Page 2217 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CONDITION POSSIBLE CAUSE CORRECTION
Lubricant leaking from transfer case
seals or vent.1) Transfer case overfilled. 1) Drain lubricant to the correct
level.
2) Transfer case vent closed or
restricted.

CONDITION POSSIBLE CAUSE CORRECTION
Lubricant leaking from transfer case
seals or vent.1) Transfer case overfilled. 1) Drain lubricant to the correct
level.
2) Transfer case vent closed or
restricted.2) Clean or replace vent as
necessary.
3) Transfer case seals damaged or
installed incorrectly.3) Replace suspect seal.
Transfer case will not shift through
4HI (Part-time) range.1) Incomplete shift due to drivetrain
torque load.1) Drive in a straight line and
momentarily release the accelerator
pedal to complete the shift.
2) Incorrect tire pressure. 2) Correct tire pressure as
necessary.
3) Excessive tire wear. 3) Correct tire condition as
necessary.
4) Excessive vehicle loading. 4) Correct as necessary.
REMOVAL
(1) Shift transfer case into AWD.
(2) Raise vehicle.
(3) Drain transfer case lubricant.
(4) Mark front and rear propeller shafts for align-
ment reference.
(5) Support transmission with jack stand.
(6)
Remove the transfer case skid plate, if equipped.
(7) Disconnect front and rear propeller shafts at
transfer case.
(8) Disconnect transfer case shift motor and mode
sensor wire connectors.
(9) Disconnect transfer case vent hose.
(10) Support transfer case with transmission jack.
(11) Secure transfer case to jack with chains.
(12) Remove nuts attaching transfer case to trans-
mission (Fig. 2).(13) Pull transfer case and jack rearward to disen-
gage transfer case.
(14) Remove transfer case from under vehicle.
DISASSEMBLY
Position transfer case in a shallow drain pan.
Remove drain plug and drain any remaining lubri-
cant remaining in case.
SHIFT MOTOR ASSEMBLY AND FRONT OUTPUT
SHAFT SEAL
(1) Remove the bolts (Fig. 3) which hold the shift
motor and mode sensor assembly to the transfer
case.
Fig. 2 Remove Transfer Case - Typical
1 - TRANSMISSION
2 - TRANSFER CASE
3 - MODE SENSOR CONNECTOR
Fig. 3 Remove the Shift Motor and Mode Sensor
Assembly Bolts - Typical
1 - TRANSFER CASE
2 - SHIFT MOTOR AND MODE SENSOR ASSEMBLY
3 - BOLT
21 - 514 TRANSFER CASE - NV244 GENIIDR
TRANSFER CASE - NV244 GENII (Continued)

Page 2218 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (2) Remove the shift motor and mode sensor
assembly from the transfer case.
(3) Remove the front propeller shaft seal boot
retaining clamp (Fig. 4).
(4) Remove the front propeller shaft seal boot (Fig

Page 2219 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (2) Remove rear extension housing (Fig. 8). Tap
extension once or twice with a plastic mallet to break
sealer bead and loosen it.
(3) Remove output bearing retaining ring with
heavy duty snap-ring pli

Page 2220 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (4) Remove rear case and oil pump assembly from
front case (Fig. 12).
(5) Remove the oil pump pickup tube.
FRONT OUTPUT SHAFT AND DRIVE CHAIN
(1) Remove shift rail spring (Fig. 13).(2) Remove front sp

Page 2221 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (4) Remove the rear output shaft retaining ring
(Fig. 16) from the output shaft.
(5) Pull front sprocket, rear sprocket, and chain
outward simultaneously (Fig. 17).
(6) Remove front sprocket, rear spr

Page 2222 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (4) Remove front output shaft from bearing in
case.
(5) Remove the mainshaft and differential assem-
bly (Fig. 20) from the input gear and transfer case.
(6) Remove the shift rail (Fig. 21) from the r

Page 2223 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (9) Remove the shift sector o-ring (Fig. 24).
MAINSHAFT
(1) Remove intermediate clutch shaft snap-ring
(Fig. 25).(2) Remove the intermediate clutch shaft thrust
ring (Fig. 26).
(3) Remove the intermed

Page 2224 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (4) Remove the differential snap-ring (Fig. 28).(5) Remove the differential assembly (Fig. 29) from
the mainshaft.
(6) Remove the mode hub (Fig. 30) and mode hub
retainer from the differential assembl
