DAEWOO LACETTI 2004 Service Repair Manual 1C1 – 6I1.4L/1.6L DOHC ENGINE MECHANICAL DAEWOO V–121 BL4 Application Lb–InLb–Ft NSm Oil Pump Bolts10–89 Oil Pump Rear Cover Bolts8–71 Oil Pump Retaining Bolts10–89 Oil Suction Pipe or S

Page 50 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1.4L/1.6L DOHC ENGINE MECHANICAL 1C1 – 7 DAEWOO V–121 BL4 SPECIAL TOOLS SPECIAL TOOLS TABLE J–42492 Timing Belt Adjuster KM–470–B Angular Torque Gauge J–28467–B Engine Assembly Support

Page 51 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1C1 – 8I1.4L/1.6L DOHC ENGINE MECHANICAL DAEWOO V–121 BL4 KM–805 Valve Guide Reamer KM–412 Engine Overhaul Stand KM–498–B Pressure Gauge KM–635 Crankshaft Rear Oil Seal Installer J–367

Page 52 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1.4L/1.6L DOHC ENGINE MECHANICAL 1C1 – 9 DAEWOO V–121 BL4 COMPONENT LOCATOR CYLINDER HEAD 1. Oil Filler Cap 2. Engine Cover 3. Camshaft Cover 4. Camshaft Cover Gasket 5. Camshaft Cover Bolt 6.

Page 53 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1C1 – 10I1.4L/1.6L DOHC ENGINE MECHANICAL DAEWOO V–121 BL4 CYLINDER BLOCK

Page 54 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1.4L/1.6L DOHC ENGINE MECHANICAL 1C1 – 11 DAEWOO V–121 BL4 1. Piston Ring Set 2. Piston 3. Piston Pin 4. Connecting Rod 5. Connecting Rod Bearing Set 6. Oil Level Gauge Stick 7. Gauge Stic Tu

Page 55 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1C1 – 12I1.4L/1.6L DOHC ENGINE MECHANICAL DAEWOO V–121 BL4 INTAKE & EXHAUST MANIFOLD 1. Oxygen Sensor 2. Heat Shield 3. Exhaust Manifold 4. Exhaust Manifold Gasket 5. Intake Manifold 6. Main Thr

Page 56 of 2643

DAEWOO LACETTI 2004 Service Repair Manual 1.4L/1.6L DOHC ENGINE MECHANICAL 1C1 – 13 DAEWOO V–121 BL4 TIMING BELT 1. Water Pump Sealing 2. Water Pump 3. Timing Belt Rear Cover 4. Camshaft Position Sensor 5. Auto Temsioner 6. Camshaft G
