operating conditions at the
time the diagnostic fail. This information will be
stored in the Freeze Frame and Failure Records
buffers.
S A history DTC is stored.
Conditions for Clearing the MIL/DTCS The MIL will turn off after four consecutive ignition
cycles in which the diagnostic runs without a fault.
S A history DTC will clear after 40 consecutive warm–
up cycles without a fault.
S DTC(s) can be cleared by using the scan tool.
S Disconnecting the ECM battery feed for more than
10 seconds.
Diagnostic Aids
An Intermittent problem may be caused by a poor connec-
tion, rubbed through wire insulation, or wire that is broken
inside the insulation.
Any circuitry, that is suspected as causing the complaint,
should be thoroughly checked for the following conditions.
S Backed–out terminals
S Improper mating
S Broken locks
S Improperly formed
S Damaged terminals
S Poor terminals to wire connection
S Physical damage to the wiring harness
Page 587 of 2643
ENGINE CONTROLS 1F – 341
DAEWOO V–121 BL4
DTC P1660 – Malfunction Indicator Lamp (MIL) High Voltage
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the system check complete?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
21. Turn the ignition switch to LOCK.
2. Disconnect the cluster wiring connector.
3. With the test light, connected to ground, probe
the ignition feed circuit, at terminal B6 in the
harness connector.
Does the resistance within the specified value?0WGo to Step 3Go to Step 6
31. Turn the ignition switch to LOCK.
2. With the test light, connected to ground, probe
the ignition feed circuit, at ECM wiring connec-
tor terminal 39.
Does the test light illuminate?–Go to Step 4–
41. Turn the ignition switch to LOCK.
2. Replace the cluster.
Is the replacement complete?–Go to Step 6–
5Repair a short to battery between the ECM wiring
connector terminal 39 and cluster wiring connector
terminal B6.
Is the repair complete?–Go to Step 6–
61. Using the scan tool, clear the Diagnostic
Trouble Codes(DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic has
run and passed?–Go to Step 7Go to Step 2
7Check if any additional DTCs are set.
Are any DTCs displayed that have not been diag-
nosed?–Go to
applicable DTC
tableSystem OK
Page 588 of 2643
1F – 342IENGINE CONTROLS
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P1661
MALFUNCTION INDICATOR LAMP (MIL) LOW VOLTAGE
Circuit Description
When the ignition switch to ON, the Malfunction Indicator
Lamp (MIL) is ON steady.
When the engine cranking, the Malfunction Indicator
Lamp (MIL) is OFF after one flashing time.
If a system have some difficulties, the Malfunction Indica-
tor Lamp (MIL) is ON.
Conditions for Setting the DTC
S The Malfunction Indicator Lamp (MIL) wiring har-
ness low voltage.
Action Taken When the DTC Sets
S The Malfunction Indicator Lamp (MIL) will illuminate
after three consecutive trip with a fail.
S The ECM will record operating conditions at the
time the diagnostic fail. This information will be
stored in the Freeze Frame and Failure Records
buffers.
S A history DTC is stored.
Conditions for Clearing the MIL/DTCS The MIL will turn off after four consecutive ignition
cycles in which the diagnostic runs without a fault.
S A history DTC will clear after 40 consecutive warm–
up cycles without a fault.
S DTC(s) can be cleared by using the scan tool.
S Disconnecting the ECM battery feed for more than
10 seconds.
Diagnostic Aids
An Intermittent problem may be caused by a poor connec-
tion, rubbed through wire insulation, or wire that is broken
inside the insulation.
Any circuitry, that is suspected as causing the complaint,
should be thoroughly checked for the following conditions.
S Backed–out terminals
S Improper mating
S Broken locks
S Improperly formed
S Damaged terminals
S Poor terminals to wire connection
S Physical damage to the wiring harness
Page 589 of 2643
ENGINE CONTROLS 1F – 343
DAEWOO V–121 BL4
DTC P1661 – Malfunction Indicator Lamp (MIL) Low Voltage
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the system check complete?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
21. Turn the ignition switch to LOCK.
2. Disconnect the cluster wiring connector.
3. With the test light, connected to ground, probe
the ignition feed circuit, at terminal B6 in the
harness connector.
Does the resistance within the specified value?0WGo to Step 3Go to Step 6
31. Turn the ignition switch to LOCK.
2. With the test light, connected to ground, probe
the ignition feed circuit, at ECM wiring connec-
tor terminal 39.
Does the test light illuminate?–Go to Step 4–
41. Turn the ignition switch to LOCK.
2. Replace the cluster.
Is the replacement complete?–Go to Step 6–
5Repair a short to ground or open between the ECM
wiring connector terminal 39 and cluster wiring con-
nector terminal B6.
Is the repair complete?–Go to Step 6–
61. Using the scan tool, clear the Diagnostic
Trouble Codes(DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic has
run and passed?–Go to Step 7Go to Step 2
7Check if any additional DTCs are set.
Are any DTCs displayed that have not been diag-
nosed?–Go to
applicable DTC
tableSystem OK
Page 590 of 2643
1F – 344IENGINE CONTROLS
DAEWOO V–121 BL4
TROUBLE CODE DIAGNOSIS (1.8L DOHC)
CLEARING TROUBLE CODES
Notice : To prevent Engine Control Module (ECM) dam-
age, the key must be OFF when disconnecting or recon-
necting the power to the ECM (for example battery cable,
ECM pigtail connector, ECM fuse, jumper cables, etc.).
When the ECM sets a Diagnostic Trouble Code (DTC), the
Malfunction Indicator Lamp (MIL) lamp will be turned on
only for type A, B and E but a DTC will be stored in the
ECM’s memory for all types of DTC. If the problem is inter-mittent, the MIL will go out after 10 seconds if the fault is
no longer present. The DTC will stay in the ECM’s memory
until cleared by scan tool. Removing battery voltage for 10
seconds will clear some stored DTCs.
DTCs should be cleared after repairs have been com-
pleted. Some diagnostic tables will tell you to clear the
codes before using the chart. This allows the ECM to set
the DTC while going through the chart, which will help to
find the cause of the problem more quickly.
DIAGNOSTIC TROUBLE CODES (1.8L DOHC)
DTCDescriptionTypeIlluminate MIL
P0106Manifold Absolute Pressure RationalityEYe s
P0107Manifold Absolute Pressure Low VoltageAYe s
P0108Manifold Absolute Pressure High VoltageAYe s
P0112Intake Air Temperature Low VoltageEYe s
P0113Intake Air Temperature High VoltageEYe s
P0117Engine Coolant Temperature Low VoltageAYe s
P0118Engine Coolant Temperature High VoltageAYe s
P0122Throttle Position Sensor Low VoltageAYe s
P0123Throttle Position Sensor High VoltageAYe s
P0131Front Heated Oxygen Sensor (HO2S1) Low VoltageAYe s
P0132Front Heated Oxygen Sensor (HO2S1) High VoltageAYe s
P0133Front Heated Oxygen Sensor (HO2S1) Slow ResponseEYe s
P0134Front Heated Oxygen Sensor (HO2S1) No Activity or OpenAYe s
P0135Front Heated Oxygen Sensor (HO2S1) Heater Circuit Not FunctioningEYe s
P0137Rear Heated Oxygen Sensor (HO2S2) Low VoltageEYe s
P0138Rear Heated Oxygen Sensor (HO2S2) High VoltageEYe s
P0140Rear Heated Oxygen Sensor (HO2S2) No Activity or OpenEYe s
P0141Rear Heated Oxygen Sensor (HO2S2) Heater Circuit Not FunctioningEYe s
P0171Fuel Trim System Too LeanBYe s
P0172Fuel Trim System Too RichBYe s
P0201Injector 1 Circuit FaultAYe s
P0202Injector 2 Circuit FaultAYe s
P0203Injector 3 Circuit FaultAYe s
P0204Injector 4 Circuit FaultAYe s
P0300Multiple Cylinder Misfire DetectedBYe s
P0301Cylinder 1 MisfireAYe s
P0302Cylinder 2 MisfireAYe s
P0303Cylinder 3 MisfireAYe s
P0304Cylinder 4 MisfireAYe s
P0317Rough Road Sensor Source Not DetectedCnlNo
P0325Knock Sensor Internal MalfunctionCnlNo
Page 591 of 2643
ENGINE CONTROLS 1F – 345
DAEWOO V–121 BL4
DTCIlluminate MIL Type Description
P0327Knock Sensor Circuit FaultCnlNo
P033658X Crank Position Sensor Extra/Missing PulsesEYe s
P033758X Crank Position Sensor No SignalAYe s
P0341Camshaft Position Sensor RationalityEYe s
P0342Camshaft Position Sensor No SignalAYe s
P0351Ignition Control Circuit A Fault (Cylinder 1 and 4)AYe s
P0352Ignition Control Circuit B Fault (Cylinder 2 and 3)AYe s
P0401Exhaust Gas Recirculation Insufficient FlowCnlNo
P0402Exhaust Gas Recirculation Excessive FlowEYe s
P0404Exhaust Gas Recirculation Open Valve Position ErrorEYe s
P0405Exhaust Gas Recirculation Pintle Position Low VoltageEYe s
P0406Exhaust Gas Recirculation Pintle Position High VoltageEYe s
P0420Catalyst Oxygen Sensor Low EfficiencyAYe s
P0443Evaporative Emission System Purge Solenoid Control CircuitEYe s
P0461Fuel Level StuckCnlNo
P0462Fuel Level Low VoltageCnlNo
P0463Fuel Level High VoltageCnlNo
P0502Vehicle Speed Sensor No Signal (Engine Side)EYe s
P0506Idle Speed rpm Lower Than Desired Idle SpeedEYe s
P0507Idle Speed rpm Higher Than Desired Idle SpeedEYe s
P0532A/C Pressure Sensor Low VoltageCnlNo
P0533A/C Pressure Sensor High VoltageCnlNo
P0562System Voltage Too Low (Engine Side)CnlNo
P0563System Voltage Too High (Engine Side)CnlNo
P0601ECM Checksum Error (Engine Side)AYe s
P0602ECM Reprogram ErrorAYe s
P0607Lower Power Counter ErrorCnlNo
P0700Transaxle Control Module MalfunctionAYe s
P1106Manifold Absolute Pressure Intermittent High VoltageCnlNo
P1107Manifold Absolute Pressure Intermittent Low VoltageCnlNo
P 1111Intake Air Temperature Intermittent High VoltageCnlNo
P1112Intake Air Temperature Intermittent Low VoltageCnlNo
P1114Engine Coolant Temperature Intermittent Low VoltageCnlNo
P1115Engine Coolant Temperature Intermittent High VoltageCnlNo
P1121Throttle Position Sensor Intermittent High VoltageCnlNo
P1122Throttle Position Sensor Intermittent Low VoltageCnlNo
P1133Front Heated Oxygen Sensor (HO2S1) Too Few TransitionsEYe s
P1134Front Heated Oxygen Sensor (HO2S1) Transition RatioEYe s
P1167Front Heated Oxygen Sensor (HO2S1) Rich in Decel Fuel Cut–off (DFCO)AYe s
P1171Fuel Trim System Lean During Power EnrichmentBYe s
P133658X Crank Position Tooth Error Not LearnedAYe s
P1391G Sensor Rough Road RationalityCnlNo
Page 592 of 2643
1F – 346IENGINE CONTROLS
DAEWOO V–121 BL4
DTCIlluminate MIL Type Description
P1392G Sensor Rough Road Low VoltageCnlNo
P1393G Sensor Rough Road High VoltageCnlNo
P1396ABS WSS Signal VariationCnlNo
P1397ABS WSS No SignalCnlNo
P1404Exhaust Gas Recirculation Closed Valve Pintle ErrorEYe s
P1601SPI Communications Between ECM and TCMAYe s
P1607Lower Power Counter ResetCnlNo
P1626Immobilizer No ResponseCnlNo
P1631Immobilizer Incorrect ResponseCnlNo
P1650SPI Communications Between Error with SIDM ChipCnlNo
P1655SPI Communications Between Error with PSVI ChipEYe s
