DODGE RAM 1500 1998 2.G Workshop Manual NATURAL VACUUM LEAK DETECTION ASSEMBLY (NGC) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 Z910 18BK GROUND 2 K107 18VT/WT NVLD SWITCH SIGNAL 3 K106 18VT/LB NVLD SOLENOID CONTROL OUTPUT SPEED SENSOR (45RFE) -

Page 1130 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual OXYGEN SENSOR 1/1 UPSTREAM (NGC) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 K99 18BR/LG O2 1/1 HEATER CONTROL 2 Z42 18BK/LG GROUND 3 K902 18BR/DG O2 RETURN (UP) 4 K41 18DB/LB O2 1/1 SIGNAL OXYGEN SENSOR 1/2

Page 1131 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual PARK/TURN SIGNAL LAMP-LEFT FRONT - BROWN 3 WAY CAV CIRCUIT FUNCTION 1 L61 18WT/LG LEFT FRONT TURN LAMP DRIVER 2 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT 3 Z377 18BK/BR GROUND PARK/TURN SIGNAL LAMP-RIGH

Page 1132 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual POWER MIRROR-RIGHT - BLACK 8 WAY CAV CIRCUIT FUNCTION 1 C16 18DB/GY HEATED MIRROR RELAY OUTPUT 2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN) 3 P74 18TN/OR RIGHT MIRROR LEFT DRIVER 4 P72 18TN/G

Page 1133 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual POWER SEAT MOTOR-DRIVER HORIZONTAL-2WAY CAV CIRCUIT FUNCTION 1 P17 12LG/DG DRIVER SEAT HORIZONTAL FORWARD DRIVER 2 P15 12LG/BR DRIVER SEAT HORIZONTAL REARWARD DRIVER POWER SEAT MOTOR-DRIVER REAR VERTI

Page 1134 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual POWER SEAT SWITCH-DRIVER - 12 WAY CAV CIRCUIT FUNCTION A A210 12OR/RD FUSED B(+) B Z939 14BK GROUND C P105 12LG LUMBAR MOTOR FORWARD D P13 12LG/OR DRIVER SEAT REAR DOWN E P107 12LG/WT LUMBAR MOTOR REA

Page 1135 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual POWER WINDOW CIRCUIT BREAKER-2WAY CAV CIRCUIT FUNCTION 1 F991 10PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-START) 2 F30 12PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) POWER WINDOW MOTOR-DRIVER-2WAY CAV C

Page 1136 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual POWER WINDOW MOTOR-RIGHT REAR-2WAY CAV CIRCUIT FUNCTION A Q212 14TN/LB PASSENGER REAR WINDOW DRIVER (DOWN) B Q112 14TN/YL PASSENGER REAR WINDOW DRIVER (UP) POWER WINDOW SWITCH-LEFT REAR - BLUE 6 WAY C
