9L – 18IGLASS AND MIRRORS
DAEWOO V–121 BL4
OUTSIDE REARVIEW MIRRORS
Removal Procedure
1. Remove the front door escutcheon.
2. Disconnect the mirror electrical connector if the mir-
ror is electronically controlled.
3. Remove the bolts and the outside rearview mirror
assembly from the door.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the outside rearview mirror assembly to the
door with the screws.
Tighten
Tighten the outside rearview mirror assembly screws
to 4.5 NSm (40 lb–in).
2. Connect the mirror electrical connector if the mirror
is electronically controlled.
3. Install the front door escutcheon.
FOLDING MIRRORS UNIT
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the grove box. Refer to Section 9E, Grove
Box.
3. Remove the bolt.
4. Remove the folding mirror unit
Installation Procedure
1. Install the folding mirror unit with the bolt.
Tighten
Tighten the folding mirror unit bolt to 10 NSm (89 lb–
in).
2. Connect the folding mirror unit electrical connector.
3. Connect the negative cable.
