Page 1993 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (17) Remove screws attaching pressure adjusting screw bracket to valve body and transfer plate (Fig. 286). Hold bracket firmly against spring tension while removing last screw. (18) Remove adjusting s

Page 1994 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual Fig. 288 Upper Housing Control Valve Locations 1 - UPPER HOUSING 8 - MANUAL VALVE 2 - REGULATOR VALVE 9 - 1-2 GOVERNOR PLUG 3 - SWITCH VALVE 10 - GOVERNOR PLUG COVER 4 - REGULATOR VALVE SPRING 11 - TH

Page 1995 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (23) Remove left-side screw and remove 3-4 accu- mulator housing from valve body (Fig. 291). (24) Bend back tabs on boost valve tube brace (Fig. 292).(25) Remove boost valve connecting tube (Fig. 293)

Page 1996 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (29) Remove the Number 10 check ball from the transfer plate (Fig. 295). The check ball is approxi- mately 4.8 mm (3/16 in.) in diameter. (30) Remove transfer plate from upper housing (Fig. 296). (31)

Page 1997 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual VALVE BODY UPPER HOUSING (1) Note location of check balls in valve body upper housing (Fig. 299). Then remove the one large diam- eter and the five smaller diameter check balls. (2) Remove governor pl

Page 1998 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual Fig. 301 Shuttle and Boost Valve Location 1 - SPRING 8 - SHUTTLE VALVE COVER 2 - RETAINER 9 - SHUTTLE VALVE 3 - BOOST VALVE 10 - SHUTTLE VALVE PRIMARY SPRING 4 - BOOST VALVE PLUG 11 - GOVERNOR PLUG CO

Page 1999 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual Fig. 302 Upper Housing Shift Valve and Pressure Plug Locations 1 - UPPER HOUSING 7 - LIMIT VALVE AND SPRING 2 - 1-2 SHIFT VALVE AND SPRING 8 - RETAINER 3 - 2-3 SHIFT VALVE AND SPRING 9 - 1-2 SHIFT CON

Page 2000 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual VALVE BODY LOWER HOUSING (1) Remove timing valve cover. (2) Remove 3-4 timing valve and spring. (3) Remove 3-4 quick fill valve, spring and plug. (4) Remove 3-4 shift valve and spring. (5) Remove conv
